Roberts Swallow CD9959 Manual

Stereo cd radio
Hide thumbs Also See for Swallow CD9959:
Table of Contents

Advertisement

Quick Links

See also: User Manual
CD9959
Stereo CD Radio
Please read this manual before use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Swallow CD9959 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Roberts Swallow CD9959

Summary of Contents for Roberts Swallow CD9959

  • Page 1 CD9959 Stereo CD Radio Please read this manual before use...

  • Page 2: Table Of Contents

    Contents Contents ... 2 Controls ... 3-5 Battery Operation ... 6 Mains Operation ... 6 Listening to the radio - FM ... 7 Listening to the radio - Medium and Long wave ... 8 Compact discs ... 9 Inserting a CD ... 10 Playing a CD ...

  • Page 3: Controls

    Controls 1. Function switch 2. Tuning control 3. Dial pointer If you need any further advice, please call our Technical Helpline on :- 020 8758 0338 (Mon-Fri) 1000 1300 1600 FM STEREO RADIO 4. Telescopic aerial 5. FM Stereo indicator 6.
  • Page 4 Controls 7. LED Display 8. BBS button 9. Repeat indicator 10. On indicator 11. Open/Close button 12. Program indicator 13. Program button PROGRAM REPEAT PLAY/PAUSE PROGRAM VOLUME REPEAT STOP PLAY/PAUSE 17 16 15 14. Play/Pause indicator 15. F.Skip button 16. B.Skip button 17.

  • Page 5: Controls

    Controls 21. Mains power socket 22. Handle 23. Headphone socket If you need any further advice, please call our Technical Helpline on :- 020 8758 0338 (Mon-Fri) 24. FM Mode switch 30. Battery compartment (on underside)

  • Page 6: Battery Operation

    Battery operation 1. Slide the battery cover catch in the direction of the arrow. Open the battery cover. 2. Fit six LR14 (C size) batteries into the spaces in the compartment. Take care to ensure all batteries are inserted with the correct polarity as shown inside the battery compartment.

  • Page 7: Listening To The Radio - Fm

    Listening to the radio - FM 1. Switch on your CD radio by sliding the Function switch to the 'Radio' position. The On indicator will light. 2. Slide the Waveband switch to the 'FM' position. 3. Tune in to the desired station by rotating the Tuning control . The station frequency is indicated in the dial scale.

  • Page 8: Listening To The Radio - Medium And Long Wave

    Listening to the radio - Medium and Long wave 1. Switch on your CD radio by sliding the Function switch to the 'Radio' position. The On indicator will light. 2. Select the required waveband by sliding the Waveband switch to the desired position.

  • Page 9: Compact Discs

    Your CD clock radio can playback CD-DA format audio CD-R/CD-RW discs that have been finalised* upon completion of recording. Your CD clock radio may fail to playback some CD-R/CD-RW discs due to poor recording of the CD-R/CD-RW disc. *Finalising enables a CD-R/CD-RW disc to playback on audio CD players such as your CD clock radio.

  • Page 10: Inserting A Cd

    Inserting a CD 1. Set the Function switch to 'CD'. The On indicator will light up and '--' will flash on the display. 2. To open the CD compartment, push the Open/Close button on the CD door . Press the CD onto the spindle until it clicks into place. Close the CD door .

  • Page 11: Playing A Cd

    Playing a CD 1. Press the Play/Pause button to start playback. The Play/Pause indicator will light up and the display will show the track number. 2. Set the Volume control to the required setting. Press the BBS button to activate the Bass Boost System. 3.

  • Page 12: Selecting A Track

    Selecting a track 1. Whilst the CD is playing, press either the F.skip or B.skip buttons to change to the desired track, the track number appears in the display. 2. You can also skip tracks when the player is in stop mode. Skip to the desired track using the F.skip or B.skip buttons.

  • Page 13: Cd Repeat Mode

    CD repeat mode 1. Whilst the CD is playing press the Repeat button once to repeat the current track. The Repeat indicator will flash. 2. Press the Repeat button again to repeat all tracks on the CD. The Repeat indicator will light up. 3.

  • Page 14: Programmed Play

    Programmed play By programming the player you can play up to 20 tracks in any desired order. 1. Whilst the CD is in Stop mode, press the Program button . The display will flash ‘01’ once before flashing '00'. The Program indicator will flash.

  • Page 15: Editing A Programme

    Editing a programme 1. Whilst the CD is in Stop mode, repeatedly press the Program button to step through the tracks programmed until you find the desired counter number. The display will flash the counter number (‘03’) once before flashing '00'. The Program indicator will flash. 2.

  • Page 16: Checking A Programme

    Checking a programme 1. Whilst the CD is in Stop mode, repeatedly press the Program button to step through the tracks programmed. The Display will flash each programmed track number in sequence. 2. Resume play by pressing the Play/Pause button . Erasing a programme 1.

  • Page 17: Headphones

    Headphones A 3.5mm Headphone Socket located on the left side of the unit is provided for use with either headphones or an earpiece. Inserting a plug into the socket automatically mutes the internal loudspeaker. If you need any further advice, please call our Technical Helpline on :- 020 8758 0338 (Mon-Fri)

  • Page 18: General

    General Do not allow this unit to be exposed to moisture (e.g. dripping or splashing) or to temperatures exceeding 70 degrees centigrade. It is recommended that the FM band be used wherever possible as better results in terms of quality and freedom from interference will usually be obtained than on the MW/LW bands.

  • Page 19: Specification

    Specifications Power Requirements Mains AC 230 volts, 50Hz Batteries 6 x LR14 (C size) Frequency Coverage 88 -108MHz 525- 1605kHz 150- 285kHz The Company reserves the right to amend the specification without notice. If you need any further advice, please call our Technical Helpline on :- 020 8758 0338 (Mon-Fri) Circuit Features only...
  • Page 20 Notes:...

  • Page 21: Guarantee

    In the event that it is not possible to return the instrument to the Roberts' dealer from whom it was purchased, please contact Roberts Radio Technical Services department at the address shown on the rear of this manual before taking further action.
  • Page 22 ROBERTS RADIO TECHNICAL SERVICES 97-99 Worton Road Isleworth Middlesex TW7 6EG Technical Helpline:- 020 8758 0338 (Mon-Fri) Issue 1...
