1
Pure
User Guide

Advertisement

   Also See for Siemens Pure 500

   Summary of Contents for Siemens Pure 500

  • Page 1 Pure User Guide...
  • Page 3 Introduction Dear Customer, Congratulations! You have selected the new Pure hear- ing instruments from Siemens. These instructions as well as the guidance from your Hearing Care Professional will help you understand how your new Pure hearing instruments work. If you have any further questions, please contact your...
  • Page 4: Table Of Contents

    Contents Your Pure hearing instrument Intended use General notes on safety Handling of standard and rechargeable batteries 10 Low battery indicato Inserting the batter Removing the batter Inserting and removing your hearing instrument 13 Inserting your hearing instrumen Removing your hearing instrumen Turning your hearing instrument on and off Changing the hearing program e2e wireless 2.0...
  • Page 5 Handling of the Receiver Unit Remove Receiver Uni Attach Receiver Uni Accessories Remote contro Charge Tek wireless enhancemen Troubleshooting tips Technical information Disposal information Your hearing instrument configuration...
  • Page 6: Your Pure Hearing Instrument

    Your Pure hearing instrument ① Features: ④ ② ① Receiver Unit ⑤ ② Dome ③ ③ Battery compartment ④ Push Button ⑦ ⑤ Microphone Cover ② ⑥ ⑥ Receiver Mold ⑦ C-Guard ⑦ CAUTION Risk of injury caused by incorrect use of Domes. Always wear the Receiver Unit with the Dome.
  • Page 7: Intended Use

    Intended use Hearing instruments are intended to improve the hearing of hearing impaired persons. Diagnosis and prescription of a hearing instrument must be performed by hearing health specialists, e.g. ENT doctors, audiologists or acous- ticians. Read and follow the instructions of this user guide to avoid injuries or damage to the hearing instrument.
  • Page 8: General Notes On Safety

    General notes on safety NOTICE Your hearing instrument is sensitive to extreme heat, high humidity, strong magnetic fields (> 0.1T), X-rays and mechanical stress. Do not expose your hearing instrument to extreme temperature or high humidity. Do not leave it in direct sunlight. Do not wear it in the shower or when you apply make- up, perfume, aftershave, hairspray or suntan lotion.
  • Page 9 General notes on safety In some countries restrictions for the usage of wireless equipment exist. Refer to local authorities for further information. NOTICE for batteries Leaking batteries damage the instrument. Remove batteries when the instrument is not in use for a prolonged period of time.
  • Page 10: Handling Of Standard And Rechargeable Batteries

    Handling of standard and rechargeable batteries Use standard batteries or rechargeable batter- ies in your hearing instruments. Always use size 312 batteries. Charge the rechargeable batteries before first use. original size Remove the tab on your batteries only when you are ready to use them.
  • Page 11: Inserting The Battery

    Handling of standard and rechargeable batteries Inserting the battery Open the battery compartment completely using your fingernail as shown in the il- lustration. Insert the proper size battery. Make sure that the "+" symbol on the battery points up as shown in the picture.
  • Page 12: Removing The Battery

    Handling of standard and rechargeable batteries Removing the battery Open the battery compartment complete- Normally the battery drops out when the compartment is completely open. If the battery does not come out, lightly tap the instrument or push the battery out with a pencil as shown.
  • Page 13: Inserting And Removing Your Hearing Instrument

    Inserting and removing your hearing instrument NOTICE Do not use lubricant when you insert the Dome/ Re- ceiver Mold, because it may clog the sound outlet. NOTICE For hearing instruments with Receiver Mold, handle by holding the Receiver Mold. Do not pull the tube. Inserting your hearing instrument Turn your hearing instrument off.
  • Page 14: Removing Your Hearing Instrument

    Inserting and removing your hearing instrument Removing your hearing instrument Turn your hearing instrument off. Hold the Receiver Unit/ Receiver Mold between your thumb and index finger and carefully pull it out. You may find it helpful to lightly push your ear from the back.
  • Page 15: Turning Your Hearing Instrument On And Off

    Turning your hearing instrument on and off Turn on: Press the push button for 2 seconds to turn the instrument ON. Turn off: Press the push button for 2 seconds to turn the instrument OFF. You can also use the remote control to turn the hea- ring instrument on and off.
  • Page 16: Changing The Hearing Program

    Changing the hearing program Your hearing instruments offer up to 5 hearing pro- grams for specific listening environments. Each time you press the program button, your hear- ing instruments switch to the next program, con- firming each change with an acoustic signal. Example Turn your hearing instruments on.
  • Page 17: E2e Wireless 2.0

    e2e wireless 2.0 Your hearing instruments are equipped with e2e (ear-to- ear) wireless 2.0 technology. Advantages of the wireless functionality: Automatically adjusts both hearing instruments simulta- neously to different listening situations. Allows use of accessories, e.g. a remote control. Provides synchronization of the settings in the system. If you change the volume or program on one hearing in- strument, the other hearing instrument is automatically adjusted.
  • Page 18: Maintenance And Care

    Maintenance and care Your hearing instruments are highly sensitive systems. Proper care and handling will ensure the best possible performance. Clean instruments regularly to prevent damage to the hearing instruments and to avoid health problems. Clean your hearing instruments with a soft, dry tissue, as necessary.
  • Page 19: Domes And Receiver Molds

    Domes and Receiver Molds Your hearing instruments have one of the following ear pieces: Dome with Grid-Dome Receiver Mold C-Guard with C-Guard Full functionality of Domes, Grid-Domes and Receiver Molds is only assured with a working wax guard. Wax guard is the Wax guard is the Wax guard is the integrated...
  • Page 20: Cleaning

    Domes and Receiver Molds Cleaning NOTICE Domes, Grid-Domes and Receiver Molds are easily dam- aged when handled wrongly. Never use brushes or sharp objects for cleaning. Never use running water or immerse the hearing in- strument. Never use pressure or rotating action while cleaning. Don't spray cerumen solvent directly onto the C-Guard! Do not pull the receiver out of the Receiver Mold.
  • Page 21: Replacing The Dome/ Grid-dome

    Domes and Receiver Molds Replacing the Dome/ Grid-Dome Remove the old Dome/ Grid-Dome from the receiver. Press the tip of the Receiver Unit into the new Dome/ Grid-Dome. Ensure that the Dome/ Grid-Dome is fully attached (refer to illustra- tion). If the Dome/ Grid-Dome is not mounted correctly the sound quality will be affected.
  • Page 22: Replacing The C-guard Of The Receiver Mol D

    Domes and Receiver Molds Replacing the C-Guard of the Receiver Mold Remove the C-Guard with the back side of the C-Guard tool. The C-Guard can not be re-used after the disassembling process. Insert the new C-Guard. Change the C-Guard approximately every three months, or as needed.
  • Page 23: Handling Of The Receiver Unit

    Handling of the Receiver Unit The Receiver Unit can be changed as needed by your Hearing Care Professional. If you need to replace the Receiver Unit by yourself follow these directions care- fully. Remove Receiver Unit Hold the instrument in one hand and turn the Receiver Unit with the other hand carefully to the left (45º) and remove it.
  • Page 24: Accessories

    Accessories Remote control The wireless function of your hearing instruments allows you to use a remote control to change the program and volume of your hearing instruments. For further information about the remote control, contact your Hearing Care Professional or refer to the remote con- trol user guide.
  • Page 25: Charger

    Accessories Charger Your hearing instruments work with standard or recharge- able batteries. With the easy-to-use charger you can charge the rechargeable batteries for one or two hearing instruments. After just five hours of charging, the charger shuts itself off and the hear- ing instruments are ready to run for a day.
  • Page 26: Tek Wireless Enhancement

    Accessories Tek wireless enhancement Your hearing instruments together with the Tek Connect remote control will allow you to con- nect your hearing instruments to the growing world of technology. Via a special Bluetooth connection it is possible to receive audio sig- nals from your mobile, your television or your mp3-player.
  • Page 28: Troubleshooting Tips

    Troubleshooting tips Your Pure hearing are reliable devices. Should instruments a problem occur, it can usually be corrected quickly. Use these troubleshooting tips to resolve simple issues. Problem Cause Sound is weak Weak or dead battery Dome / Receiver Mold clogged Volume too low Instrument emits Improper seating in ear...
  • Page 29 Possible Solution Insert new standard battery Clean Receiver Mold / clean or change Dome Increase volume (with remote control) Try reinserting the Receiver Unit until it fits securely Lower volume (with remote control) Clean Dome / Receiver Mold or contact your Hearing Care Professional Lower volume (with remote control) Replace battery...
  • Page 30: Technical Information

    Changes or modifications not expressly approved by the party responsible for compliance could void the users au- thority to operate the equipment. Siemens Pure 300, Pure 500, Pure 700 FCC ID: SGI-WL002BTE IC: 267AB-WL002 This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canady.
  • Page 31 Technical information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reason- able protection against harmful interference in a residen- tial installation.
  • Page 32: Disposal Information

    Valetta CMR 01 Kilbarrack Crawley RH109TT P.O. Box 374 5 Dublin www.siemens.com/hearing With the CE marking Siemens confirms compliance with the European Directive 93/42/EEC concerning 0123 medical devices and the European Directive 99/5/EC (R&TTE) concerning radio and telecommunica- tions terminal equipment.
  • Page 33: Your Hearing Instrument Configuration

    Your hearing instrument configuration Hearing instrument LEFT RIGHT Model Serial number Battery Power on delay Push button Signal tones Low battery warning Volume control limit Volume control change Hearing Description of the hearing program program Remote control (e.g. ProPocket) Serial number...
  • Page 34 Notes...
  • Page 36 © Siemens AG, 04.2009 · SB Document No. A91SAT-00311-99T4-7600 Order/Item No. 104 172 08 Printed in Germany Siemens Audiologische Technik GmbH Gebbertstrasse 125 91058 Erlangen Germany Phone +49 9131 308 0 www.siemens.com /hearing...
