Introduction

Thank you for purchasing the Revolution 7.1 by M-Audio. The Revolution 7.1 is an
audio upgrade for any PC or Macintosh computer,* bringing the ultimate in
surround performance to your computer system. The Revolution 7.1 brings you up
to 24-bit, 192kHz audio and the highest-quality stereo, virtual surround, and multi-
channel surround sound available today.
Please take the time to read this User Guide. It will tell you how to install the
Revolution 7.1 on your particular computer and instruct you on how to get the most
from your Revolution 7.1 audio interface.
* Must meet minimum system requirements

Revolution 7.1 Features

Audiophile quality 24-bit/192kHz audio playback, 24-bit/96kHz recording
Analog connectors for powered speakers or stereo receiver
Supports Dolby Digital 5.1 (AC3)®, DTS®, and other encoded multi-
channel formats
Advanced Circle Surround II® technology creates true multi-channel surround
sound from your stereo, MP3s, CDs, and other audio sources
SRS TruSurround XT® technology delivers virtual surround sound over stereo
speakers, deep bass enhancement, and Dialog enhancement
S/PDIF Coaxial (RCA Jack) Output
Revolution 7.1 supports the following digital output formats: 24-bit Linear PCM;
16-bit Linear PCM; 16-bit AC-3, Dolby Pro Logic, or DTS over coaxial connector
Revolution 7.1 supports the following sampling frequencies (Hz): 32000,
44100, 48000, 88200, 96000, 176400, 192000; with MME drivers all rates up
to 192kHz using internal sample rate conversion with Windows XP SP1
Pro Audio Performance: Dynamic Range: 106 dB (a-weighted); Signal-to-
Noise Ratio: 107 dB (a-weighted); THD+N: <0 .00235% (-92.6 db)
One-year warranty
