Summary of Contents for Laney Iommi TI100

  • Page 2 WARNING: When using electrical products, basic cautions should always be followed, including the following: 1. Read these instructions. 2. Keep these instructions safe. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with a dry cloth. 7.
  • Page 3 ATTENTION: L’utilisation de tout appareil électrique doit être soumise aux precautions d’usage incluant: 1. Lire ces instructions 2. Gardez ce manuel pour de futures références. 3. Prétez attention aux messages de précautions de ce manuel. 4. Suivez ces instructions. 5. N’utilisez pas cette unité proche de plans d’eau. 6.
  • Page 4 ACHTUNG: Beim Einsatz von Elektrogeräten müssen u.a. grundlegende Vorsichtsmaßnahmen befolgt werden: 1. Lesen Sie sich diese Anweisungen durch. 2. Bewahren Sie diese Anweisungen auf. 3. Beachten Sie alle Warnungen. 4. Befolgen Sie alle Anweisungen. 5. Setzen Sie dieses Gerät nicht in der Nähe von Wasser ein. 6.
  • Page 5 CUIDADO: Cuando use productos electrónicos, debe tomar precauciones básicas, incluyendo las siguientes: 1. Lea estas instrucciones. 2. Guarde estas instrucciones. 3. Haga caso de todos los consejos. 4. Siga todas las instrucciones. 5. No usar este aparato cerca del agua. 6.

  • Page 7: Specifications

    SPECIFICATIONS ~100V, ~120V, ~220V, ~230V, ~240V 50/60Hz Supply Voltage:- Factory Preset Mains Fuse: ~100V>~120V T5A L ~220V, ~230V,~240V T2A L T1A L HT Fuse Power Consumption 300W Output Power Rating 100W Twin Channels - Lead & Rhythm Features: Switchable Pre-Boost on both Channels - LED indicates active EQ - Independent Bass, Mid, Treble on each Channel Volume - Independent on each Channel Enhance - Independent on each Channel...
  • Page 9 The date was February 13, 1970 and the album was Black Sabbath by Black Sabbath – the guitarist was Tony Iommi and the distorted diminished fifth sound was a Laney LA100BL. Since this auspicious day Laney’s association with Tony...

  • Page 10: Front Panel Controls

    FRONT PANEL CONTROLS LEAD CHANNEL RHYTHM CHANNEL LEAD & RHYTHM channels are provided, both can have different settings and be switched between with the channel switch (8) or footswitch if connected. Although the functions of the controls on each channel are similar, the sounds can be very different.
  • Page 11 FRONT PANEL CONTROLS VOLUME: Controls the volume of each channel independantly. Experiment with different combinations of the Drive and Volume controls to achieve different sounds. Reducing the Drive while increasing the Volume will result in a warm, open, overdriven sound as the power amp is driven harder, while reducing the Volume and increasing the Drive will give a tighter, more modern sound with more distortion.

  • Page 12: Rear Panel Controls

    REAR PANEL CONTROLS P O W E R TO T H E M U S I C N15039 L Z B 1 2 3 4 Spare fuse located in the fuse drawer. MAINS INLET SOCKET: Make sure the voltage indicated on the rear panel is correct for your country! MAINS FUSE: This drawer contains the main safety fuse for the unit.
  • Page 13 REAR PANEL CONTROLS EFFECTS LOOP RETURN: Connect the output from your external effects to this socket. EFFECTS LOOP SWITCH: This allows the global effects loop to operate in three distinct modes: 1) Side Chain: The return signal is mixed with the dry signal, the level of FX return is controlled by the FX return level control.

  • Page 14: Quick Start Settings

    QUICK START SETTINGS USE EITHER CHANNEL TONY’S TYPICAL SETTINGS CLEAN CRUNCH LEAD VOLUME AS DESIRED...

  • Page 15: User Settings

    USER SETTINGS...
  • Page 16 TUBE AMP TIPS Tube amplifiers generally sound much warmer/sweeter than solid state transistor amplifiers but they also need a little more respect due to the fragile glass tubes. The TI100 head uses eight 12AX7 preamp tubes, and four 6L6 output tubes which should give you years of trouble free service, however like all tube amps;...

  • Page 17: Block Diagram

    BLOCK DIAGRAM FX SEND FX RETURN LEAD LEAD INPUT DRIVE LEAD LEAD VOLUME POWER AMP PRE AMP Pre-Boost LEVEL CHANNEL SWITCH SIDE CHAIN-INSERT-BYPASS SHOWN IN SIDE CHAIN MODE FOOTSWITCH RHYTHM RHYTHM RHYTHM DRIVE RHYTHM VOLUME Pre-Boost SYM LINK IN SYM LINK OUT 16Ohms 8Ohms 2x16Ohms...

  • Page 18: Sample Setups

    SAMPLE SETUPS FX Unit L Z B 1 2 3 4 L Z B 1 2 3 4 TI412S FS4-TI...
  • Page 19 Master FX Unit Slave Master L Z B 1 2 3 4 L Z B 1 2 3 4 TI412S FS4-TI Slave TI412S L Z B 1 2 3 4 All of the preamp controls are disabled on the Slave amp, only the Dynamics &...
  • Page 20 OPERATING INSTRUCTIONS - Issue 1.3...
