CE MARK TECHNICAL FILE
AUSTRALIA EMC CONSTRUCTION
FILE
of
Personal Computer
Model/ Type/ Machine Type
VT7200D
Contains:
1. Declaration of Conformity
2. EN55022/CISPR 22, AS/NZS 3548 Class B EMI test report
3. EN55024, AS/NZS 4252.1, EN61000-3-2, and EN61000-3-3
test report
4. Certificate of EN60950
5. Block Diagram and Schematics
6. User`s manual
Date: 2001/11/20
ISL-01A105E
