Summary of Contents for Teledyne 329R
- Page 1 ODEL 329R XYGEN ETECTOR NSTRUCTION ANUAL P/N M57726.02 8/24/94 TELEDYNE ANALYTICAL INSTRUMENTS...
- Page 2 This warranty does not cover defects caused by wear, accident, misuse, neglect or repairs other than those performed by Teledyne or an authorized service center. We assume no liability for direct or indirect damages of any kind and the purchaser by the acceptance of the equipment will assume all liability for any damage which may result from its use or misuse.
-
Page 3: Table Of Contents
Calibration ....................7 3.0 Maintenance Replacing the Fuse..................9 Replacing the Sensor ..................10 E-2 Cell Warranty Conditions ..............11 Appendix Specifications....................13 Spare Parts List ..................... 14 Drawing List ....................15 Material Safety Data Sheet ................16 TELEDYNE ANALYTICAL INSTRUMENTS... - Page 4 TELEDYNE ANALYTICAL INSTRUMENTS...
-
Page 5: Introduction
Modular and compact design provide outstanding performance and reliable on-line monitoring and make the 329R virtually maintenance-free. A special range on the 329R enables you to calibrate in ambient air. The Micro-Fuel Cell produces an output that corresponds linearly to the oxygen concentration;... -
Page 6: Micro-Fuel Cell
Custom voltage outputs, either grounded or isolated, are available as options. 6. Analog Current Output. The Model 329R has a 4–20 mA current output suitable for connection to external devices that use a 4–20 mA input. A 0–20 mA current output, either grounded or isolated, is available as an option. -
Page 7: Installation & Operation
The unit is designed to be panel-mounted in a general purpose area, away from moisture and the elements. The unit should be installed at viewing level in a sheltered area. Refer to the Outline diagram (dwg. C-57490) for the physical dimen- sions of the analyzer. TELEDYNE ANALYTICAL INSTRUMENTS... -
Page 8: Analysis Unit Connection
2 SCFH (atmospheric pressure) is nominal. AC Power (International Ranges) A 6-foot power cord is supplied with the Model 329R. Plug the female end of the power cord into the receptacle in the upper left-hand corner of the rear panel. The unit is now ready to be plugged into an AC power source (85-264 VAC, 47-440 Hz). -
Page 9: Alarm Terminal Connection
4. Attach the red lead of the new cell to terminal #1 and the black lead to terminal #2. 5. Replace the cell on the cell holder by pushing and twisting until it strikes bottom. TELEDYNE ANALYTICAL INSTRUMENTS... -
Page 10: Setting Alarms
5. Remember, the System/Cell Failure alarm is factory set at 2% of full scale; should this alarm trigger, the LED to the left of the front panel display will blink. TELEDYNE ANALYTICAL INSTRUMENTS... -
Page 11: Calibration
329R Installation & Operation 2.0 TELEDYNE ANALYTICAL INSTRUMENTS... - Page 12 2.0 Installation & Operation 329R TELEDYNE ANALYTICAL INSTRUMENTS...
-
Page 13: Maintenance
4. Remove the bad fuse and replace it with a 5X20 mm 1A fast acting fuse (P/N F1189) for AC units or 1/2 A fast acting fuse (P/N F51) for DC units. Figure 5-1: Replacing the fuse (AC power). TELEDYNE ANALYTICAL INSTRUMENTS... -
Page 14: Replacing The Sensor
(75°F nominal), and in such a way to eliminate any possibility of damage. Under no circumstance should you disturb the integrity of the cell package until the cell is to be used. If the cell package TELEDYNE ANALYTICAL INSTRUMENTS... -
Page 15: Cell Warranty Conditions
Warranty Conditions The Class E-2 cell used in the 329R is warranted for twenty-four (24) months of service from the date of shipment. Customers having warranty claims must return the cell in question to the factory for evaluation. If it is determined that failure is due to faulty material or workmanship, the cell will be replaced free of charge. - Page 16 3.0 Maintenance 329R TELEDYNE ANALYTICAL INSTRUMENTS...
-
Page 17: Appendix
±5% of full scale throughout operating temperature range. Response: 90% of full scale in 20 seconds. Operating Temp. Range: 32 °F to 122 °F (0 °C to 50 °C) Power: 85-264 VAC, 47-440 Hz or 10-36 VDC. Enclosure: General purpose, panel mount TELEDYNE ANALYTICAL INSTRUMENTS... -
Page 18: Spare Parts List
IMPORTANT: Orders for replacement parts should include the part num- ber and the model and serial number of the system for which the parts are intended. Send orders to: TELEDYNE ANALYTICAL INSTRUMENTS 16830 Chestnut Street City of Industry, CA 91749-1580 Telephone: (818) 961-9221... -
Page 19: Drawing List
C-57305 Power supply PCB schematic diagram C-57307 Power supply PCB assembly diagram B-58123 Analysis unit (probe) outline Note: 329R analyzers with 25% and 100% range modifications incorporate the following changes: 100% range modified circuit changes: JP2 - connects pins 1 and 2 R52 is 12.5K... -
Page 20: Material Safety Data Sheet
Product Name: Micro-Fuel Cells Mini-Micro-Fuel Cells, all classes Super Cells, all classes except T–5F Electrochemical Oxygen Sensors, all classes. Manufacturer: Teledyne Analytical Instruments Address: 16830 Chestnut Street, City of Industry, CA 91749 Phone: (818) 961-9221 Date Prepared or Last Revised: 08/08/91... - Page 21 NTP Annual Report on Carcinogens: Not listed LARC Monographs: Not listed OSHA: Not listed Other health hazards: Lead is listed as a chemical known to the State of California to cause birth defects or other reproductive harm. TELEDYNE ANALYTICAL INSTRUMENTS...
- Page 22 The information is believed to be correct but does not purport to be all inclusive and shall be used only as a guide. Teledyne Analytical Instruments shall not be held liable for any damage resulting from handling or from contact with the above product.
