802.11g USB Wireless Adapter
Installation Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the 802.11g USB and is the answer not in the manual?

Questions and answers

Related Manuals for 2Wire 802.11g USB

Summary of Contents for 2Wire 802.11g USB

  • Page 1 802.11g USB Wireless Adapter Installation Guide...
  • Page 2 Notice to Users ©2008 2Wire, Inc. All rights reserved. This manual in whole or in part, may not be reproduced, translated, or reduced to any machine-readable form without prior written approval. 2WIRE PROVIDES NO WARRANTY WITH REGARD TO THIS MANUAL, THE SOFTWARE, OR OTHER...

  • Page 3: Windows Vista

    Wireless USB Adapter allows users to roam throughout the home or office while remaining connected to the local area network (LAN). Windows Vista These instructions describe the procedure to install the adapter and driver for the 2Wire 802.11g Wireless USB Adapter under Microsoft Windows Vista, and to run a...
  • Page 4 Follow these steps to complete the adapter installation: Step 1 - Install the 2Wire 802.11g Wireless USB Adapter. Step 2 - Install the adapter driver from your 2Wire Wireless Installation CD. Step 3 - Configure the Wireless Manager. The following sections give you detailed instructions for completing each step.
  • Page 5 Step 1: Install the 2Wire 802.11g Wireless USB Adapter The supplied USB cable has a different type of USB connector on each end. Series A connector. The Series A USB connector plugs into the USB port on your computer. Mini Series B connector. The Series B USB connector plugs into a...
  • Page 6 Connect the 2Wire 802.11g Wireless USB Adapter to an available USB port on your computer using the supplied USB cable.
  • Page 7 You may see the Windows Found New Hardware Wizard screen. If this occurs, simply click Cancel to continue with the original driver installation workflow.
  • Page 8 Step 2: Installing the Driver Insert the CD into your computer and wait for the installer to load. You may see a User Account Control dialog box, where you must click Allow - I trust this program in order to proceed with the installation.
  • Page 9 The Install USB Driver menu displays. Choose and click Windows Vista Driver. A separate 2Wire WLAN Driver InstallShield Wizard window opens to prepare installation setup. Note: The 2Wire Wireless Manager utility is not installed on computer systems running Microsoft Windows Vista 64-bit.
  • Page 10 Wireless LAN USB Driver - Ready to Install the Program window opens. Click Install to begin the installation. The InstallShield Wizard will install the driver software. Once the driver has been installed, a new window for the 2Wire Wireless Manager Setup will open automatically.
  • Page 11 Click Setup to continue with the installation of the 2Wire Wireless Manager software. Next, the InstallShield Wizard for 2Wire Wireless Manager will open. The InstallShield Wizard will let you install, repair, or remove 2Wire Wireless Manager from your computer.
  • Page 12 From the Welcome to the InstallShield Wizard for 2Wire Wireless Manager window, click Next to continue the installation. Click to accept the terms in the License Agreement, and click Next. Click Next to install the program to the default folder location, or click Change to install to a different folder of your choice.
  • Page 13 The Ready to Install the Program window opens. Click Install to commence the installation. Wait for the installation to complete. You can monitor the installation status in the status bar window.
  • Page 14 Upon completion, the InstallShield Wizard Completed window will open. Click Finish Continue to Step 3: Configure the Wireless Manager.
  • Page 15 Step 3: Configure the Wireless Manager Once you have finished with Step 2, the 2Wire Wireless Configuration Utility starts automatically. Follow the on-screen instructions to configure your wireless setting. Enter the 2Wire gateway’s serial number and encryption key, located on the bottom of...
  • Page 16 Click Begin Wireless Configuration to continue.
  • Page 17 Once the 2Wire Wireless Configuration Utility finishes, the installation window will close and the 2Wire Wireless Manager window will open. You are now ready to begin using the adapter to connect wirelessly.

  • Page 18: Windows Xp, Windows 2000

    These instructions describe the procedure to install the adapter and driver for the 2Wire 802.11g Wireless USB Adapter under Microsoft Windows XP and Windows 2000, and to run a wireless configuration program to configure your 2Wire 802.11g Wireless USB Adapter to work with the 2Wire gateway.
  • Page 19 Follow these steps to complete the adapter installation: Step 1 - Install the 2Wire 802.11g Wireless USB Adapter. Step 2 - Install the adapter driver from your 2Wire Wireless Installation CD. Step 3 - Configure the Wireless Manager. The following sections give you detailed instructions for completing each step.
  • Page 20 Connect the 2Wire 802.11g Wireless USB Adapter to an available USB port on your computer using the supplied USB cable.
  • Page 21 You may see the Windows Found New Hardware Wizard screen. If this occurs, simply click Cancel to continue with the original driver installation workflow.
  • Page 22 Click the Install USB Driver button. The Install USB Driver menu displays. Depending on your operating system, choose and click Windows XP Driver or Windows 2000 Driver. A separate 2Wire Wireless LAN USB Driver InstallShield Wizard window opens to prepare installation setup.
  • Page 23 Wireless LAN USB Driver - Ready to Install the Program window opens. Click Install to begin the installation. The InstallShield Wizard will install the driver software. Once the driver has been installed, a new window for the 2Wire Wireless Manager Setup will open automatically.
  • Page 24 Click Setup to continue with the installation of the 2Wire Wireless Manager software. Next, the InstallShield Wizard for 2Wire Wireless Manager will open. The InstallShield Wizard will let you install, repair, or remove 2Wire Wireless Manager from your computer.
  • Page 25 From the Welcome to the InstallShield Wizard for 2Wire Wireless Manager window, click Next to continue the installation. Click to accept the terms in the License Agreement, and click Next. Click Next to install the program to the default folder location, or click Change to install to a different folder of your choice.
  • Page 26 The Ready to Install the Program window opens. Click Install to commence the installation. Wait for the installation to complete. You can monitor the installation status in the status bar window.
  • Page 27 Upon completion, the InstallShield Wizard Completed window will open. Click Finish Continue to Step 3: Configure the Wireless Manager.
  • Page 28 Step 3: Configure the Wireless Manager Once you have finished with Step 2, the 2Wire Wireless Configuration Utility starts automatically. Follow the on-screen instructions to configure your wireless setting. Enter the 2Wire gateway’s serial number and encryption key, located on the bottom of...
  • Page 29 Click Begin Wireless Configuration to continue.
  • Page 30 Once the 2Wire Wireless Configuration Utility finishes, the installation window will close and the 2Wire Wireless Manager window will open. You are now ready to begin using the adapter to connect wirelessly.

  • Page 31: Regulatory Information

    Regulatory Information FCC Statement This device has been tested and complies with the specifications for a Class B digital device, pursuant to Part 15 of the FCC rules. These rules are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used according to the instructions, may cause harmful interference to radio communications.
