- Page 1 11/06/200 JARLTECH ISO 9001 Certified Lead with technology Win customers with service Magnetic Stripe Reader 1218 SERIES Version 1.0 OPERATION MANUAL...
-
Page 2: Table Of Contents
User’s Manual MSR 1218 series Table of Contents: Chapter 1 Introduction ..................3 Chapter 2 Appearance ..................4 Chapter 3 Installation ..................5 Appendix I – S pecification ................15 Troubleshooting....................17... -
Page 3: Chapter 1 Introduction
User’s Manual MSR 1218 series CHAPTER 1 Introduction This product is an advanced bi-directional and non-programmable magnetic stripe reader. It supports ISO Standard(7810,7811,7812, 7813 format card. It is designed for using with credit authorization terminals, point-of-sale erminals, portable terminals, personal computers and banking terminals. -
Page 4: Chapter 2 Appearance
User’s Manual MSR 1218 series Appearance CHAPTER 2... -
Page 5: Chapter 3 Installation
User’s Manual MSR 1218 series CHAPTER 3 Installation MSR KB series: The MD-6M side of KB cable, shall be connected to PC PS/2 Keyboard port. The MD-6F side of KB cable can be connected to normal PC keyboard, PC keyboard can work with... - Page 6 series User’s Manual MSR 1218 MSR RS232 series: The DB-9F side of RS232 cable connects to PC COM port (COM 1 or COM 2 or other COMs) , and power connects to USB .
- Page 7 User’s Manual MSR 1218 series MSR USB installation Step 1: Connect to the computer Plug the USB-connector into the USB port of your computer. Refer to Figure 2-1. !! !! !!! ! ! ! ! ! ! ! ! ! ! !
- Page 8 series User’s Manual MSR 1218 G j h v s f !3 G j h v s f !3 ..2 2 2 2 G j h v s f !3 G j h v s f !3 !!!!!!! ! ! ! ! MSR USB will have “Beep”...
- Page 9 User’s Manual MSR 1218 series Installation for WindowsXP 1. Insert CD-ROM and select "MSR USB Driver" folder. 2. Then select "USB for Win SERIES" folder.
- Page 10 User’s Manual MSR 1218 series 3. Select "PL-2303 Driver Install.exe". 4.When the setup screen appears then to select "Next" step.
- Page 11 User’s Manual MSR 1218 series 5. After the installation completes, please select " Finish" and restart the computer. 1218 USB Driver for Windows Specification.: 1. Support Microsoft Windows 95,98,ME,NT,2000,XP 2. Support Visual COM port. 3. Plug and Play. How to Install: 1.When you plug-in 1218 USB, Windows operating system will detect...
- Page 12 [root@JuiLinux root]# uname -a Linux JuiLinux.jarltech.com.tw 2.4.18-14 #1 Wed Sep 4 12:13:11 EDT 2002 i686 athlon i386 GNU/Linux 2. After the product installation, it determines the driver has written down correctly (Plug-in USB port to able to hear "Beep").
- Page 13 User’s Manual MSR 1218 series 3 . Obtain the data from USB0 . [root@JuiLinux root]# cat < /dev/ttyUSB0...
- Page 14 User’s Manual MSR 1218 series 1218 USB / Device and Driver block chart v1.0 1218 MSR Software: Micro controller Magnetic Head Open Visual COM port to read data With Decoder And data buffer board From 1218 (UART Interface) Or direct control 1218 by sending Command codes.
-
Page 15: Appendix I - S Pecification
User’s Manual MSR 1218 series Appendix I : Specifications 1218 Model Triple-tracks: Tracks 1 & 2 & 3 Decoding Capability 7.5 to 125 cm/sec Card Reading Speed Bi-directional ISO standard 7810,7811,7812,7813 Card Format Supports Magnetic Head Life 300,000 passes Audible beep for each... - Page 16 User’s Manual MSR 1218 series This equipment has been tested and found to comply with the limits for Class A digital device. Pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 17: Troubleshooting
User’s Manual MSR 1218 series Troubleshooting Q1. When 1218 USB plug-in the USB port, the operating system will require to install the driver? Ans: It needs to install the specialized driver of 1218 USB. After installation, it will produce a virtual COM port in the administrator. - Page 18 LED exchanges glimmering red and green, checks the mistake for 1218 CPU Ren's body. Please reexecute Ren turn on the computer. Otherwise, the keyboard device is no action. movement that body upgrade.(Please return jarltech and make tough body to upgrade fiemware.). B. Please use the software which can receive from the keyboard data for testing, such as Notepad, Microsoft Word…so on.
