Cooper Wheelock RSS-24110W Installation Instructions

273 Branchport Ave.
Long Branch, N.J. 07740
(800) 631-2148
www.cooperwheelock.com
Use this product according to this instruction manual. Please keep this instruction manual for future reference.

GENERAL:

Series RSSA/RSSB/RSSG/RSSR Strobes can provide a non-synchronized strobe appliance when connected directly to a fire alarm control panel (FACP), or provide a
synchronized strobe appliance when used in conjunction with a Sync Module (SM), Dual Sync Module (DSM) or Wheelock power supplies with patented sync protocol.
Series RSS strobes with amber, blue, green and red lens are UL Listed under Standard 1638 (Visual Signaling Appliance) for Private Mode Emergency General Utility
Signaling. The RSS strobes are intended for ceiling mount or wall mount with the backboxes specified in these instructions (See Mounting Options). The RSS models
have an integrated strobe mounting plate (SMP) that can be mounted to a single-gang, double-gang, 4" backbox, 100mm European backbox or SHBB surface backbox.
The strobe uses a xenon flashtube with solid state circuitry enclosed in a polycarbonate lens to provide maximum visibility and reliability for effective visible signaling.
All inputs are polarized for compatibility with standard reverse polarity supervision of circuit wiring by an FACP.
WARNING: PLEASE READ THESE INSTRUCTIONS CAREFULLY.
INSTRUCTIONS, CAUTIONS AND WARNINGS COULD RESULT IN IMPROPER APPLICATION, INSTALLATION AND/OR OPERATION OF THESE
PRODUCTS IN AN EMERGENCY SITUATION, WHICH COULD RESULT IN PROPERTY DAMAGE AND SERIOUS INJURY OR DEATH TO YOU
AND/OR OTHERS.
WARNING: CANDELA SETTING WILL DETERMINE THE CURRENT DRAW OF THE PRODUCT.

SPECIFICATIONS:

Model
Code
RSS-24110W
RSS-24MCC
RSS-24MCCH
NOTES:
1. Candela is measured on axis. Models with MCC strobes have 4 field-selectable candela settings: 15, 30, 75, 95 cd. Models with MCCH strobes have 2 field-
selectable candela settings: 115 and 177 cd. MCC and MCCH candela settings are rated for clear lens - derate approximately 25% for amber, 55% for green,
70% for blue and 80% for red lens.
2. All strobes operate from 16 to 33 volts at 1 flash/second using filtered or full-wave-rectified DC voltage.
3. Strobes with Amber Lens meet the required light distribution patterns defined in UL 1971.
4. All models are for indoor use with a temperature range of +32°F to +120°F (0°C to +49°C) and maximum humidity of 85% RH. The effect of shipping and
storage temperatures shall not adversely affect the performance of the appliance when it is stored in the original cartons and is not subjected to misuse or
abuse.
MCC Max DC RMS
Current Draw
MCC Setting 15 30
16-33 VDC 0.065 0.105
WARNING: CHECK THE MINIMUM AND MAXIMUM OUTPUT OF THE POWER SUPPLY AND STANDBY BATTERY AND SUBTRACT THE
VOLTAGE DROP FROM THE CIRCUIT WIRING RESISTANCE TO DETERMINE THE APPPLIED VOLTAGE TO THE STROBES.
CAUTION: Strobes are not designed to be used on coded systems in which the applied voltage is cycled on and off.
WARNING: MAKE SURE THAT THE TOTAL AVERAGE/RMS CURRENT REQUIRED BY ALL APPLIANCES THAT ARE CONNECTED TO THE
SYSTEM'S PRIMARY AND SECONDARY POWER SOURCES, APPLIANCE CIRCUITS, SM AND DSM SYNC MODULES DO NOT EXCEED THE
POWER SOURCES' RATED CAPACITY OR THE CURRENT RATINGS OF ANY FUSES ON THE CIRCUITS TO WHICH THESE APPLIANCES ARE
WIRED. OVERLOADING POWER SOURCES OR EXCEEDING FUSE RATINGS COULD RESULT IN LOSS OF POWER AND FAILURE TO ALERT
OCCUPANTS DURING AN EMERGENCY, WHICH COULD RESULT IN PROPERTY DAMAGE AND SERIOUS INJURY OR DEATH TO YOU
AND/OR OTHERS.
When calculating the total currents: Use Table 1 and 2 to determine the highest value of Average/RMS current for an individual strobe (across the expected operating
voltage range of the strobe). Then multiply the value by the total number of strobes; be sure to add the currents for any other appliances, including audible signaling
appliances, powered by the same source and include any required safety factors.
Copyright 2007 Cooper Wheelock, Inc. All rights reserved.
Thank you for using our products.
INSTALLATION INSTRUCTIONS
SERIES RSSA/RSSB/RSSG/RSSR STROBE APPLIANCES
Table 1: Models and Ratings
Candela Voltage
110 24 VDC
15/30/75/95 24 VDC
115/177 24 VDC
Table 2: Strobe Current (AMPS)
MCC Max FWR
Current Draw
75 95 15 30
0.189 0.249 0.110 0.170
FAILURE TO COMPLY WITH ANY OF THE FOLLOWING
Maximum DC RMS
Current Draw
0.300
Table 2
Table 2
MCCH Max DC
RMS Current Draw
75 95 115
0.280 0.375 0.300
Maximum FWR Mounting
RMS Current Draw Options
0.455 A,B,C,D
Table 2 A,B,C,D
Table 2 A,B,C,D
MCCH Max FWR
Current Draw
177 115
0.420 0.455
177
0.645
P84517 L
Sheet 1 of 4
