USER MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the Tony Iommi TI100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Laney Tony Iommi TI100

  • Page 1 USER MANUAL...
  • Page 2 CONTENTS INTRODUCTION ..........................2 FRONT CONTROLS ...........................3 1. INPUT ............................3 2. PRE-BOOST ..........................3 3. DRIVE ............................3 4. EQ CONTROLS ........................3 5. VOLUME ..........................3 6. ENHANCE ..........................3 7. PRESENCE ..........................3 8. CHANNEL SWITCH ......................4 9. STANDBY SWITCH ......................4 10. POWER SWITCH ........................4 REAR FEATURES ..........................5 1.
  • Page 3 The band were BLACK SABBATH; the track was the first track of the bands first release. The Guitar player was Tony Iommi and the sound of that super distorted diminished fifth interval was the sound of a Laney amp – an LA100BL.
  • Page 4 FRONT CONTROLS The TI100 contains two preamp channels, LEAD & RHYTHM; both can have different settings and be switched between with the channel switch (8) or footswitch if connected. Although the functions of the controls on each channel are similar, the sounds can be very different. 1/4"...
  • Page 5 Switches between the Lead and Rhythm channels, the LED lights on the active channel. Disconnects the main HT voltage from the tubes but keeps the tubes warm so that they are ready to play instantly. Switch for short breaks when you don't want to wait for the tubes to warm up again. With the switch in the 1 (up) position, the amp is in play mode, while 0 (down) allows the amp to warm up.
  • Page 6 REAR FEATURES Make sure the voltage indicated on the rear panel is correct for your country. The voltage is preset at the factory. The drawer contains the main safety fuse for the unit. The fuse protects the amplifier from damage in the event of fault by disconnecting the mains power supply. A spare is included inside. This fuse disconnects the high voltage DC power to the tubes within the amplifier in the event of a tube fault.
  • Page 7 FX Loop for connected external devices. The FX SEND 1/4" mono jack socket should be connected to the input of an external FX unit. This can also be used as a line out for connection to another power amp slave input or for recording. The FX RETURN connects to the output from your external effects. It is switchable between insert, side chain and bypass modes.
  • Page 8 CONNECTIONS Page 7...
  • Page 9 QUICK START SETTINGS Page 8...
  • Page 10 BLOCK DIAGRAM Page 9...
  • Page 11 325 x 810 x 360mm (12.8" x 31.9" x 14.2") , 0.095 M3 Packed Weight 25.5Kg, (56.2 lbs) EAN Code (Single) 5060109453072 In the interest of continued development, Laney reserves the right to amend product specification without prior notification. Page 10...
  • Page 12 1) Unpacking: On unpacking your product, please check carefully for any signs of damage that may have occurred whilst in transit from the Laney factory to your dealer. In the unlikely event that there has been damage, please re-pack your unit in its original carton and consult your dealer.
  • Page 13 1) This device may not cause harmful interference. 2) This device must accept any interference received, that may cause undesired operation. Warning: Changes or modification to the equipment not approved by Laney can void the user's authority to use the equipment.
  • Page 14 LANEY STEELPARK ROAD, COOMBSWOOD BUSINESS PARK WEST, HALESOWEN, B62 8HD. UK FOR THE LATEST INFORMATION PLEASE VISIT WWW.LANEY.CO.UK IN THE INTEREST OF CONTINUED DEVELOPMENT, LANEY RESERVES THE RIGHT TO AMEND PRODUCT SPECIFICATION WITHOUT PRIOR NOTIFICATION. Page 13 V1.0...
