ASSEMBLY AND INSTALLATION INSTRUCTIONS

Important: Read entire instruction sheet before
assembling or installing mantel kit.
These mantels are only approved for use with any
DESA Heating, LLC 36" electric and gas fireplace sys-
tems. Do not use mantel with any other product.
This mantel kit contains the following:
• Mantel pieces - unassembled and numbered as follows:
#1 Base
#2 Right Side Assembly
#3 Left Side Assembly
#4 Header
#5 Top
• Hardware Package
18 - 1 / " Wood Screws
1
4
* Extra hardware may be included
Tools required:
• Power Screwdriver with #2 Phillips Bit
If any wood pieces are missing or damaged, contact the
dealer where you purchased this mantel for replacement. If
hardware is missing or damaged, contact DESA Heating, LLC
at 1-866-672-6040 for referral information. You can also visit
DESA Heating, LLC's web site at www.desatech.com.
W36TU and W36TO
Mantel and Base
114325-01
www.desatech.com
WARNING: Follow guidelines of paint or finish
manufacturer. Use care when finishing or painting an
unfinished mantel (W36TU only). Do not finish or paint
mantel pieces near running heater or open flame. These
vapors are highly flammable.
IMPORTANT: If you are staining an unfinished mantel (W36TU
only), remove any sawdust, dirt or oils. This will prevent blem-
ishes from appearing under the stain. Stain mantel before
assembling according to manufacturer's instructions. Apply
sanding sealer.
IMPORTANT: If you are painting an unfinished mantel (W36TU
only), assemble mantel before painting. Follow directions
listed on paint for wood products. Apply base coat and top
coat following directions listed on product.
Note: Gather all mantel pieces together before assembling
mantel.
WARNING: Only use 1
mantel. Damage to mantel will result if other screws
are used for this purpose.
/ " screws to assemble
1
4
