Key Operator Tools

These settings allow you to set up functions you frequently use as well as store
important information, such as your fax machine's identification. In addition,
you can also customize the default settings of each function to suit your require-
ments. The Key Operator Tools settings are split into the following three catego-
ries:
System Settings
Use to store your own name and fax number, the type of line your machine is
connected to, Polling ID and other IDs, Internet Fax Settings (option required)
etc.
Also use to adjust the sounds that the machine makes, change the date and
time, and check on how many pages the machine as sent or received.
Initial Set Up
P.259
Use to set up Collate, Authorized Reception, Specified Tray, Memory Lock,
TX/RX File In HD, Specified Senders, Backup File Transmission, Program
Scan Area etc.
Box Settings
P.289
With these settings you can register, edit and delete Personal Boxes, Informa-
tion Boxes, and Transfer Boxes.
Note
For the order in which the Key Operator Tools settings are displayed,
seeP.322 "Function List".
For detailed information on the above functions, refer to the page reference
given.
Navigating Menus
• To access the Key Operator Tools, enter the code for "Kep Op. Tools"
from the User Tools main menu, then press the {#} key within 3 sec-
onds.
• Press [ Prev.] or [Next ] to switch between screens.
• Press [PrevMenu] to move to the previous menu.
• When you have finished, press [OK]. If you do not press [OK], any chang-
es to the Key Operator Tools settings you have made are not applied.
• Press [Cancel] to cancel the current setting and return to the previous
menu.
9. Key Operator Tools
P.230
229
