- Page 1 P5755 IMPORTANT! KEEP INSTRUCTIONS FOR FUTURE REFERENCE. www.fi sher-price.co.uk...
-
Page 2: Consumer Information
Consumer Information IMPORTANT! Place the high chair on a level, stable surface away from electrical flexes. Be sure to keep electrical flexes out of child's reach. • Please read these instructions before assembly and use of this product. - Page 3 Assembled Parts CAUTION This package contains small parts in its unassembled state. Adult assembly is required. Seat Back Seat Bottom 2 Frames Hinge Rod Back Base Front Base 2 Seat Bottom Tubes Footrest Food Tray Base Tray Note: Tighten or loosen all screws with a Phillips screwdriver. Do not over-tighten the screws. #8 x 1,9 cm Screws –...
- Page 4 IMPORTANT! Before assembly and each use, inspect this product for damaged hardware, loose joints, missing parts or sharp edges. DO NOT use if any parts are missing or broken. Contact Fisher-Price for replacement parts and instructions if needed. Never substitute parts.
- Page 5 Insert Screws Here • Insert two #10 x 2,2 cm black screws through the footrest and into the seat bottom. Tighten the screws. This may require extra force. Seat Back Pin Slot Seat Bottom Assembly • Turn the seat bottom assembly upright. •...
- Page 6 Frame Leg Frame Decorated Side Screw Retainers • Pull the frame leg out on each frame to open. Make sure it "clicks" into place. • Position a frame so that the decorated side is outward. • Fit the end of a base into the back leg of a frame. •...
- Page 7 Base • Fit the frame front legs onto the remaining base. • Fit a screw retainer over a hole in the front leg. • Insert a #10 x 2,2 cm black screw through the screw retainer and front leg. Tighten the screw. •...
- Page 8 Elastic Loops Hole FRONT VIEW Tabs Elastic Loops BACK AND BOTTOM VIEW • Lift the bottom of the pad. Insert the two elastic loops on the pad through the holes in the seat bottom. • From the back and bottom of the seat, hook the elastic loops to the tabs on the seat.
- Page 9 • Fold the top of the pad down. • Remove the shoulder portion of the waist/shoulder belts by feeding them through the slots in the seat back. Bottom Slots • Lift the top of the pad. • Thread the waist/shoulder belts through the bottom slots in the back of the seat pad.
- Page 10 • The child should at all times wear a safety harness correctly fitted and adjusted. The tray is not designed to hold the child in the chair. • Do not use the high chair unless all com- ponents are correctly fitted and adjusted. Waist/Shoulder Belt Crotch Belt Crotch Belt •...
- Page 11 To change shoulder belt slots: • From the back of the high chair, push the shoulder portion of the waist/shoulder belts through the seat back slots. Secure Child...
- Page 12 WARNING Prevent serious injury or death from falls or sliding out. The child should at all times wear a safety harness correctly fitted and adjusted. The tray is not designed to hold the child in the chair. Armrest • Fit the base tray onto the seat armrests. Push down until the base tray "snaps"...
- Page 13 Using the Trays Food Tray Base Tray • While pushing the release bar on the front of the base tray, • Fit the food tray into the base tray, as shown. pull the tray base towards you and remove. Hint: Before use, thoroughly wash all parts (the trays) that may contact food.
-
Page 14: Adjusting The Seat
Prevent serious injury or death from falls or sliding out: It is recommended that only children capable of sitting upright unassisted use the high chair in the upright position. Hint: Adjust the seat angle to any of three positions: Upright, Semi-Recline or Recline. - Page 15 Storage • With the legs all the way open, lower the seat to position 7 (the lowest position). • Pull the frame release latches forward and push the rear legs toward the front legs. • The restraint system, pad, frame, trays and tray toy may be wiped clean using a mild cleaning solution and a damp cloth.
- Page 16 Great Britain: Vanwall Business Park, Maidenhead SL6 4UB. Helpline: 01628 500303. www.service.mattel.com/uk. Asia: Mattel East Asia Ltd, Room 1106, South Tower, World Finance Centre, Harbour City, Tsimshatsui, HK, China. Malaysia: Diimport & Diedarkan Oleh: Mattel SEA Ptd Ltd. (993532-P) Lot 13.5, 13th Floor, Menara Lien Hoe, Persiaran Tropicana Golf Country Resort, 47410 PJ.
