Cooper Wheelock XB4 Specification

Description:
These high output (21 Joule) strobes have been designed
for use in potentially explosive atmospheres and harsh
environmental conditions. The marine grade alloy or stainless
steel enclosures are suitable for use offshore or onshore,
where light weight combined with corrosion resistance
and strength is required. Units can be painted to customer
specification and fitted with identification labels.
Architects and Engineers Specifications
Explosion-proof strobes shall be UL and cUL Listed for Class I, Division 1, Groups C&D, and Class I, Zone 1, AExd
IIB T4 hazardous locations and shall be listed under UL Standard 1638 for Indoor/Outdoor use. The strobes shall
be constructed of marine grade alloy with an epoxy paint finish and shall meet NEMA 4x, NEMA6, IP 66 and IP 67
environmental requirements over a temperature range of -67°F to 158°F (-55°C to 70°C) in hazardous and harsh
environments.
The strobe shall be rated to flash at 1 Hz with 21 joules per flash. Rated current draw shall not exceed 1400 mA at 24
vdc. The strobe shall be capable of direct surface mounting in any direction.
Note: Due to continuous development of our products, specifications and offerings are subject to change without notice in accord-
ance with Cooper Wheelock standard terms and conditions.
ATEX
Strobe, 21 Joules, Explosion Proof
Features*:
UL Listed for USA and Canada
★
– Hazardous locations:
Class I, Div 1, Groups C & D
Class I, Zone 1, AExd IIB T4
– Ordinary locations: Visual-Signal Device
ATEX approved
★
Certified temperature –67°F to +158°F (–55°C to
★
+70°C)
NEMA 4x & 6, IP67 and IP66
★
Various lens colors
★
Twin replaceable tubes
★
Tapered spigot flamepath.
★
4 wire monitored connection
★
Optional lens guard
★
24 VDC
★
110 & 240 VAC
★
Xenon
★
*Depending on version.
XB4
