- Page 1 Product Manual Barracuda ES Serial ATA ST3750640NS ST3750840NS ST3500630NS ST3500830NS ST3400620NS ST3400820NS ST3250620NS ST3250820NS ST3320620NS ST3320820NS 100424667 Rev. D September 2007...
-
Page 2: Revision History
United States and/or other countries. Barracuda, SeaTools and SeaTDD are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. All other trademarks or registered trademarks are the property of their respective owners. -
Page 3: Table Of Contents
Seagate Technology support services ........ - Page 4 Barracuda ES Serial ATA Product Manual, Rev. D...
- Page 5 Mounting dimensions—top, side and end view ........29 Barracuda ES Serial ATA Product Manual, Rev. D...
-
Page 7: Introduction
Introduction This manual describes the functional, mechanical and interface specifications for the following Seagate Barracuda ES Serial ATA model drives: ® ST3750640NS ST3500630NS ST3400620NS ST3320620NS ST3250620NS ST3750840NS ST3500830NS ST3400820NS ST3320820NS ST3250820NS These drives provide the following key features: • 7,200 RPM spindle speed. -
Page 8: About The Serial Ata Interface
Shadow Register Block. All Serial ATA devices behave like Device 0 devices. For addi- tional information about how Serial ATA emulates parallel ATA, refer to the “Serial ATA: High Speed Serialized AT Attachment” specification. The specification can be downloaded from www.serialata.org. Barracuda ES Serial ATA Product Manual, Rev. D... -
Page 9: Drive Specifications
ST3400820NS ST3320820NS ST3250820NS Specification summary tables The specifications listed in the following tables are for quick reference. For details on specification measure- ment or definition, see the appropriate section of this manual. Barracuda ES Serial ATA Product Manual, Rev. D... - Page 10 Altitude, nonoperating –60.96 m to 12,192 m (below mean sea level, max) (–200 ft. to 40,000+ ft.) Operational Shock (max at 2 msec) 63 Gs Non-Operational Shock (max at 2 msec) 300 Gs Barracuda ES Serial ATA Product Manual, Rev. D...
- Page 11 *One Gbyte equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting. **During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Barracuda ES Serial ATA Product Manual, Rev. D...
- Page 12 Altitude, nonoperating –60.96 m to 12,192 m (below mean sea level, max) (–200 ft. to 40,000+ ft.) Operational Shock (max at 2 msec) 63 Gs Non-Operational Shock (max at 2 msec) 300 Gs Barracuda ES Serial ATA Product Manual, Rev. D...
- Page 13 *One Gbyte equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting. **During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Barracuda ES Serial ATA Product Manual, Rev. D...
- Page 14 Altitude, nonoperating –60.96 m to 12,192 m (below mean sea level, max) (–200 ft. to 40,000+ ft.) Operational Shock (max at 2 msec) 63 Gs Non-Operational Shock (max at 2 msec) 300 Gs Barracuda ES Serial ATA Product Manual, Rev. D...
- Page 15 *One Gbyte equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting. **During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Barracuda ES Serial ATA Product Manual, Rev. D...
- Page 16 Altitude, nonoperating –60.96 m to 12,192 m (below mean sea level, max) (–200 ft. to 40,000+ ft.) Operational Shock (max at 2 msec) 63 Gs Non-Operational Shock (max at 2 msec) 350 Gs Barracuda ES Serial ATA Product Manual, Rev. D...
- Page 17 *One Gbyte equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting. **During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Barracuda ES Serial ATA Product Manual, Rev. D...
- Page 18 Altitude, nonoperating –60.96 m to 12,192 m (below mean sea level, max) (–200 ft. to 40,000+ ft.) Operational Shock (max at 2 msec) 63 Gs Non-Operational Shock (max at 2 msec) 350 Gs Barracuda ES Serial ATA Product Manual, Rev. D...
- Page 19 *One Gbyte equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting. **During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Barracuda ES Serial ATA Product Manual, Rev. D...
-
Page 20: Formatted Capacity
Sectors per track 16,383 LBA mode When addressing these drives in LBA mode, all blocks (sectors) are consecutively numbered from 0 to n–1, where n is the number of guaranteed sectors as defined above. Barracuda ES Serial ATA Product Manual, Rev. D... -
Page 21: Recording And Interface Technology
635 grams (1.4 lbs) ST3400820NS, ST3320620NS and ST3320820NS ST3250620NS and ST3250820NS 580 grams (1.28 lbs) Cache buffer ST3750640NS 16 Mbytes (16,384 kbytes) ST3500630NS ST3400620NS ST3320620NS ST3250620NS ST3750840NS 8 Mbytes (8,192 kbytes) ST3500830NS ST3400820NS ST3320820NS ST3250820NS Barracuda ES Serial ATA Product Manual, Rev. D... -
Page 22: Seek Time
Start/stop times Power-on to Ready (sec) 15 (max) Standby to Ready (sec) 15 (max) Ready to spindle stop (sec) 10 (max) Barracuda ES Serial ATA Product Manual, Rev. D... -
Page 23: Power Specifications
Standby 0.80 0.106 0.023 Sleep 0.80 0.106 0.023 *During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Barracuda ES Serial ATA Product Manual, Rev. D... -
Page 24: Conducted Noise
10 MHz. Note. Equivalent resistance is calculated by dividing the nominal voltage by the typical RMS read/write current. 2.8.3 Voltage tolerance Voltage tolerance (including noise): 5V ± 5% 12V ± 10% Barracuda ES Serial ATA Product Manual, Rev. D... -
Page 25: Power-Management Modes
Standby mode. In both Idle and Standby mode, the drive accepts all commands and returns to Active mode when disc access is necessary. Barracuda ES Serial ATA Product Manual, Rev. D... -
Page 26: Environmental Specifications
300 Gs for 750, 500 and 400 GB models) and 350 Gs (for 250 GB models) based on a nonrepetitive half-sine shock pulse of 2 msec duration. Barracuda ES Serial ATA Product Manual, Rev. D... -
Page 27: Vibration
3.2 bels (typ) 2.8 bels (max) 3.5 bels (max) *During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Barracuda ES Serial ATA Product Manual, Rev. D... -
Page 28: Electromagnetic Immunity
150 kHz to 80 MHz, 3 Vrms, 80% AM with 1 kHz sine A EN 61000-4-6: 97 immunity Voltage dips, 0% open, 5 seconds EN 61000-4-11: 94 interrupts 0% short, 5 seconds 40%, 0.10 seconds 70%, 0.01 seconds Barracuda ES Serial ATA Product Manual, Rev. D... -
Page 29: Reliability
Information Technology Equipment (ITE). Emission levels are defined by EN 55022, Class B and the immunity levels are defined by EN 55024. Seagate uses an independent laboratory to confirm compliance with the EC directives specified in the previous paragraph. Drives are tested in representative end-user systems. Although CE-marked Seagate drives comply with the directives when used in the test systems, we cannot guarantee that all systems will comply with the directives. -
Page 30: Fcc Verification
As a subassembly, no Federal Communications Commission verification or certification of the device is required. Seagate Technology LLC has tested this device in enclosures as described above to ensure that the total assembly (enclosure, disc drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules. -
Page 31: Environmental Protection
The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chlo- ride, and nitrate contaminants. Sulfur is found to be the most damaging. In addition, electronic components should never be exposed to condensing water on the surface of the printed circuit board assembly (PCBA) or exposed to an ambient relative humidity greater than 95%. - Page 32 Barracuda ES Serial ATA Product Manual, Rev. D...
-
Page 33: Configuring And Mounting The Drive
• Do not remove the factory-installed labels from the drive or cover them with additional labels. Removal voids the warranty. Some factory-installed labels contain information needed to service the drive. Other labels are used to seal out dirt and contamination. Barracuda ES Serial ATA Product Manual, Rev. D... -
Page 34: Configuring The Drive
For installations which require cables, you can connect the drive as illustrated in Figure 4. Signal connector Power connector Signal cable Power cable Figure 4. Attaching SATA cabling Each cable is keyed to ensure correct orientation. Barracuda ES Serial ATA drives support latching SATA con- nectors. Barracuda ES Serial ATA Product Manual, Rev. D... -
Page 35: Drive Mounting
2 x 3.750 (2 x 95.25) 2 x 1.625 (2 x 41.28) [1] 2 x 1.750 (2 x 44.45) 4.000 (101.6) Recommended case temperature measurement location Figure 5. Mounting dimensions—top, side and end view Barracuda ES Serial ATA Product Manual, Rev. D... - Page 36 Barracuda ES Serial ATA Product Manual, Rev. D...
-
Page 37: Serial Ata (Sata) Interface
Attachment” specification. Hot-Plug compatibility Barracuda ES Serial ATA drives incorporate connectors which enable you to hot plug these drives in accor- dance with the Serial ATA II: Extension to Serial ATA 1.0a specification. This specification can be downloaded from www.serialata.org. -
Page 38: Serial Ata Device Plug Connector Pin Definitions
3. There are three power pins for each voltage. One pin from each voltage is used for pre-charge when installed in a blind-mate backplane configuration. 4. All used voltage pins (V ) must be terminated. Barracuda ES Serial ATA Product Manual, Rev. D... -
Page 39: Supported Ata Commands
Read Native Max Address Extended Read Sectors Read Sectors Extended Read Sectors Without Retries Read Verify Sectors Read Verify Sectors Extended Read Verify Sectors Without Retries Recalibrate Security Disable Password Security Erase Prepare Barracuda ES Serial ATA Product Manual, Rev. D... - Page 40 Write DMA Extended Write DMA FUA Extended Write DMA Without Retries Write Log Extended Write Multiple Write Multiple Extended Write Multiple FUA Extended Write Sectors Write Sectors Without Retries Write Sectors Extended Barracuda ES Serial ATA Product Manual, Rev. D...
-
Page 41: Identify Device Command
Number of current logical heads xxxx Number of current logical sectors per logical track xxxx 57– Current capacity in sectors xxxx Number of sectors transferred during a Read Multiple or Write Multiple xxxx command Barracuda ES Serial ATA Product Manual, Rev. D... - Page 42 These words are required for drives that support 500 GB models = 976,773,168 the 48-bit addressing feature. Maximum value: 0000FFFFFFFFFFFFh. 400 GB models = 781,422,768 320 GB models = 625,142,448 250 GB models = 488,397,168 104– ATA-reserved 0000 Barracuda ES Serial ATA Product Manual, Rev. D...
- Page 43 Word 0xE3 set to 0x1388 // 5 seconds Word 0xE4 set to 0x2710 // 10 seconds Word 0xE5 set to 0x0015 // 21 seconds Word 0xE6 set to 0x0025 // 37 seconds Word 0x5B set to 0xFEFE Barracuda ES Serial ATA Product Manual, Rev. D...
- Page 44 Ultra DMA mode 2 is currently active. Ultra DMA mode 3 is currently active. Ultra DMA mode 4 is currently active. Ultra DMA mode 5 is currently active. Ultra DMA mode 6 is currently active. Barracuda ES Serial ATA Product Manual, Rev. D...
-
Page 45: Set Features Command
Enable read look-ahead (read cache) feature (default). Report full capacity available At power-on, or after a hardware or software reset, the default values of the features are as indi- Note. cated above. Barracuda ES Serial ATA Product Manual, Rev. D... -
Page 46: S.m.a.r.t. Commands
S.M.A.R.T. Disable Operations S.M.A.R.T. Return Status If an appropriate code is not written to the Features Register, the command is aborted and 0x 04 Note. (abort) is written to the Error register. Barracuda ES Serial ATA Product Manual, Rev. D... -
Page 47: Seagate Technology Support Services
Seagate Service Centers Presales Support Our Presales Support staff can help you determine which Seagate products are best suited for your specific application or computer system, as well as product availability and compatibility. Technical Support Seagate technical support is available to assist you online at support.seagate.com... - Page 48 Seagate Customer Service Operations (CSO) representative for warranty- related issues. Resellers or end users of drive products should contact their place of purchase or Seagate warranty service for assistance. Have your serial number and model or part number available.
- Page 49 CSA C22.2 (950) 23 guaranteed sectors 14 cycles 23 Cylinders 14 Handling precautions 27 heads 14 data-transfer rates 1 height 15 DC power 17 humidity 20 Default logical geometry 14 density 15 Barracuda ES Serial ATA Product Manual, Rev. D...
- Page 50 Recording technology 15 Nonrecoverable read errors 23 relative humidity 20 Reliability 23 RF 22 RMS read/write current 18 operating 17 RoHS 25 Operating power 17 RRL 24 Operating shock 20 Operating vibration 21 Barracuda ES Serial ATA Product Manual, Rev. D...
- Page 51 Spinup power 17 Standby 17 Standby Immediate 34 Standby mode 17 standby timer 19 Standby to Ready 16 Start/stop times 16 start-stop cycles 23 static-discharge 27 support services 41 Surge immunity 22 Barracuda ES Serial ATA Product Manual, Rev. D...
- Page 52 Barracuda ES Serial ATA Product Manual, Rev. D...
- Page 54 Seagate Technology LLC 920 Disc Drive, Scotts Valley, California 95066-4544, USA Publication Number: 100424667, Rev. D, Printed in U.S.A.
