b-Vent deCoratIVe eleCtronIC IGnItIon Gas FIrePlaCe
oWner's oPeratIon and InstallatIon manual
models m36e(b,h), m42e(b,h), Vm36e(b,h) and Vm42e(b,h)
models m36eP(b,h), m42eP(b,h), Vm36eP(b,h) and
WARNING: If the information in these instructions is
not followed exactly, a fire or explosion may result
causing property damage, personal injury or death.
— Do not store or use gasoline or any other flammable
vapors or liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS :
• Do not try to light any appliance.
• Do not touch any electrical switch;
• Do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a quali-
fied installer, service agency or the gas supplier.
INSTALLER: Leave this manual with the appliance
CONSUMER: Retain this manual for future reference.
natural Gas
Vm42eP(b,h) ProPane/lP Gas
FOR YOUR SAFETY
For more information, visit www.desatech.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Desa Vm42eP
Summary of Contents for Desa Vm42eP
- Page 1 IGnItIon Gas FIrePlaCe oWner’s oPeratIon and InstallatIon manual models m36e(b,h), m42e(b,h), Vm36e(b,h) and Vm42e(b,h) models m36eP(b,h), m42eP(b,h), Vm36eP(b,h) and Vm42eP(b,h) ProPane/lP Gas WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result causing property damage, personal injury or death. — Do not store or use gasoline or any other flammable vapors or liquids in the vicinity of this or any other appliance.
-
Page 2: Table Of Contents
WARNING: Improper installation, adjustment, altera- tion, service or maintenance can cause injury or prop- erty damage. Refer to this manual for correct installation and operational procedures. For assistance or addi- tional information consult a qualified installer, service agency or the gas supplier. NOT FOR USE WITH SOLID FUEL CHECK LOCAL CODES PRIOR TO INSTALLATION This book is valuable. In addition to instructing you on how to install and maintain your appliance, it also contains infor- mation that will enable you to obtain replacement parts or optional accessory items when needed. -
Page 3: Safety Information
saFety InFormatIon WARNING: This product contains and/or generates chemicals known to the State of California to cause cancer or birth defects or other reproduc- tive harm. IMPORTANT: Read this owner’s manual carefully and completely before trying to assemble, op- erate or service this fireplace. Improper use of this fireplace can cause serious injury or death from burns, fire, explosions, electrical shock and carbon monoxide poisoning. -
Page 4: Unpacking
DESA. Unless you use DESA approved components tested for this appliance, YOU MAY CAUSE A FIRE HAZARD! The DESA warranty will be voided by and DESA dis- claims any responsibility for the following actions : A) Modification of the appliance or any of the components. -
Page 5: Selecting Location
IntroduCtIon Continued WARNING: Installation of this appliance should be done by a qualified service person well trained in the installation of such appliances. You will also need a building permit from your local Building and Safety Commissioner before installing this appliance; otherwise your insurance co. may not cover this appliance. NOTICE: This appliance is not intended to be used as a primary source of heat. -
Page 6: Product Specifications
ProduCt sPeCIFICatIons Max. Input Rating: Manifold Pressure: Minimum Supply Pressure: Maximum Supply Pressure: Orifice Size: Max. Input Rating: Manifold Pressure: Minimum Supply Pressure: Maximum Supply Pressure: Orifice Size: For Use With 6"Ø Type B-1 Vent Pipe Only Stand Off Collar 7"... -
Page 7: Pre-Installation Preparation
(229mm) 6" (152mm) 3" (76mm) " (38mm) Max. M36E(B,H), M42E(B,H), M36EP(B,H) M42EP(B,H) VM36E(B,H), VM42E(B,H), VM36EP(B,H) VM42EP(B,H) 14" (356 mm) 15" (381 mm) 8" (03 mm) 9" (9 mm) (Cross Section) TOP VIEW Outer Surround SAFE ZONE 3" (76 mm) Max. - Page 8 VM36E(B,H), VM36EP(B,H) (6.3 mm) (1876.4 mm) (136 mm) (438. mm) Figure 8 - Corner Installation Guidelines www.desatech.com M42E(B,H), M42EP(B,H) VM42E(B,H), VM42EP(B,H) " (111 mm) " (587 mm) " (16 mm) in Wall M42E(B,H), M42EP(B,H) VM42E(B,H), VM42EP(B,H) " " (700.1 mm) "...
-
Page 9: Venting Installation
Pre-InstallatIon PreParatIon Continued INSTALLING TRANSITION PIPE AND STARTER COLLAR The transition pipe and starter collar shown in Figure 9 are supplied with the fireplace, unattached and ready for installation. Remove the starter collar and set aside. Slide the transition pipe over the vent collar and attach with a minimum of three screws. - Page 10 VentInG InstallatIon Listed Vent Cap Maintain Listed Clearance 12' Min. Position Firestop Maintain Listed Clearance EXAMPLE 1 Figure 10 - Typical B-Vent Configuration The flue connection must be made using listed B-type connectors and the existing system must be code inspected for damage and proper installation. It is not recommended that this appliance be com- mon vented with an existing gas burning appliance.
-
Page 11: Installation
VentInG InstallatIon Continued CHECKING FOR PROPER VENTING After completing and checking the electrical, gas and vent connections, follow the lighting instructions and allow the main burner to run for approximately 5 minutes. Hold a lighted match or cigarette near the top edge of the fireplace opening and play it along the entire length of the opening (see Figure 12). - Page 12 Figure 17. CAUTION: Do not kink flex- ible gas line. DESA recommends that a black iron gas line be routed from the gas source, through a sediment trap (shown in Figure 18) and into the appliance. Once connected through the appliance, a flexible gas line may be used for ease of installation to gas control valve (see Figure 19, page 13).
- Page 13 InstallatIon Continued CAUTION: Compounds used on threaded joints of gas piping shall be resistant to the action of Liquefied Petroleum (LP or propane) and should be applied lightly to ensure excess sealant does not enter the gas line. WARNING: All gas piping and connections must be tested for leaks after the installation is completed. After ensuring that the gas valve is on, apply a commercial leak detection solution to all con- nections and joints. If bubbles appear, leaks can be detected and corrected.
- Page 14 InstallatIon Continued Grate 0.5" 0.5" Burner Pan Figure 22 - Pan and Ember Material Clearances LOG PLACEMENT FOR M36E, M36EP, VME36 AND VM36EP MODELS 1. Place small front right log (log 1) on right front of grate as shown in Figure 23. 2.
- Page 15 Log 1 Log 5 Log B Figure 29 - Installing Logs 5 and 6 Log 4 Log 1 Figure 30 - Logs Installed for M42E, M42EP, VM42E and VM42EP Models www.desatech.com Log 6 Log 1 Notch Log B...
- Page 16 InstallatIon Continued COMBUSTION AIR KIT MODEL AK4 (OPTIONAL) The outside air kit may be installed on the left side of the fireplace only. The vent can be installed through any outside wall a minimum of three feet below fireplace termination cap. The handle to operate the damper door for the outside air inlet will be located inside the left “screen pocket”...
- Page 17 InstallatIon Continued 6. Repeat the process for the opposite door assembly. 7. To adjust the doors, slide them partially open. Using a screwdriver, loosen the hold-down screws in the spring clip (see Figure 34) and pivot plate. 8. Close both doors until evenly joined at the middle and note the gap at the outer edges of the face.
-
Page 18: Operating Fireplace
oPeratInG FIrePlaCe FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not fol- low these instructions exactly, a fire or explosion may result causing property damage, per- sonal injury or loss of life. A. This appliance has a pilot which must be lighted by hand. When lighting the pilot, follow these instructions exactly. -
Page 19: Inspecting Burners
oPeratInG FIrePlaCe Continued TO TURN OFF GAS TO APPLIANCE 1. Turn off the wall switch. 2. Turn off all electric power to the appliance if service is to be performed. 3. Fully open glass doors if installed. 4. Remove front hearth brick and control access panel. -
Page 20: Cleaning And Maintenance
If so, contact DESA’s Technical Service Department at 1-866-672-6040. When calling please have your model and serial numbers of your heater ready. You can also visit DESA’s Technical Services web site at www.desatech.com. rePlaCement Parts Note: Use only original replacement parts. This will protect your warranty coverage for parts replaced under warranty. -
Page 21: Wiring Diagram
INCOMING MAIN GAS SUPPLY VENT SAFETY SHUTOFF SWITCH MANUAL DAMPER SWITCH GAS LINE BURNER 108796-01L WIrInG dIaGram Pilot Burner Pilot Gas Line 24V AC STEP DOWN TRANSFORMER 120V AC www.desatech.com WALL SWITCH (SUPPLIED) BLACK INCOMING 120V AC WHITE (FUSE BOX GREEN OR BREAKER) ELECTRICAL RATING:... -
Page 22: Troubleshooting
Note: Before troubleshooting the system, make sure the gas shutoff valve is ON. The two most common causes of a malfunctioning gas appliance are: 1. Loose wiring connections 2. Construction debris clogging the pilot and/or gas control valve filter OBSERVED PROBLEM Ignitor will not spark or pilot will not light Pilot will not stay lit... - Page 23 WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions. • If you cannot reach your gas supplier, call the fire department. IMPORTANT: Operating fireplace where impurities in air exist may create odors.
-
Page 24: Illustrated Parts Breakdown
Illustrated Parts breakdoWn MODELS M36E(B,H), M36EP(B,H), M42E(B,H), M42EP(B,H), VM36E(B,H), VM36EP(B,H), VM42E(B,H) AND VM42EP(B,H) 35 34 www.desatech.com 59/60 108796-01L... -
Page 25: Parts List
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed under Replacement Parts on page 20 of this manual. M36E(P)(B,H) M42E(P)(B,H) VM36E(P)(B,H) VM42E(P)(B,H) DESCRIPTION QTY 14153 14153 10664-01 10664-01 Air Rod 106643-01 106643-01 Damper Rod 106651-01 107805-01 Panel Closure 106657-0 107811-0 Air Separator 11408... - Page 26 This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed under Replacement Parts on page 20 of this manual. M36(B,H) M42(B,H) VM36(B,H) VM42(B,H) 106658-0 10781-0 Left Refractory, Std. Brick (M36EB/ME4B) 108164-0 108169-0 Left Refractory, Herringbone (M36EH/M4EH) 106658-01 10781-01 Left Refractory, Std.
- Page 27 Illustrated Parts breakdoWn LOGSETS FOR MODELS M36(B,H), M36P(B,H), VM36(B,H) AND VM36P(B,H) PART NUMBER 107999-01 10874-01 901098-01 10870-01 10871-01 1087-01 10873-01 108796-01L DESCRIPTION Log Set Right Front 9" Split Log Rear Log Top Right Log - 11 Top Right Log - 16" Top Left Log - 13 Top Left Log - 11"...
- Page 28 Illustrated Parts breakdoWn LOGSETS FOR MODELS M42(B,H), M42P(B,H), VM42(B,H) AND VM42P(B,H) PART NUMBER 107999-0 901098-0 10873-01 108839-01 1087-01 108838-01 10871-01 10870-01 DESCRIPTION Log Set Rear Log Left Front Log - 11" Right Front Log - 15 Top Left Log - 13 " Y-Log Inside Top Left Log - 15 Inside Top Right Log - 16"...
-
Page 29: Accessories
NOTICE: All accessories may not be available for all fireplace models. Purchase these firebox accessories from your local dealer. If they can not supply these accessories, call DESA’s Sales Department at 1-866-672-6040 for information. You can also write -to the address listed on the back page of this manual. AIR KIT - AK4 Optional kit helps offset the negative pressure of- ten existing in today's tightly constructed homes. - Page 30 _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ notes www.desatech.com 108796-01L...
- Page 31 _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ 108796-01L notes www.desatech.com...
-
Page 32: Warranty Information
We make no other warranty, expressed or implied. DESA warrants this product to be free from defects in materials and components for four (4) years from the date of first purchase, provided that the product has been properly installed, operated and maintained in accordance with all applicable instructions.
