Zotac Supreme H67ITX series User Manual

Intel series
Hide thumbs Also See for Supreme H67ITX series:
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading

Related Manuals for Zotac Supreme H67ITX series

Summary of Contents for Zotac Supreme H67ITX series

  • Page 2: Electronic Emission Notices

    Electronic Emission Notices WARNING! Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 3: Table Of Contents

    Intel H67-ITX series Motherboard Table of Contents Motherboard Specifications ---------------------------------------------------------------------------------4 Motherboard Layout--------------------------------------------------------------------------------------------6 Hardware Installation ------------------------------------------------------------------------------------------9 Safety Instructions-------------------------------------------------------------------------------------------9 Preparing the Motherboard -------------------------------------------------------------------------------10 Installing the CPU --------------------------------------------------------------------------------------10 Installing the CPU Fan --------------------------------------------------------------------------------11 Installing Memory Modules --------------------------------------------------------------------------11 Installing the Motherboard --------------------------------------------------------------------------------12 Installing the I/O Shield -------------------------------------------------------------------------------12 Securing the Motherboard into the Chassis -----------------------------------------------------12 Installing an mSATA SSD module (optional) ----------------------------------------------------13 Connecting Cables and Setting Switches -------------------------------------------------------------14...
  • Page 4 Table of Contents Security Menu ------------------------------------------------------------------------------------------------26 Administrator Password ------------------------------------------------------------------------------26 User Password ------------------------------------------------------------------------------------------26 Exit Menu ------------------------------------------------------------------------------------------------------27 Save Changes and Exit-------------------------------------------------------------------------------27 Discard Changes and Exit ---------------------------------------------------------------------------27 Save Changes and Reset ----------------------------------------------------------------------------27 Discard Changes and Reset ------------------------------------------------------------------------27 Save Changes ------------------------------------------------------------------------------------------27 Discard Changes ---------------------------------------------------------------------------------------28 Restore Defaults----------------------------------------------------------------------------------------28 Save as User Defaults --------------------------------------------------------------------------------28 Restore User Defaults --------------------------------------------------------------------------------28...

  • Page 5: Motherboard Specifications

    Intel H67-ITX series Motherboard Motherboard Specifications q Chipset v Intel ® H67 Chipset q Size v Mini ITX form factor of 6.7 X 6.7 inch q Microprocessor support v Supports LGA 1155 Socket for 2nd Generation Intel ® Core i3/i5/i7 and Pentium processors q Operating systems v Supports Windows XP 32bit/64bit, Windows Vista 32bit/64bit and Windows 7 32bit/64bit q System Memory...
  • Page 6 Motherboard Specifications v High speed wireless connection up to 150 Mbps q Audio v 8 channel High Definition Audio (including one optical SPDIF output port) v All DACs support 192k/96k/48k/44.1kHz sample rate v One SPDIF-out header on board q Onboard Graphics Features v Integrated Intel ®...

  • Page 7: Motherboard Layout

    Intel H67-ITX series Motherboard Motherboard Layout Figure 1 shows the top of motherboard, Figure 2 shows the bottom, and Figure 3 shows the back panel connectors. 16 17 115XLM REMOVE Chipset SPK1 M_PCIE1 FP_S1 PCIE_X4 Figure 1 Figure 1. Board Layout CPU Fan Connector-CPUFAN3 10.
  • Page 8 Rear panel Figure 2 Figure 2. Bottom Layout 19. Mini PCI Express Slot for mSATA SSD Figure 3. Backpanel connectors 1. LAN port LED indicators Speed LED Activity LED Speed LED Activity LED Status Description Status Descritption Speed: 10 Mbps No link Green Speed: 100 Mbps...
  • Page 9 Intel H67-ITX series Motherboard 2. USB 3.0 Ports 3. Clear CMOS Button 4. eSATA Port 5. USB 2.0 Ports 6. HDMI Port (Nvidia ® GT520) 7. DVI-I Port (Nvidia ® GT520) 8. Optical SPDIF Output 9. Port 2-Channel 4-Channel 6-Channel 8-Channel Blue Line-In...

  • Page 10: Hardware Installation

    Hardware Installation Hardware Installation This section will guide you through the installation of the motherboard. The topics covered in this section are: q Preparing the motherboard v Installing the CPU v Installing the CPU fan v Installing Memory DIMMs q Installing the motherboard v Installing the I/O Shield v Securing the Motherboard into the Chassis v Installing an mSATA SSD module (optional)

  • Page 11: Preparing The Motherboard

    Intel H67-ITX series Motherboard Preparing the Motherboard The motherboard shipped in the box does not contain a CPU or memory DIMM. You need to purchase them to complete this installation. Installing the CPU Be very careful when handling the CPU. Make sure not to bend or break any pins on the back. Hold the processor only by the edges and do not touch the bottom of the processor.

  • Page 12: Installing The Cpu Fan

    Hardware Installation Installing the CPU Fan There are many different fan types that can be used with this motherboard. Follow the instruction that came with your fan assembly. Be sure that the fan orientation is correct for your chassis type and your fan assembly.

  • Page 13: Installing The Motherboard

    Intel H67-ITX series Motherboard Installing the Motherboard The sequence of installing the motherboard into the chassis depends on the chassis you are using and if you are replacing an existing motherboard or working with an empty chassis. Deter- mine if it would be easier to make all the connections prior to this step or to secure the mother- board and then make all the connections.

  • Page 14: Installing An Msata Ssd Module (Optional)

    Hardware Installation Installing an mSATA SSD module (optional) The motherboard supports one mSATA SSD via mini PCIe slot of the bottom. Users please install the mSATA SSD module according to the following instructions. 1. Locate the Mini-PCIe slot of the bottom, and insert an mSATA SSD into the slot at a 45 degree angle.

  • Page 15: Connecting Cables And Setting Switches

    Intel H67-ITX series Motherboard Connecting Cables and Setting Switches This section takes you through all the connectors and switch settings necessary on the mother- board. This will include: q Power Connectors v 24-pin ATX Power Connector-PW1 v 4-pin ATX_12V Power Connector-PW2 q Internal Headers/Connectors v COM Header-CN4 (Optional) v Front Panel Header-FP1...

  • Page 16: 24-Pin Atx Power Connector-Pw1

    Hardware Installation 24-pin ATX Power Connector-PW1 PW1 is the main power supply connector. Make sure that the power supply cable and pins are properly aligned with the connector on the motherboard. Firmly plug the power supply cable into the connector and make sure it is secure. PW1-Pin Definition Signal Signal...

  • Page 17: Com Header-Cn4 (Optional)

    Intel H67-ITX series Motherboard COM Header-CN4 (Optional) CN4 - Pin Definition Signal Signal 115XLM REMOVE Front Panel Header-FP1 The front panel header on this motherboard is one connector used to connect the following four cables : FP1-Pin Definition Signal Signal HDD_LED+ PW_LED+ HDD_LED-...

  • Page 18: Usb Headers-Fp_U1/Fp_Usb3_1

    Hardware Installation USB Headers-FP_U1/FP_USB3_1 This motherboard contains two USB 2.0 and two USB 3.0 ports that are exposed on the rear panel of the chassis. The motherboard also contains one 10-pin internal USB 2.0 header and one 20-pin USB 3.0 connector onboard. Note: Secure the bracket to either the front or rear...

  • Page 19: Speaker Header-Spk1

    Intel H67-ITX series Motherboard Speaker Header-SPK1 SPK1-Pin Definition Assignment SPK- CPUFAN3 Control Sense +12V 115XLM Control Sense REMOVE +12V SYSFAN4 Control Sense +12V SYSFAN3 SPK1 SATA-Pin Definition Serial-ATA (SATA) Connectors (SATA1~4) Signal The Serial ATA connector is used to connect the Serial ATA device to the motherboard.

  • Page 20: Expansion Slots

    Hardware Installation Expansion Slots The motherboard contains three expansion slots, two Mini PCIe slots and one PCIe x4 slot. 115XLM REMOVE M_PCIE1 PCIE_X4 MINI_PCIE1 Mini PCI Express Slots-M_PCIE1/MINI_PCIE1 There are two Mini PCI Express slots. M_PCIE1 supports one half-sized WiFi card. MINI_PCIE1 supports one mSATA SSD.

  • Page 21: Configuring The Bios

    Intel H67-ITX series Motherboard Configuring the BIOS This section discusses how to change the system settings through the BIOS Setup menus. Detailed descriptions of the BIOS parameters are also provided. Enter BIOS Setup The BIOS is the communication bridge between hardware and software. Correctly setting the BIOS parameters is critical to maintain optimal system performance.

  • Page 22: Advanced Menu

    Configuring the BIOS Advanced Menu The Advanced menu items allow you to change the setting for the CPU and other system devices. Press <enter> to display the configuration options: X-Setting The X-Setting menu items show the settings of CPU, memory and so on. q CPU Configuration The items in this submenu show the CPU-related information that the BIOS automatically detects.

  • Page 23: Storage Configuration

    Intel H67-ITX series Motherboard Storage Configuration The items in this menu allow you to set or change the storage configurations. Press <enter>to display the configuration options: q SATA Mode Allows you to choose SATA mode, including IDE Mode, AHCI Mode and RAID Mode.

  • Page 24: Usb Configuration

    Configuring the BIOS USB Configuration The items in this menu allow you to change the USB-related features. Press <enter> To display the configuration options: q Legacy USB Support Allows you to enable or disable support for USB devices on legacy operating systems.

  • Page 25: Chipset Menu

    Intel H67-ITX series Motherboard Chipset Menu The chipset menu items allow you to change the advanced chipset settings. Press <enter> to display the sub-menu: Display Configuration The item allows you to configure graphics features. Press <enter> To display the configuration options: q OnBoard P.E.G Use this item to enable or disable onboard PCI Express Graphics.

  • Page 26: Boot Menu

    Configuring the BIOS Boot Menu The Boot menu items allow you to change the system boot options. Press <enter> to display the configuration options: Boot Settings Configuration The items allow you to configure Boot settings. Press <enter> To display the configuration options: q Setup Prompt Timeout Use this item to set number of seconds to wait for setup activation key.

  • Page 27: Security Menu

    Intel H67-ITX series Motherboard Security Menu The security menu items allow you to change the system security settings. Press <enter> to display the configuration options: Administrator Password Select this item to set Setup Administrator Password. User Password Select this item to set the user password. To set an Administrator/User Password: 1.

  • Page 28: Exit Menu

    Configuring the BIOS Exit Menu The exit menu items allow you to load the option or failsafe default values for the BIOS items, and save or discard your changes to the BIOS items. Press <enter> to display the sub-menu: Save Changes and Exit Select this item and press <Enter>...

  • Page 29: Discard Changes

    Intel H67-ITX series Motherboard Discard Changes This option allows you to discard the selections you have made and restore the previ- ously saved values. When the dialog box [Load Previous Values?] appears, select [Yes] to discard any change and load the previously saved values. Restore Defaults Use this item to restore/load default values for all the setup options.

  • Page 30: Installing Drivers And Software

    Installing Drivers And Software Installing Drivers and Software Note: It is important to remember that before installing the driver disk that is shipped in the kit, you need to load your operating system. The motherboard supports Windows XP 32 bit/64 bit, Windows Vista 32 bit/64 bit and Windows 7 32bit/64bit. The kit comes with a driver disk that contains utility drivers and additional software.
  • Page 31 Intel H67-ITX series Motherboard 2. Left-click Intel Chipset Driver, begin loading...
  • Page 32 Installing Drivers And Software 3. Left-click HDA sound driver, begin loading 4. Left-click Intel Graphics Driver, begin loading...
  • Page 33 Intel H67-ITX series Motherboard 5. Left-click Nvdia Graphics Driver, begin loading...
  • Page 34 Installing Drivers And Software 6. Left-click Ethernet PCI-E Driver, begin loading...
  • Page 35 Intel H67-ITX series Motherboard 7. Left-click VIA USB 3.0 Controller Driver, begin loading Note: USB 3.0 port would not work in POST, CMOS setup and DOS mode.
  • Page 36 Installing Drivers And Software...
  • Page 37 Intel H67-ITX series Motherboard 8. Left-click Intel Management Engine, begin loading...
  • Page 38 Installing Drivers And Software 9. Left-click Azurewave WIFI driver, begin loading...
  • Page 39 Intel H67-ITX series Motherboard 10. Left-click Bluetooth driver, begin loading.
  • Page 40 Installing Drivers And Software At last, you can enter Computer Management that provides information about the hardware devices on this motherboard to check if the driver installation is complete.

  • Page 41: Realtek Hd Audio Driver Setup

    Intel H67-ITX series Motherboard Realtek HD Audio Driver Setup Getting Started After Realtek HD Audio Driver being installed (insert the driver disk and follow the on-screen instructions), “Realtek HD Audio Manager” icon will show in System tray as below. Double click the icon and the control panel will appear: Sound Effect After clicking on the “Sound Effect”...

  • Page 42: Equalizer Selection

    Installing Drivers And Software Equalizer Selection The Equalizer section allows you to create your own preferred settings by utilizing this tool. In standard 10 bands of equalizer, ranging from 100Hz to 16KHz are available: Frequently Used Equalizer Setting Realtek recognizes the needs that you might have. By leveraging our long experience at audio field, Realtek HD Audio Sound Manager provides you certain optimized equalizer settings that are frequently used for your quick enjoyment.

  • Page 43: Mixer

    Intel H67-ITX series Motherboard Mixer Realtek HD Audio Sound Manager integrates Microsoft’s “Volume Control” functions into the Mixer page. This gives you the advantage to you to create your favorite sound effect in one single tool. Playback control Mute You may choose to mute single or multiple volume controls or to completely mute sound output. Tool √...

  • Page 44: Recording Control

    Installing Drivers And Software With this function, you will be able to have an audio chat with your friends via headphone (stream 1 from front panel) while still have music (stream 2 from back panel) playing. At any given period, you can have maximum 2 streams operating simultaneously. Recording control Mute You may choose to mute single or multiple volume controls or to completely mute sound input.

  • Page 45: Audio I

    Intel H67-ITX series Motherboard Audio I/O Realtek HD Audio Manager frees you from default speaker settings. Different from before, for each jack, they are not limited to perform certain functions. Instead, now each jack is able to be chosen to perform either output (i.e. playback) function or input (i.e. Recording) function, we call this “Retasking”.

  • Page 46: Speaker Configuration

    Installing Drivers And Software Speaker Configuration Step 1: Plug in the device in any available jack. Step 2: Dialogue “Connected device” will pop up for your selection. Please select the device you are trying to plug in. * If the device is being plugged into the correct jack, you will be able to find the icon beside the jack changed to the one that is same as your device.

  • Page 47: Connector Settings

    Intel H67-ITX series Motherboard Connector Settings Click to access connector settings √ Mute rear panel when front headphone plugged in Once this option is checked, when front headphone is plugged, the music that is playing from the back panel, will be stopped. Disable front panel jack detection (option) √...

  • Page 48: Speaker Calibration

    Installing Drivers And Software √ Output Sampling Rate 44.1KHz: This is recommended while playing CD 48KHz: This is recommended while playing DVD or Dolby 96KHz: This is recommended while playing DVD-Audio 192KHz: This is recommended while playing HD Audio √ Output Source Output digital audio source: The digital audio format (such as .wav, .mp3, .midi etc) will come out through S/PDIF-Out.

  • Page 49: Microphone

    Intel H67-ITX series Motherboard Microphone This page is designed to provide you better microphone/recording quality. Below picture indicates both “Noise Suppression” & “Acoustic Echo Cancellation” are both enabled. Noise Suppression If you feel that the background noise, especially the sound generated from the fan inside PC, is too loud? Try “Noise Suppression”, which allows you to cut off and suppress disturbing noise.

  • Page 50: 3D Audio Demo

    Installing Drivers And Software 3D Audio Demo The section “3D Audio Demo” grants you another possibility to enjoy your sound. The Audio Demo allows you to listen to sound in an extraordinary way. Information This section provides information about your current system audio device.

  • Page 51: Sata Raid User Manual

    Intel H67-ITX series Motherboard SATA RAID User Manual Setting up the BIOS Setting your computer, then press <Delete> to enter BIOS SETUP UTILITY. Use the arrow key to select Advanced menu. When enter the Advanced menu, select the Item “Storage Configuration”. Press <Enter>...

  • Page 52: Entering The Raid Bios Utility

    SATA RAID User Manual Enable the disks that you want to use as RAID disks. Press F10 to save the configuration and exit. The PC reboo Entering the RAID BIOS utility During POST, press <Ctrl-I> to enter the Intel(R) Rapid Storage Technology RAID BIOS menu.

  • Page 53: Deleting A Raid Set

    Intel H67-ITX series Motherboard Note: When more than two HDDs are installed in your computer, the Disks item will be selectable. Then users can select the HDD that you want to belong to the RAID set. Please be noticed that selecting a wrong disk will result in losing the original data of the HDD. Press <Enter>...
