Page x of y
Rev 02 05/04/05
SC-554
Thank you for buying the Robic SC-554. Your purchase brings you a world class timer with a vast array of
advanced timekeeping functions.
Please take a few moments to review this operating guide, so that you may become familiar with the SC-
554's many capabilities and how you can best access them for your maximum benefit.
PART I
PUSHBUTTON and INDICATOR LOCATION
The following illustration details the location of pushbuttons and indicators for setting and operating the
SC-554.
Pushbutton "B"
LAP •SPLIT/RESET
Pushbutton "D"
AVG/MAXIMUM
Alarm Time Display
Pushbutton "F"
MEMORY RECALL/SET
The indicators in this illustration will appear only when a particular mode or function is activated by
pressing a pushbutton.
Once you are familiar with the SC-554's operation, you will be ready to enjoy its many functions. The
starting point for any operation is the NORMAL TIME mode. You may sequence through the modes by
pressing "E".
NORMAL TIME
Time of Day in Hours, Minutes and Seconds
Calendar with Day, Month and Date
AM/PM or 24 Hour Time Options
Daily Alarm and Hourly Chime
CHRONOGRAPH (Stopwatch)
Three (3) Timing Options
(1) Lap Time Chronograph
(2) Split (accumulated) Time Chronograph, or
(3) Dual Lap/Split Time Chronograph
SC-554 Instructions
Pushbutton "E"
MODE/NEXT
Pushbutton "A"
START/STOP
Indicators:
UP, DOWN, AVG, MAX, SET, DIST, MILE, KM
Indicators:
CHRONO, LAP/SPL, RUN, STOP, SPEED, RCL, ♠, (((•)))
Pushbutton "C"
ADVANCE/RELEASE, Alarm,/Chime On/Off
Advertisement
Related Manuals for Robic SC-554
Summary of Contents for Robic SC-554
- Page 1 SC-554 Instructions SC-554 Thank you for buying the Robic SC-554. Your purchase brings you a world class timer with a vast array of advanced timekeeping functions. Please take a few moments to review this operating guide, so that you may become familiar with the SC- 554’s many capabilities and how you can best access them for your maximum benefit.
- Page 2 Page x of y Rev 02 05/04/05 Each option offers these functions: 1/100 Second Resolution to 24 Hours Recall of the previous 30 time readings Automatic Lap/Split Counter . . . up to 999 readings Memory Recall Can be Presented in Either Ascending (1,2,3. . .) or Descending ( . . . 3,2,1) Order Fastest and Average Lap Time Display STROKE RATE CALCULATOR Used for swimming or rowing activities...
- Page 3 The Hourly Chime can be armed to sound one (1) beep at the top of each hour. The Chime indicator (♠ ) will appear when the chime is armed. While your SC-554 is in NORMAL TIME mode, press “C” to arm, or disarm your alarm and chime. The sequence is:...
-
Page 4: Memory Recall Direction
Press “B” to take a Lap Time. The previous Lap Time will appear in the upper row of the display and the current Lap Time will build up from zero in the bottom row. The SC-554 will take up to 999 lap times. - Page 5 Upon releasing the frozen time display, the LAP COUNTER will increase by one (1) to indicate the second segment is now displayed. The SC-554 will take up to 999 Dual Split readings. You may recall up to the previous 30 at any time by pressing “F”.
- Page 6 “E”. “SET” and “DIST” indicators disappear. Please note: (1) The SC-554 returns to the reset position if no pushbuttons are pressed within 15 seconds. (2) If hundreds and tens digits have no value entered, they will disappear after you have entered the...
- Page 7 Lap Time will appear in the lower row of the display, Lap Speed in the upper row and Lap Number in the Lap Counter. Continue to press “B” to take as many lap readings as necessary. The SC-554 will record up to 999 laps.
- Page 8 “MAX” indicator will appear, as will the lap number, speed and time of the fastest lap. To return to any previous function, press “C” or the SC-554 will automatically do so after 15 seconds. The AVERAGE SPEED and TIME of multiple laps, up to 999, can be computed and displayed at any time, by pressing “D”, again.
- Page 9 NEVER include a personal item, such as a watchband, with the repair request. Robic offers a complete line of the world's finest timers and stopwatches for all your needs. Please call at (203) 264-2702 for a free catalog.
