  • Page 1 User’s Manual www.nec-mitsubishi.com...

  • Page 2: Table Of Contents

    Index Warning, Caution ........................... English-1 Declaration ............................. English-1 Canadian Department of Communications Compliance Statement ..........English-2 Declaration of Conformity ......................English-2 Contents ............................English-3 Quick Start ............................. English-4 Controls ............................English-7 Recommended use ........................English-10 Specifications ..........................English-12 Features ............................English-13 Troubleshooting ..........................

  • Page 3: Warning, Caution

    Therefore, it should be read carefully in order to avoid any problems. Caution: When operating the DiamondPoint UX21LCD with a 220-240V AC power source in Europe, use the power cord provided with the monitor. In the UK, a BS approved power cord with a moulded plug has a Black (five Amps) fuse installed for use with this equipment.

  • Page 4: Canadian Department Of Communications Compliance Statement

    C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety Regulations according to CAN/CSA C22.2 No. 60950. FCC Information Use the attached specified cables with the DiamondPoint UX21LCD (L213E9) colour monitor so as not to interfere with radio and television reception.

  • Page 5: Contents

    Contents Your new Mitsubishi LCD monitor box* should contain the following: • DiamondPoint UX21LCD monitor with tilt/swivel/pivot/height adjust stand • Power Cord • Video Signal Cable (15-pin mini D-SUB male to DVI-A) • Video Signal Cable (DVI-D to DVI-D cable) •...

  • Page 6: English

    Quick Start To attach the LCD monitor to your system, follow these instructions: 1. Turn off the power to your computer. 2. For the PC or MAC with DVI digital output: Connect the DVI signal cable to the connector of the display card in your system (Figure A.1).

  • Page 7: Raise And Lower Monitor Screen

    INPUT1 INPUT1 INPUT2 INPUT2 Figure C.2 Figure C.1 NEC-Mitsubishi optional product attachment. Vacation Do not use this connector unless specified. Switch Power Button Figure D.1 Raise and Lower Monitor Screen The monitor may be raised or lowered in either Portrait or Landscape mode.

  • Page 8: Remove Monitor Stand For Mounting

    Tilt Swivel Grasp top and bottom sides of the monitor screen with your Grasp both sides of the monitor screen with your hands hands and adjust the tilt as desired (Figure TS.1). and adjust the swivel as desired (Figure TS.2). Figure TS.1 Figure TS.2 NOTE:...

  • Page 9: Controls

    Controls OSM (On-Screen Manager) control buttons on the front of the monitor function as follows: To access OSM menu, press any of the control buttons (EXIT, , –, +). To change signal input, press the SELECT button. NOTE: OSM must be closed in order to change signal input. Menu EXIT Exits the OSM controls.

  • Page 10: Colour Control Systems

    FINE (Analog input only) Improves focus, clarity and image stability by increasing or decreasing this setting. If the “Auto Adjust function” and the “H.Size” function do not give you a satisfactory picture setting, a fine tuning can be performed using the “Fine” function. It improves focus, clarity and image stability by increasing or decreasing this setting.
  • Page 11 Note: Depending on the PC and Video card used, or when another Video signal cable is attached, this function may not operate. OFF TIMER: Monitor will automatically power-down when the end user has selected a pre-determined amount of time. Tools 2 LANGUAGE: OSM control menus are available in seven languages.

  • Page 12: Recommended Use

    NOTE: As with all personal display devices, NEC-Mitsubishi Electronics Display-Europe recommends using a moving screen saver at regular intervals whenever the screen is idle or turning off the monitor when not in use.
  • Page 13 CORRECT PLACEMENT AND ADJUSTMENT OF THE MONITOR CAN REDUCE EYE, SHOULDER AND NECK FATIGUE. CHECK THE FOLLOWING WHEN YOU POSITION THE MONITOR: • For optimum performance, allow 20 minutes for warm-up. • Adjust the monitor height so that the top of the screen is at or slightly below eye level. Your eyes should look slightly downward when viewing the middle of the screen.

  • Page 14: Specifications

    Specifications Monitor Specifications DiamondPoint UX21LCD Monitor Notes LCD Module Diagonal: 54 cm/21.3 inches Active matrix; thin film transistor (TFT) liquid Viewable Image Size: 54 cm/21.3 inches crystal display (LCD); 0.270 mm dot pitch; Native Resolution (Pixel Count): 1600 x 1200 250 cd/m white luminence;...

  • Page 15: Features

    Allows for the monitor to be mounted on a wall or an arm using any third party compliant device. NaViSet: Is a ground-breaking software family, developed by NEC-Mitsubishi Eletronics Display Europe GmbH, providing intuitive access to all monitor setting controls and remote diagnosis via the Windows interface, based upon the VESA standard, DDC/CI.

  • Page 16: Troubleshooting

    NOTE: As with all personal display devices, NEC-Mitsubishi Electronics Display recommends using a moving screen saver at regular intervals whenever the screen is idle or turning off the monitor when not in use.

  • Page 17: Appendix

    Appendix If you need detailed information about the controls, please use the advanced menu. <How to use the advanced menu> • Turn off your monitor. • Turn on your monitor by pushing the “POWER” and “SELECT” button at the same time for at least one second simultaneously.
  • Page 18 Auto SW Determines the automatic adjustment level for Auto Adjust. The choices are “SIMPLE”, (Analog input only) “FULL” and “DETAIL”. Press “+” or “-” to select. Refer to the below table. Determines the automatic adjustment level as shown in the below table. Size, Fine, Position Contrast Black Level, Long cable capability*...
  • Page 19 Tag6 Colour Control Colour Control Systems: Seven colour presets select the desired colour setting (sRGB, NATIVE and PROGRAMMABLE colour presets are standard and cannot be changed). Colour temperature increases or decreases, in each preset. R,Y,G,C,B,M,S: Increases or decreases Red, Yellow, Green, Cyan, Blue, Magenta and Saturation depending upon which is selected.
  • Page 20 OSM Lock Out This control completely locks out access to all OSM control functions. When attempting to activate OSM controls while in the Lock Out mode, a screen will appear indicating the OSM controls are locked out. There are two types of OSM LOCK OUT: OSM LOCK OUT with BRIGHTNESS and CONTRAST control: To activate the OSM Lock Out function, press SELECT, then “+”...

  • Page 21: Tco'99

    TCO’99 Congratulations! You have just purchased a Lead** TCO’99 approved and labelled product! Your Lead can be found in picture tubes, display screens, solders and choice has provided you with a product developed capacitors. Lead damages the nervous system and in higher for professional use.

  • Page 22: Manufacturer's Recycling And Energy Information

    ISO (International Organisation for Standardization) and TCO (Swedish Trades Union). For more information, and for help in recycling your old NEC or Mitsubishi monitors, please visit our website at http://www.nec-mitsubishi.com (in Europe) or http://www.nmv.co.jp/environment (in Japan) or...
