Cooper Wheelock XB16 Specification

Description:
These listed strobes have been designed for use in potentially
explosive atmospheres and harsh environmental conditions.
The enclosures are suitable for use offshore or onshore, where
light weight combined with corrosion resistance is required.
The housing is manufactured from a U.V. stable, glass
reinforced polyester, with the lens manufactured from a U.V.
stable polycarbonate. Stainless steel screws are used ensuring
a totally corrosion-free product.
The model XB16 contains supervisory diode and four wire
leads for fire alarm applications. This strobe is also available
UL 1971 (ADA) listed for hearing impaired applications.
Units can be painted to customer specification and supplied
with identification labels.
Architects and Engineers Specifications
Strobes for hazardous locations and harsh environments shall be UL and cUL listed for Class I, Division 2, Groups A,B,C&D
applications and shall be listed under UL Standard 1638 for Indoor/Outdoor use. The strobes shall be available with UL
1971 Listing (Standard for Safety Signaling Devices for Hearing Impaired). They shall be constructed of lightweight,
UV stable glass reinforced polyester, shall be corrosion resistant, and shall meet NEMA 4x, NEMA 6, IP 66 and IP 67
environmental requirements over a temperature range of -67°F to 158°F (-55°C to 70°C).
The strobes shall be rated to flash at 1 Hz with 285 candela per flash. Rated current draw shall not exceed 890 mA at 24
vdc. The strobes shall be pipe mounted and shall be capable of mounting in any direction.
Note: Due to continuous development of our products, specifications and offerings are subject to change without notice in accordance
with Cooper Wheelock standard terms and conditions.
Strobe - 285 Candela, Hazardous Location
Features*:
UL listed for USA and Canada
★
– Hazardous locations for USA and Canada
Class I, Div. 2, Groups A, B, C & D
Class II, Div. 2, Groups F & G
UL 1971 compliant version available†
– Ordinary locations: Visual Signal Device
– 'T' Rating model dependent. Contact sales office for information
NEMA 4x & 6, IP66 & 67
★
Certified temperature –67°F to +158°F (–55°C to +70°C)
★
Pipe mount with ¾" NPT entry
★
Corrosion-free GRP enclosure
★
285 candela
★
Polycarbonate lens, various colors available†
★
4 wire diode monitored board
★
Optional relay initiate
★
Optional lens guard
★
*Depends on version
†UL 1971 version available with clear lens only.
XB16
