1
Version DA 041100
Table of Contents
FCC Class B and CE Compliance .................................................... 2
Overview ............................................................................................. 3
Features ................................................................................................ 4
Panels - Fig. 1....................................................................................... 4
Panel Description................................................................................ 5
Front Panel ................................................................................... 5
Rear Panel ..................................................................................... 5
Installation and Typical Setup ......................................................... 6
Typical Setup - Fig. 2 ......................................................................... 7
Operation ............................................................................................ 8
Internal Jumper Settings - Fig. 3 ...................................................... 9
Troubleshooting ............................................................................... 10
Specifications .................................................................................... 11
Lifetime Limited Warranty.............................................................. 12
Flying Calf D/A
™
MANUAL
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for M-Audio midiman Flying Calf D/A
Summary of Contents for M-Audio midiman Flying Calf D/A
-
Page 1: Table Of Contents
™ MANUAL Flying Calf D/A Version DA 041100 Table of Contents FCC Class B and CE Compliance ............ 2 Overview ..................... 3 Features ....................4 Panels - Fig. 1..................4 Panel Description................5 Front Panel ................... 5 Rear Panel ..................5 Installation and Typical Setup ............ -
Page 2: Fcc Class B And Ce Compliance
FCC Class B and CE Compliance WARNING: This equipment has been tested and found to comply with the lim- its for a CLASS B digital device, pursuant to Part 15 of the FCC Rules. These lim- its are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 3: Overview
Overview Thank you for choosing the Flying Calf Professional External Digital Audio Converter Box. This unit provides high-quality Digital-to-Analog (D/A) conversion and supports the popular S/PDIF digital audio format. The Flying Calf is a perfect companion for computer digital I/O cards (such as the Midiman DiO), DAT machines, or any other digital audio device that requires high-quality D/A conversion. -
Page 4: Features
Features • High-quality stereo D/A converter. • Compact desk-top size: 5.2” x 3.2” x 1.2”. • S/PDIF digital input on an RCA connector. • Unbalanced analog outputs on independent left and right 1/4” jacks. D/A Converter • 20-bit, stereo D/A, delta-sigma with 128x oversampling. •... -
Page 5: Panel Description
Panel Description Front Panel 1. Data Valid: This LED indicates valid incoming digital data at the S/PDIF Input. This LED lights whenever the Flying Calf has acquired and locked to that data. 2. Power LED: The Power LED lights whenever the power is properly applied to the Flying Calf. -
Page 6: Installation And Typical Setup
Installation and Typical Setup Your Flying Calf should contain this user manual, a "wall-wart" power adapter and the Flying Calf unit itself. Please save all packing materials in case you should ever need to ship the unit. Plug one end of the provided power adapter into the Flying Calf's power jack, and the other end into a wall socket or power strip. -
Page 7: Typical Setup - Fig. 2
Typical Setup - Fig. 2 SPEAKERS POWER S/PDIF DIGITAL AUDIO CARD (Inside PC) S/PDIF Audio Out Audio Out Right Left FL YING Calf D/A... -
Page 8: Operation
Operation The Flying Calf is compatible with 20-bit, 18-bit and even 16-bit S/PDIF data. The more bits per data word, the better the dynam- ic range of the output signal and better dynamic range equates to better audio quality. When a valid signal is present at the Flying Calf's S/PDIF In jack, the Calf automatically detects the S/PDIF sample rate and syn- chronizes to it. -
Page 9: Internal Jumper Settings - Fig. 3
Internal Jumper Settings - Fig. 3 Jumpers JP1 & JP2 for 2 V rms (standard) for 1 V rms (-6 dB option) -
Page 10: Troubleshooting
Troubleshooting Symptom: When power is applied, there are no LED's lit on the Flying Calf's front panel. Solution: Make sure the power supply is properly plugged into the unit and into a live wall source or power strip. Also, make sure the Calf's Power button is pushed in and latched. -
Page 11: Specifications
Specifications Physical Specifications: Size: Approximately 5.2” x 3.2” x 1.2”. Power Supply: 9 volt DC, center-pin positive, 300 mil- liamps or larger. D/A Converter: Full-Scale Output Level: 2 volts RMS, unbalanced, jumper- switchable to 1 volt RMS unbalanced. Frequency Response: 20 Hz to 22 kHz, +/-0.5 dB. -
Page 12: Lifetime Limited Warranty
Lifetime Limited Warranty MIDIMAN warrants that this product is free of defects in materials and work- manship under normal use so long as the product is owned by the original pur- chaser and that purchaser has registered his/her ownership of the product by sending in the completed warranty card.
