Cooper Wheelock XB15 Specification

Description:
These listed strobes have been designed for use in potentially
explosive atmospheres and harsh environmental conditions.
The enclosures are suitable for use offshore or onshore, where
light weight combined with corrosion resistance is required.
The housings are manufactured completely from a U.V.
stable, glass reinforced polyester. Stainless steel screws and
mounting bracket are available ensuring a totally corrosion-
free product.
The model XB15 contains a polarization diode and four wire
lead connections for fire alarm applications.
Units can be painted to customer specification and supplied
with identification labels.
Architects and Engineers Specifications
Strobes for hazardous locations and harsh environments shall be UL and cUL Listed for Class I, Division 2, Groups
A,B,C&D, and Class I, Zones 1, Class II, Div 2, Groups F & G, AExd IIC T5/T6 applications and shall be listed under UL
Standard 1638 for Indoor/Outdoor use. They shall be constructed of lightweight, UV stable glass reinforced polyester,
shall be corrosion resistant, and shall meet NEMA 4x, NEMA 6, IP 66 & IP 67 environmental requirements over a
temperature range of -67°F to +158°F (-55°C to +70°C).
The strobes shall be rated to flash at 1 Hz with 15 joules per flash. Rated current draw shall not exceed 780 mA at 24 vdc.
The strobes shall be available for direct surface mounting or pipe mounting and shall be able to mount in any direction
Note: Due to continuous development of our products, specifications and offerings are subject to change without notice in accordance
with Cooper Wheelock standard terms and conditions.
ATEX
Strobe - 355 Candela, Hazardous Location
XB15
Pipe Mount
(with cast guard)
Features*:
UL listed for USA and Canada
★
– Hazardous locations:
Class I, Div. 2, Groups A, B, C & D.
Class I, Zone 1, AExd IIC T5/T6
Class II, Div. 2, Groups F & G
– Ordinary locations: Visual-Signal Device
ATEX approved
★
NEMA 4x & 6, IP66 & 67
★
Certified temperature –67°F to +158°F (–55°C to
★
+70°C)
520,000 peak candlepower
★
Pipe mount or direct mount enclosure
★
Corrosion-free GRP
★
Four wire monitored connection
★
Optional stainless steel backstrap (direct mount version
★
only)
Various lens colors
★
Optional relay
★
Optional cast or wire lens guard
★
Up to 3 x 3/4" NPT entries
★
Filament version available (100W max)
★
*Depends on version
XB15
XB15 Direct
Mount (with
wire guard)
