Cooper Wheelock SP-LOC Specification

Description:
The SP4-LOC Remote Microphone and Local Operator Console is
designed for indoor use with the SafePath4 SP40/2 and the SP40S
panels for mass notification applications.
The SP4-LOC contains the SafePath4 SPRM Remote Microphone
module and eight black push on/push off buttons which provide
a contact closure used to activate the SP40/2 or SP40S digital
messages in the ON position. The buttons change color from black
in the OFF position to green in the ON position. A message name
plate holder is located above the pushbuttons.
An optional HVAC Emergency Shutoff red, mushroom type cutoff
pushbutton and labeling is available as a seperate kit.
The Remote Microphone module (SPRM) incorpoates a Push-
To-Talk (PTT) microphone and system status LED indicators. The
SPRM provides a microphone override for any tone generation,
digitak voice module prerecorded message, background music,
or telephone paging. It is equipped with a keyed lock that, when
activated, allows the use of the module. The SPRM is fully supervised
from the SP40/2 or the SP40S panel and contains front panel LEDs
for remote indications of System Normal, System Trouble, and
Alarm conditions. Voice frequency response shall be 275 Hz-6.5
kHz +/- 2.4 dB. Power requirements shall be 24VDC and will be
supplied by the SP40/2 or SP40S. Input current for standby mode
shall be 26mA and 38mA in the alarm mode. Shielded 6-wire cable
shall be used. Approvals for the system shall include; UL Standard
864, UL Standard 1711, FCC Part 15, and CSFM. The panel shall
be OSHA 1910.165 and ADA compliant.
The SP4-LOC is available in two models. The flush mount model
has a 1/2 inch skirt around the door section, while the surface
mount model door section is flush with the back box. Both models
use the same white 4 inch deep backbox with a single 1/2 inch/
3/4 inch double knockout on the back center, and top and bottom
of the backbox.
The flush mount door section has exterior dimensions of 15-1/2
inches wide and 16-1/4 inches high. The surface mount model
has dimensions of 14-1/2 inches wide, 15-1/2 inches high and
4 inches deep. Both models have a pull slam latch to open the
continuous hinged door. Both models are available in white.
The SP4-LOC can be installed up to 2,000 feet from the SP40/2
or SP40S panel using 14-18 AWG wiring. Shielded wire is only
required for the 1Vrms output from the SPRM.
SP4-LOC Remote Microphone and Local Operator Console
Features:
• All message wiring is pre-wired to a terminal block
• Internal terminal block accepts up to 16 AWG wiring for filed
wiring
• Built-in SPRM requires 24VDC, supplied by the SP40/2 or
SP40S
• SPRM Input current: Standby: 26mA Alarm: 38mA
• All output circuitry is Power Limited
• SP4 LOC is available in flush and surface models
• Backbox for both models are identical with knockout
mounting holes in the sides and back
• Backbox contains three (3) double knockouts for 1/2" or 3/4"
conduit fittings. Knockouts are located in the center top and
bottom and one in the center top back
• Optional HVAC Emergency Shutoff mushroom pushbutton kit
• Can be mounted up to 2,000 feet away from the SP40/2 or
SP40S
• Remote microphone usage disengages background music
and general paging
• Eight (8) push on/push off pushbuttons that provide a contact
closure in the ON position. Pushbuttons are balck in the OFF
position and green in the ON position.
