Page 1: Service Manual
PCG-GRS175 SERVICE MANUAL For American Area Canadian Model Ver 1-2002K Revision History S400 Lineup : PCG-GRS175 • Design and specifications are subject to change without notice. NOTEBOOK COMPUTER 9-876-020-01... - Page 2 Caution Markings for Lithium/Ion Battery - The following or similar texts shall be provided on battery pack of equipment or in both the Sony, VAIO and CLIE are trademarks or registered trademarks of operating and the service instructions. Sony. Microsoft, Windows, Windows Media, Outlook, Bookshelf and other Microsoft products are trademarks or registered trademarks CAUTION: Danger of explosion if battery is incorrectly replaced.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Section Title Page CHAPTER 1. BLOCK DIAGRAM ....... 1-1 (to 1-2) CHAPTER 2. FRAME HARNESS DIAGRAM ..2-1 (to 2-2) CHAPTER 3. EXPLODED VIEWS AND PARTS LIST ..........3-1 3-1. Main Section ..............3-2 3-2. LCD Section – Made by HI – .......... 3-5 3-3. -
Page 4: Chapter 1. Block Diagram
CHAPTER 1. BLOCK DIAGRAM Cable USB Righ t CONN USB Left CONN VGA DSUB- 15 USB Rear CONN i.LINK IO Cont rol Hub ICH3 -m PC Card FW82801CAM Connector 2 Slot Bus #2 Dev #5 RJ11 DB-15 CONN CONN PHONE Speaker L&R Confidential... -
Page 5: Chapter 2. Frame Harness Diagram
CHAPTER 2. FRAME HARNESS DIAGRAM EXTERNAL MICROPHONE HEADPHONE PHONE USB USB NETWORK PRINTER DC-IN AV OUT MONITOR Rear Panel PCGA-PRGR2 Port Replicator HARNESS (2P) CN5001 CN1801 CN3501 INVERTER J9331 CN9301 CN1501 IEEE 1394 i.LINK CN2901 CN3101 MODEM CARD CN1112 LCD HARNESS MBX-75 Board CN2007 (Side-A) -
Page 6: Chapter 3. Exploded Views And Parts List
CHAPTER 3. EXPLODED VIEWS AND PARTS LIST NOTE: • Items marked “ * ” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • The mechanical parts with no reference number in the exploded views are not supplied. -
Page 7: Main Section
3-1. Main Section Ref.No. Part No. Description Ref.No. Part No. Description 4-667-050-01 ESCUSHION TP X-4625-236-1 HOUSING BOTTOM ASSY 1-796-166-21 PAD, TOUCH 4-654-379-12 [CH]...COVER (PORT) X-4625-237-1 HOUSING (PALM REST) ASSY 4-668-288-01 CUSHION PALM 4-667-053-01 ESCUSHION JOG 1-756-038-11 BATTERY, NICKEL HYDROGEN 4-667-062-01 PLATE GND 4-642-711-11 [CH]...SHEET (BATTERY), ADHESIVE... - Page 8 Supplied with 3 73(*1) 73(*1) (Refer to page 3-6.) Confidential PCG-GRS175 (AM)
-
Page 9: Lcd Section - Made By Hi
3-2. LCD Section – Made by HI – Ref.No. Part No. Description Ref.No. Part No. Description 4-666-090-01 COVER SCREW LOWER ACCESSORIES X-4625-183-3 HOUSING (BZEL15) ASSY ************ 4-667-073-01 COVER HINGE 0801 4-666-091-01 COVER SCREW UPPER 1-477-205-42 $ ADAPTOR, AC 1-756-269-11 $ # BATTERY PACK, LITHIUM ION 4-666-340-01 LATCH HONTAI 0803... -
Page 10: Connector Section (Ch Type Only)
3-3. Connector Section (CH Type only) Ref.No. Fig. Part No. Description 1-817-023-11 [CH]...CONNECTOR, USB USB connector 1-779-745-21 [CH]...JACK, DC DC IN connector X-4625-501-1 [CH]...BRACKET IO ASSY I/O Bracket ∗ Among the parts that are used on the boards of this model, only the connectors that are show in the list can be replaced. -
Page 11: Chapter 4. Others
CHAPTER 4. OTHERS 4-1. Replacing the CPU 1. Removing the CPU 1 Insert a flat-blade screwdriver into the notch as shown in the illustration and rotate it so that the protrusion comes to the lock release position. 2 Pull the CPU gently upward to lift it out of the CPU socket. Lock position CPU socket Lock release position... - Page 12 PCG-GRS170 PCG-GRS175 9-876-020-01 : Additional Models This manual and the constituent data may not be replicated, copied nor reprinted in whole or in part without prior written authorization of Sony Corporation. English 2002K1600-1 9-876-020-01 Sony Corporation © 2002 Sony Corporation —...
- Page 13 Revision History Suffix Ver. Date Contents QM No. First Ver. 1 2002.11.18 Edition < Remarks > [Confidential] PCG-GRS175 (AM)
