Download this manual See also: Operator and Technical Reference Manual, Operating Manual
EZ Manual
M-8400RVe
Electric Checks and Adjustments
Ribbon Clutch Adjustment
Print Head Position Alignment
Print Head Balance Adjustment
home | next
Barcode SATO International Pte Ltd

Advertisement

loading
Need help?

Need help?

Do you have a question about the M-8400RVe and is the answer not in the manual?

Questions and answers

Related Manuals for SATO M-8400RVe

Summary of Contents for SATO M-8400RVe

  • Page 1 EZ Manual M-8400RVe Electric Checks and Adjustments Ribbon Clutch Adjustment Print Head Position Alignment Print Head Balance Adjustment home | next Barcode SATO International Pte Ltd...
  • Page 2 If not, replace parts or adjust sensor level. Refer to Check and Adjustment chart. 6 After performing test, put the LH cover back to the printer. Ground PIN SIG PIN Dial < previous | home | next > TP Test Module Barcode SATO International Pte Ltd...
  • Page 3 High level (Set the label or Gap sensor Level CH2B - CH1A(GND) tag on the sensor) = D High level - Low level = C - D = more than +1.0V < previous | home | next > Barcode SATO International Pte Ltd...
  • Page 4 Dispenser Sensor Level Adjustment VR3(CE) Ribbon Sensor Level Adjustment VR5 I-mark VR4(GAP) Gap Sensor Level Adjustment VR5(IM) I-Mark Sensor Level Adjustment VR4 Gap VR1 Offset VR2 DEM VR3 CE < previous | home | next > MAIN PCB Barcode SATO International Pte Ltd...
  • Page 5 EZ Manual: M-8400RVe Potentiometers are located on FRONT PANEL Electric Checks and Adjustments Chart 3 PRINT Adjust Print Darkness OFFSET Adjust FEED/BACKFEED PITCH Adjust Pitch Offset DISPLAY Adjust Display Darkness < previous | home | next > Barcode SATO International Pte Ltd...
  • Page 6 CW for more tension and CCW for less tension. Tighten the locking screw and repeat steps 3 and 4 until the correct tension is achieved. < previous | home | next > Barcode SATO International Pte Ltd...
  • Page 7 EZ Manual: M-8400RVe Ribbon Clutch Ribbon Unwind Clutch 550g-650g Unwind Adjustment continued Locking Screw is inside Adjust Nut Adjust Nut < previous | home | next > Ribbon Rewind Clutch 950g-1050g Rewind Barcode SATO International Pte Ltd...

  • Page 8: Print Head Position Alignment

    To adjust the print head alignment and consistent quality 2 Tighten the screws. across label, perform the following steps: Adjustment Marks < previous | home | next > Screw Barcode SATO International Pte Ltd...

  • Page 9: Print Head Balance Adjustment

    3 If the front side of label is too light, turn the screw in clockwise direction. 4 If the front side of label is too dark, turn the screw in counter-clockwise direction. < previous | home | next > Loosen the set screw Barcode SATO International Pte Ltd...
