Barracuda ATA Family Product Manual, Rev. B Introduction This manual describes the functional, mechanical and interface specifi- cations for the ST328040A, ST327240A, ST320430A, ST313620A, ST310220A, and the ST36810A. These drives provide the following key features: • Low power consumption • Quiet operation •...
Barracuda ATA Family Product Manual, Rev. B Specification summary table The specifications listed in this table are for quick reference. For details on specification measurement or definition, see the appropriate section of this manual. Drive Specification ST328040A ST320430A ST313620A ST310220A ST36810A ST327270A Guaranteed Mbytes 28,520...
Page 11
Barracuda ATA Family Product Manual, Rev. B Drive Specification ST328040A ST320430A ST313620A ST310220A ST36810A ST327270A Width (mm max) Length (mm max) 147.0 Weight (typical) 550 grams (1.2 lb) Average latency (msec) 4.16 msec Power-on to ready (sec typical) 12 sec Standby to ready (sec typical) 12 sec...
Page 12
Barracuda ATA Family Product Manual, Rev. B Drive Specification ST328040A ST320430A ST313620A ST310220A ST36810A ST327270A Wet bulb tempera- ture (°C max) 29.4 (op.), 40.0 (nonop.) Altitude, operating –122 m to 3,048 m (–400 ft to 10,000 Altitude (meters be- low mean sea level, –122 m to 12,192 m (–400 ft to 40,000 max) Shock, operating...
Barracuda ATA Family Product Manual, Rev. B 1.0 Drive specifications Unless otherwise noted, all specifications are measured under ambient conditions, at 25°C, and nominal power. For convenience, the phrases the drive and this drive are used throughout this manual to indicate the ST328040A, ST327240A, ST320430A, ST313620A, ST310220A and the ST36810A.
Barracuda ATA Family Product Manual, Rev. B 1.2 Physical organization Drive Model Read/Write heads (GMR) Number of discs ST328040A/ST327240A ST320430A ST313620A ST310220A ST36810A 1.3 Recording and interface technology Interface Recording method 16/17 EPRML Recording density KBPI (bits/inch) Track density TPI (tracks/inch) 16,420 Areal density (Mbits/inch max)
Barracuda ATA Family Product Manual, Rev. B Maximum length (mm) 147.0 (inches) 5.78 Typical weight (grams) (pounds) 1.5 Seek time Seek measurements are taken with nominal power at 25°C ambient temperature. All times are measured using drive diagnostics. The spec- ifications in the table below are defined as follows: •...
Barracuda ATA Family Product Manual, Rev. B 1.7 Power specifications The drive receives DC power (+5V or +12V) through a four-pin standard drive power connector. 1.7.1 Power consumption Power requirements for the drives are listed in the table on page 9. Typical power measurements are based on an average of drives tested, under nominal conditions, using 5.0V input voltage at 25°C ambient temperature.
Barracuda ATA Family Product Manual, Rev. B 1.7.2 Conducted noise Input noise ripple is measured at the host system power supply across an equivalent 80-ohm resistive load on the +12 volt line or an equivalent 15-ohm resistive load on the +5 volt line. •...
Barracuda ATA Family Product Manual, Rev. B • Standby mode The drive enters Standby mode when the host sends a Standby Immediate command. If the host has set the standby timer, the drive can also enter Standby mode automatically after the drive has been inactive for a specifiable length of time.
Barracuda ATA Family Product Manual, Rev. B 1.8.2 Temperature gradient Operating/Nonoperating 20°C/hr (36°F/hour) max, without condensation 1.8.3 Humidity 1.8.3.1 Relative Humidity Operating 8% to 80% noncondensing (30% per hour max) Nonoperating 5% to 90% noncondensing (30% per hour max) 1.8.3.2 Wet bulb temperature Operating 29.4°C (84°F) max Nonoperating...
Barracuda ATA Family Product Manual, Rev. B 1.8.6 Vibration All vibration specifications assume that the drive is mounted securely with the input vibration applied at the drive mounting screws. Vibration may be applied in the X, Y or Z axis. 1.8.6.1 Operating vibration The following table lists the maximum vibration levels that the drive may expe- rience while meeting the performance standards specified in this document.
Electromagnetic Compatibility Directives. Testing is performed to standards EN 50082-1 and EN 55022-B. Seagate uses an independent laboratory to confirm compliance with the EC directives specified in the previous paragraph. Drives are tested in representative end-user systems. Although CE-marked Seagate drives comply with the directives when used in the test systems, we cannot guarantee that all systems will comply with the directives.
Communications Commission verification or certification of the device is required. Seagate Technology, Inc. has tested this device in enclosures as de- scribed above to ensure that the total assembly (enclosure, disc drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules.
Page 24
Barracuda ATA Family Product Manual, Rev. B lems . This booklet is available from the Superintendent of Documents, U.S. Government Printing Office, Washington, DC 20402. Refer to pub- lication number 004-000-00345-4.
Barracuda ATA Family Product Manual, Rev. B 2.0 Configuring and mounting the drive This section contains the specifications and instructions for configuring and mounting the drive. 2.1 Handling and static-discharge precautions After unpacking, and before installation, the drive may be exposed to potential handling and electrostatic discharge (ESD) hazards.
Barracuda ATA Family Product Manual, Rev. B 2.2 Jumper settings 2.2.1 Master/slave configuration The options jumper block shown in Figure 2 is used to configure the drive for operation. It is the 6-pin dual header between the interface connector and the power connector. Use the following settings to configure the drive as a master or a slave.
Barracuda ATA Family Product Manual, Rev. B 2.2.2 Cable-select option Computers that use cable-select determine the master and slave drives by selecting or deselecting pin 28, CSEL, on the interface bus. Master and slave drives are determined by their physical position on the cable. To enable cable select, set a jumper on pins 5 and 6 as shown in Figure 2 on page 18.
Barracuda ATA Family Product Manual, Rev. B 3.0 ATA interface These drives use the industry-standard ATA task file interface that supports 16-bit data transfers. It supports ATA programmed input/output (PIO) modes 0–4; multiword DMA modes 0–2, and Ultra DMA modes 0–4.
Barracuda ATA Family Product Manual, Rev. B Drive pin # Host pin # and signal description Signal name Reset – Hardware Reset Ground Ground Host Data Bus Bit 7 Host Data Bus Bit 8 Host Data Bus Bit 6 Host Data Bus Bit 9 Host Data Bus Bit 5 DD10 Host Data Bus Bit 10...
Barracuda ATA Family Product Manual, Rev. B 3.1.1 Supported ATA commands The following table lists ATA-standard commands that the drive sup- ports. For a detailed description of the ATA commands, refer to the Draft ATA-4 Standard. See Section 3.2.4 on page 30 for details and subcom- mands used in the S.M.A.R.T.
Barracuda ATA Family Product Manual, Rev. B Command name Command code (in hex) ATA-standard power-management commands Check Power Mode or E5 Idle or E3 Idle Immediate or E1 Sleep or E6 Standby or E2 Standby Immediate or E0 ATA-standard security commands Security Set Password Security Unlock Security Erase Prepare...
Page 33
Barracuda ATA Family Product Manual, Rev. B Word Description Value Configuration information: Bit 15: 0 = ATA; 1 = ATAPI • 0C5A Bit 7: removable media • Bit 6: removable controller • Bit 0: reserved • Number of logical cylinders ST328040A, ST327240A ST320430A, ST313620A, ST310220A = 16,383...
Page 34
Barracuda ATA Family Product Manual, Rev. B Word Description Value (Bits 7–0) Maximum sectors 8010 per interrupt on Read multi- ple and Write multiple (16) Reserved 0000 Standard Standby timer, 2F00 IORDY supported and may be disabled ATA-reserved 0000 PIO data-transfer cycle 0200 timing mode Retired...
Page 35
Barracuda ATA Family Product Manual, Rev. B Word Description Value Advanced PIO modes sup- 0003 ported (modes 3 and 4 sup- ported) Minimum multiword DMA 0078 transfer cycle time per word (120 nsec) Recommended multiword 0078 DMA transfer cycle time per word (120 nsec) Minimum PIO cycle time 00F0...
Page 36
Hardware Reset Value 4000 (see description following this table) 94–127 ATA-reserved 0000 129–159 Seagate-reserved xxxx 160–255 ATA-reserved 0000 Note. See the bit descriptions below for words, 63, 88 and 93 of the Identify Drive data: Description (if bit is set to 1) Word 63 Multiword DMA mode 0 is supported.
Barracuda ATA Family Product Manual, Rev. B Ultra DMA mode 1 is currently active. Ultra DMA mode 2 is currently active. Ultra DMA mode 3 is currently active. Ultra DMA mode 4 is currently active. Word 93 1=80-conductor cable detected, CBLID above V 0=40-conductor cable detected, CBLID below V 3.1.3 Set Features command This command controls the implementation of various features that the...
Barracuda ATA Family Product Manual, Rev. B Ultra DMA mode 2 Ultra DMA mode 3 Ultra DMA mode 4 Disable read look-ahead (read cache) feature. Disable write cache. Enable read look-ahead (read cache) feature (default). Note. At power-on, or after a hardware or software reset, the default values of the features are as indicated above.
Page 39
Barracuda ATA Family Product Manual, Rev. B Note. If an appropriate code is not written to the Features Register, the command is aborted and 0x04 (abort) is written to the Error register.
Page 40
Barracuda ATA Family Product Manual, Rev. B...
Page 41
Barracuda ATA Family Product Manual, Rev. B...
Page 42
