Desa Wall Mantel and Base with Trim W32DS Assembly And Installation Instructions

Wall Mantel and Base with Trim

ASSEMBLY AND INSTALLATION INSTRUCTIONS

Important: Read entire instruction sheet before
assembling or installing mantel kit.
these mantels are only approved for use with any
DESA Heating Products compact fireplace system.
Do not use mantel with any other product.
This mantel kit contains the following:
• Mantel pieces - unassembled and marked as follows:
Base #1
Right Side #2 with arrow
Right Front Leg #3 with arrow Header #6 with arrow
Top #7
• Hardware Package (117197-01)
• Bracket Hardware Kit (118983-01)
• Trim Kit 113140-02 (26"), 113140-01 (32") or
113140-14 (36")
• Trim Kit Hardware (102866-01)
The hardware kit 117197-01 contains the following:
• 28 - 1 ⁄ " Screws
1
4
• 2 - 3" Screws
Tools required:
• #2 Phillips drill bit (3 1 /
• Slotted screw driver
• Measuring Tape
If any wood pieces are missing or damaged, contact the
dealer where you purchased this mantel for replacement.
If hardware or trim is missing or damaged, contact DESA
Heating Products at 1-866-672-6040 for referral informa-
tion. You can also visit DESA Heating Products' technical service
web site at
www.desatech.com.
WS26DS, W32DS and W36DS
Left Side #4 with arrow
Left Front Leg #5 with arrow
" min. length)
2
• Drill Driver
• Pencil
www.desatech.com
Note: Gather all mantel pieces together before assembling
mantel.
WARNING: Only use 1
assemble mantel. Damage to mantel will result if other
screws are used for this purpose.
WARNING: Use only 1/2" or 3/4" screws with brack-
ets in hardware pack 118983-01. Damage to mantel will
result if other screws are used for this purpose.
AssemblING mANtel
ImPORtANt: more than one person is required to lift
assembled mantel. lift mantel by leg assemblies. lifting
by header or mantel top could damage mantel.
1. For leg assembly, lay side or front that does not contain
pocket holes front side down on a soft surface. Pocket
hole locations will vary by model. Pay special attention
to the up direction arrows on panels.
2. Position second panel as shown in Figure 1, page 2. Align
panels at bottom. With one person holding the panel align-
ment secure, attach panels using 1
pocket holes. Check assembly for correct alignment.
3. Repeat steps 1 and 2 for second leg assembly.
4. Each leg assembly will use 3 brackets for stability. Your
bracket hardware kit will contain either 1/2" or 3/4" screws.
Using two 1/2" or 3/4" screws, install a bracket in the center
of each leg assembly and one at each end within 1" of but
not over the last pocket hole (see Figure 2, page 2).
/ " screws in pocket holes to
1
4
/ " screws through
1
4
