CD9925
Stereo CD Radio Cassette
Please read this manual before use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CD9925 and is the answer not in the manual?

Questions and answers

Related Manuals for Roberts CD9925

Summary of Contents for Roberts CD9925

  • Page 1 CD9925 Stereo CD Radio Cassette Please read this manual before use...

  • Page 2: Table Of Contents

    Important Information ............1 Headphones ..............18 Controls ................2-5 General ................19 Battery Operation ............... 6 Mains Supply ..............19 Mains Operation ..............6 Specification ..............20 Listening to the radio - FM ..........7 Guarantee ................ 22 Listening to the radio - Medium and Long wave ....8 Compact discs ..............

  • Page 3: Controls

    Controls (Front) 1. CD previous track button 5. Repeat indicator 9. Stop button 2. CD next track button 6. CD display 10. Play/pause button 3. CD mode button 7. Play/pause indicator 11. Cassette door 4. Operation LED 8. Program indicator If you need any further advice, please call our Technical Helpline on :- 020 8758 0338 (Mon-Fri)
  • Page 4 Controls (Top) 12. Volume control 19. CD lid 13. Deep bass boost button 20. Record button 14. Function switch 21. Play button 15. Telescopic aerial 22. Rewind button 25 24 23 22 21 20 16. FM stereo indicator 23. Fast forward button 17.
  • Page 5 Controls (Right side) 26. Tuning control 27. Beat cut and FM mono/stereo switch (on rear) 28. Battery compartment (on rear) If you need any further advice, please call our Technical Helpline on :- 020 8758 0338 (Mon-Fri)
  • Page 6 Controls (Left side) 29. Mains socket (on rear) 30. Headphone socket...

  • Page 7: Battery Operation

    Battery operation 1. Remove the Battery cover on the rear of your CD radio cassette by pushing the catches in the direction of the arrows. 2. Insert eight LR14 (C size) batteries into the spaces in the compart- ment. Take care to ensure all batteries are inserted with the correct polarity as shown inside the battery compartment.

  • Page 8: Listening To The Radio - Fm

    Listening to the radio - FM 1. Set the Function switch to the 'Radio' position. The Operation indicator will light up. 2. Select 'FM' using the Waveband switch. 3. Adjust the Volume control until a hissing sound is heard. 4. The Telescopic aerial which is only operational on FM, should be fully extended.

  • Page 9: Listening To The Radio - Medium And Long Wave

    Listening to the radio - Medium and Long wave 1. Set the Function switch to the 'Radio' position. The Operation indicator will light up. 2. Select 'MW' or 'LW' using the Waveband switch. 3. Adjust the Volume control until a hissing sound is heard. 4.

  • Page 10: Compact Discs

    Compact discs Use only Digital Audio CDs which have the symbol. Never write on a CD or attach any sticker to the CD. Always hold the CD at the edge and store it in its box after use with the label facing up. To remove dust and dirt, breathe on the CD and wipe it with a soft, lint- free cloth in a straight line from the centre towards the edge.

  • Page 11: Playing A Cd

    Playing a CD 1. Press the Play/Pause button to start playback. The Play/Pause indicator will light up and the display shows the track number. 2. Set the Volume and Deep bass boost controls to the required settings. 3. To pause playback press the Play/Pause button. The Play/Pause indicator will flash.

  • Page 12: Playback Modes

    Playback modes The Mode button allows you to select different CD playback modes in the following order:- REPEAT1 REPEAT ALL RANDOM NORMAL These modes can only be selected or changed during CD playback. 1. Whilst the CD is playing press the Mode button once to repeat the current track.

  • Page 13: Programmed Play

    Programmed play By programming the player you can play up to 21 tracks in any desired order. 1. Whilst the CD is in STOP, press the Mode button. The Programme indicator will start to flash and the display will show ‘01’. 2.

  • Page 14: Adding Tracks To A Programme

    Adding tracks to a programme 1. Whilst the CD is in STOP, press the Mode button repeatedly until the display shows the first empty memory location (the largest number) 2. You can now add tracks (maximum 21) to the sequence as described earlier.

  • Page 15: Listening To Cassette Tapes

    Listening to cassette tapes 1. Set the Function switch to the 'Tape' position. 2. Press the Stop eject button to open the Cassette compartment. 3. Insert a pre-recorded cassette with the tape surface uppermost and the side with the desired recording facing towards you. 4.

  • Page 16: Recording From The Radio

    Recording from the Radio 1. Set the Function switch to the 'Radio' position. 2. Tune in to the desired station. 3. Adjust the Volume control to suit your requirements. 4. Insert a blank cassette with the tape surface uppermost and the side you wish to record on facing towards you.

  • Page 17: Recording From Cd

    Recording from CD 1. Set the Function switch to the 'CD' position. 2. Insert a CD into the compartment. 3. Insert a blank cassette with the tape surface uppermost and the side you wish to record on facing towards you. 4.

  • Page 18: Preventing Accidental Erasure

    Preventing accidental erasure Safety tab side A Safety tab side B 1. To safeguard your recordings against accidental erasure, break off the appropriate tab on the cassette as shown . 2. There is one tab for each side of the cassette. This will prevent the Record button from being pressed.

  • Page 19: Headphones

    Headphone socket A 3.5mm Headphone Socket located on the left side of you CD radio cassette is provided for use with either headphones or an earpiece. Inserting a plug into the socket automatically mutes the internal loud- speaker. If you need any further advice, please call our Technical Helpline on :- 020 8758 0338 (Mon-Fri)

  • Page 20: General

    L Mains supply or coloured RED. The CD9925 will operate from a supply of AC 230volts, 50Hz only. For your convenience this product is supplied with a plug which is fitted with a fuse of the appropriate rating. If the plug supplied is not suitable for your socket outlet, it should be removed by unscrewing the plug top, the terminal screws and removing the cable.

  • Page 21: Specification

    Built-in Ferrite aerial Frequency Coverage Built-in Ferrite aerial 87.5-108MHz 522- 1620kHz 144- 281kHz ROBERTS RADIO LIMITED PO BOX 130 MEXBOROUGH SOUTH YORKSHIRE S64 8YT The Company reserves the right to amend the specification without notice. If you need any further advice, please call our Technical Helpline on :-...
  • Page 22 Notes:...

  • Page 23: Guarantee

    In the event that it is not possible to return the instrument to the Roberts' dealer from whom it was purchased, please contact Roberts Radio Technical Services department at the address shown on the rear of this manual before taking further action.
  • Page 24 ROBERTS RADIO TECHNICAL SERVICES DEPARTMENT 97-99 Worton Road Isleworth Middlesex TW7 6EG Technical Helpline:- 020 8758 0338 (Mon-Fri) Issue 1...
