EMERGENCY LOCATOR TRANSMITTER
Abbreviated Component Maintenance Manual
This manual includes data for the equipment that follows:
Component
Emergency Locator Transmitter
B406-4
Part No.
453-5004
25-62-03
Model No.
B406-4
Wulfsberg Electronics Division
6400 Wilkinson Rd., Prescott, AZ 86301
Cage Code: 1B7G3
570-5004 Rev. D
Initial Issue DEC 02/1999
Page 1 of 86
APR 06/10
