Intel
440BX Scalable
Performance Board
Development Kit Manual
July 2001
Order Number: 273318-007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 440BX and is the answer not in the manual?

Questions and answers

Summary of Contents for Intel 440BX

  • Page 1 ® Intel 440BX Scalable Performance Board Development Kit Manual July 2001 Order Number: 273318-007...
  • Page 2 No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel’s Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right.
  • Page 3: Table Of Contents

    3.2.11 IDE Support ......................23 3.2.12 Floppy Disk Support ....................23 3.2.13 Keyboard/Mouse....................23 3.2.14 USB ........................24 3.2.15 RS232 Ports ......................24 3.2.16 IEEE 1284 Parallel Port ..................24 3.2.17 PCI Connectors .....................24 3.2.18 ISA Connectors......................24 ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 4 Custom Configuration Setup Screen .................. 46 Shadow Configuration Setup Screen.................. 47 Standard Diagnostics Routines Setup Screen..............48 Start System BIOS Debugger Setup Screen ..............48 Start RS232 Manufacturing Link Setup Screen ..............49 ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 5 15 AGP Slot (J13)..........................36 16 Default Jumper Settings ......................37 17 IDE0-IDE3 Drive Assignments....................45 18 Baseboard Bill of Materials ......................59 19 PGA370 Socket Processor Assembly Bill of Materials ...............64 20 Key Components Bill of Materials....................67 ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 6: Kits Upgraded To Ship With 850 Mhz Celeron Processor (Replacing 566 Mhz

    Added support for the 700 MHz Pentium III processor and the 566 MHz Celeron™ processor. Changed document name. Removed references to specific video adapter card. 1/00 First publication of this document. ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 7: About This Manual

    Appendix B, “Bill of Materials” - This appendix contains the bill of materials for the evaluation board. Appendix C, “Schematics” - This appendix contains schematics for selected connectors and subsystems for the evaluation board. ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 8: Text Conventions

    CS0#, CS1#, CS2#, and so on; they are collectively called CSn#. A pound symbol (#) appended to a signal name identifies an active-low signal. Port pins are represented by the port abbreviation, a period, and the pin number (e.g., P1.0). ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 9: Technical Support

    Technical Support 1.3.1 Electronic Support Systems Intel’s site on the World Wide Web (http://www.intel.com/) provides up-to-date technical information and product support. This information is available 24 hours per day, 7 days per week, providing technical information whenever you need it.
  • Page 10: Related Documents

    ® Intel Celeron™ Processor Specification Update 243748 ® Intel 440BX AGPset / PGA370 Scalable Performance Board Design Guide 273296 Intel Architecture Software Developer’s Manual, Volume 1: Basic Architecture 243190 Intel Architecture Software Developer’s Manual, Volume 2: Instruction Set Reference 243191 Intel Architecture Software Developer’s Manual, Volume 3: System Programming Guide...
  • Page 11: Getting Started

    Overview The evaluation board provided in your kit is a scalable board design. It supports 440BX AGPset- based designs with several different Intel processors and core voltages ®...
  • Page 12: Baseboard Features

    — One AGP connector — Standard ATX power supply connector • Miscellaneous features include: — On-board post-code debugger (Port 80) — Reset push button — Stand-off feet for table-top operation ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 13: Included Hardware

    This product offers a winning combination of superior OEM configurability and superior embedded features. Intel selected Embedded BIOS as the standard pre-installed pre-boot firmware for this design. The following features of Embedded BIOS have been enabled in this Intel development kit: •...
  • Page 14: Qnx Software Systems, Ltd

    Console redirection • Manufacturing mode 2.3.2 QNX Software Systems, Ltd. The QNX Real Time Operating System for Intel Architecture comes pre-loaded on the hard disk included in your kit. • Small memory footprint of the QNX operating system with microGUI •...
  • Page 15: Before You Begin

    You will have to install the correct drivers for video adapters other than the one provided. Network Adapter An Intel Pro 100+ Adapter network adapter is supplied with your kit. Drivers for this adapter are also provided. The evaluation board supports all standard PCI and ISA compatible network cards.
  • Page 16: Setting Up The Evaluation Board

    J14 J15 Floppy Connector Fan Power Connector Processor Assembly J21 J22 U12 U13 PGA370 Post Socket Code Debugger IDE2 IDE1 Debugger Port Battery IDE Connectors SDRAM Special Mounting Holes DIMM Slots ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 17 Warning: Do not remove the nuts from these three holes! This will detach the processor assembly from the baseboard, and Intel will no longer support the evaluation board. Note: The evaluation board is not an ATX form factor. 5. Connect desired storage devices to the evaluation board: The evaluation board supports Primary and Secondary IDE interfaces that can each host one or two devices (master/slave).
  • Page 18: Configuring The Bios

    Setup program to modify BIOS settings and control the special features of the system. Setup options are configured through a menu-driven user interface. Chapter 5, “BIOS Quick Reference” contains a description of BIOS options. BIOS updates may periodically be posted to Intel’s Developers’ web site at http://developer.intel.com/. ®...
  • Page 19: Theory Of Operation

    PIIX4E Bus Master IDE I/O APIC XD Bus ® ISA Bus Intel Boot Flash ISA Connectors PS/2 Mouse IEEE 1284 Parallel Port SMC FDC37B787 PS/2 Keyboard COM1 SuperI/O* Floppy Drive COM2 ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 20: System Operation

    The processor assembly is attached to the baseboard at the factory. Do not remove the processor assembly from the baseboard. Intel will not support the processor assembly or the baseboard if any portion of the assembly is removed by the customer.
  • Page 21: Intel Celeron™ Processor

    Intel Celeron™ Processor The Intel Celeron Processor is offered at 300A, 366, 433, 566, 733 and 850 MHz. All processors have a processor system bus speed of 66 MHz, except for the 850 MHz version, which runs at 100 MHz. Refer to the processor datasheet for processor core voltage data (see “Related Documents”...
  • Page 22: Accelerated Graphics Port (Agp) Interface

    4 Mbytes to 256 Mbytes of 4-Mbit, 16-Mbit and 64-Mbit DRAM and SRAM technology (both symmetrical and asymmetrical). Parity is not supported. One 100 MHz, 32-Mbyte SDRAM DIMM is included in the kit. ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 23: Power

    The RTC and NVRAM are contained within the 82371EB PIIX4E device. CMOS NVRAM backup is provided by a 3-V lithium-ion battery. 3.2.10 Legacy I/O Support for legacy I/O functions is provided by the Intel 82371EB PIIX4E and the SMC FDC37B787 SuperI/O* device. 3.2.11 IDE Support The evaluation board supports both a primary and secondary IDE interface via two 40-pin IDE connectors.
  • Page 24: Usb

    USB and ISA bus. The processor side bus clock runs at 66 or 100 MHz. The PCI clocks run at 33 MHz. This device is capable of spread spectrum clocking. If spread spectrum clocking is enabled, a 0.5% down spread will be introduced in the processor and PCI clocks. ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 25: Interrupt Map

    BIOS C8000-DFFFF Available expansion BIOS area (Flash disk memory window) A0000-C7FFF Off-board video memory and BIOS 9FC00-9FFFF Extended BIOS Data (movable by QEMM, 386MAX) 80000-9FBFF 127K Extended conventional 00000-7FFFF 512K Conventional ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 27: Hardware Reference

    The processor assembly is attached to the baseboard at the factory. Do not remove the processor assembly from the baseboard. Intel will not support the processor assembly or the baseboard if any portion of the assembly is removed by the customer.
  • Page 28: Post Code Debugger

    IDSEL signal of each PCI device. Table 4 shows the mapping of PCI devices. Table 4. PCI Device Mapping Device Address Line PCI Device Number PIIX4E AD18 PCI Slot 0 (J7) AD28 PCI Slot 1 (J8) AD29 PCI Slot 2 (J9) AD30 ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 29: Connector Pinouts

    +12 V 3.3 V 3.3 V –12 V –12 V Ground PS_ON# Soft-off control Ground Ground Ground –5 V –5 Volts +5 V +5 V VCC +5 V +5 V VCC ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 30: Itp Debugger Connector

    PREQ3# BSEN# PRDY3# PREQ0# BCLK 4.5.3 Stacked USB P0 is the bottom connector. P1 is on top. Table 7. USB Connector Pinout (J2) P0 Signals P1 Signals VCC0 VCC1 GND0 GND1 ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 31: Mouse And Keyboard Connectors

    Data Bit 2 SLCT IN# Data Bit 3 Ground Data Bit 4 Ground Data Bit 5 Ground Data Bit 6 Ground Data Bit 7 Ground ACK# Ground Busy Ground Paper end Ground SLCT ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 32: Serial Ports

    Host Data 15 Ground DRQ3 Ground I/O Write# Ground I/O Read# Ground IOCHRDY BALE DACK3# Ground IRQ14 IOCS16# Addr 1 Ground Addr 0 Addr 2 Chip Select 0# Chip Select 1# Activity Ground ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 33: Floppy Drive Connector

    Drive Select A# Ground Motor Enable B# Ground DIR# Ground STEP# Ground Write Data# Ground Write Gate# Ground Track 00# Ground Write Protect# Ground Read Data# Ground Side 1 Select# Ground Diskette Change# ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 34: Pci Slot Connector

    REQ# Reserved AD30 AD31 3.3V AD29 CBEO# AD28 3.3 V AD26 AD27 3.3 V AD25 AD24 3.3 V IDSEL CBE3# 3.3V AD23 AD22 AD20 AD21 REQ64# ACK64# AD19 AD18 3.3 V ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 35: Isa Slot Connector

    DREQ0 SA15 DREQ3 MEMW# DACK5 SA14 DACK1# DREQ5 SA13 DREQ1 DACK6# SA12 REFRESH# SD10 DREQ6 SA11 SYSCLK SD11 DACK7# SA10 IRQA7 SD12 DREQ7# IRQA6 SD13 IRQA5 SD14 MASTER# IRQA4 SD15 IRQA3 ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 36: Agp Connector

    2. IDSEL# is not a pin on the AGP connector. AGP graphics components should connect the AD16 signal to the 3. 3 volt IDSEL# function internal to the component. 3. All 3.3 volt cards leave the TYPEDET signal open. All 1.5 volt cards tie this signal hard to ground. ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 37: Jumpers

    This jumper is used to control the state of the ATX power supply. When this jumper is removed, the power supply will be turned off. Placing the jumper in the 2-3 position will turn the power supply The 1-2 position is reserved and should not be used. ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 38: Flash Bios Vpp Select (J21)

    There are two push button switches on the evaluation board labeled S1 and S2. • S1 is non-functional and reserved for future use. • S2 is the reset button. Press S2 to force a hardware reset of the system. ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 39: In-Circuit Bios Update

    Hardware Reference In-Circuit BIOS Update The BIOS can be upgraded in-circuit. BIOS updates may periodically be posted to Intel’s Developers’ site at http://www.intel.com/design/. To reprogram the BIOS: 1. Set Jumper J21 and Jumper J22 to the 1-2 position on the evaluation platform.
  • Page 41: Bios Quick Reference

    General Software, Inc. for integration with new designs. General Software may be reached at (800) 850-5755, on the web at http://www.gensw.com, or via email at sales@gensw.com. BIOS updates may periodically be posted to the Intel Developers’ web site at http:// developer.intel.com/. BIOS and Pre-Boot Features The system’s pre-boot environment is managed with an adaptation of Embedded BIOS from...
  • Page 42: Bios Post Pre-Boot Environment

    OEMs can modify the look-and-feel of POST with the Embedded BIOS adaptation kit. While the demonstration BIOS looks and feels like a desktop PC, it is possible to eliminate messages, sounds, delays, to make the POST effectively invisible. ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 43: Setup Screen System

    Floppy Drive Types and IDE Drive Geometry sections. Finally, you’ll need to configure the boot sequence in the middle of the screen. Once these selections have been made, your system is ready to use. ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 44: Configuring Drive Assignments

    Floppy0 refers to the first floppy disk drive on the drive ribbon cable (normally drive A:), and Floppy1 refers to the second drive (drive B:). ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 45: Configuring Ide Drive Types

    POST, but then translate the geometry according to the Phoenix CHS convention. Using this type on a drive previously formatted with LBA or Physical geometry might show data as being missing or corrupted. ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 46: Configuring Boot Actions

    Integrated BIOS Debugger should use standard keyboard and video or RS232 console redirection for interaction with the user. If no video is available, the debugger is always redirected. ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 47: Shadow Configuration Setup Screen

    Normally, shadowing should be enabled at C000/C400 (to enhance VGA ROM BIOS performance), and then E000-F000 should be shadowed to maximize system ROM BIOS performance. Figure 7. Embedded BIOS Shadow Setup Screen ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 48: Standard Diagnostics Routines Setup Screen

    Once invoked, the debugger will display the debugger prompt: EB42DBG: and await debugger commands. To resume back to the Setup Screen main menu, type the following command, which instructs the debugger to “go”: EB42DBG: G <ENTER> ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 49: Start Rs232 Manufacturing Link Setup Screen

    ROM is available for the BIOS to detect. In the absence of any video support, the BIOS automatically switches its keyboard and screen functions to serial I/O over COM1 on the board. The hardware connection to the host computer requires a null modem cable. ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 50: Ce-Ready Windows Ce Loader

    It supports a DOS SYMDEB-style command line interface, and can be used on the main console’s keyboard and screen, or over a redirected connection to a terminal program (see “Console Redirection” on page 49). ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 51: Integrated Bios Debugger Running Over A Remote Terminal

    To continue, use the “G” command. When Embedded BIOS is adapted by the OEM, the debugger can be removed from the final production BIOS, and superfluous debugging code in the application will not cause the debugger to be invoked. ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 52: Embedded Bios Post Codes

    POST_STATUS_MONOMODE Video in monochrome mode verified. POST_STATUS_COLORMODE Video in color mode verified. POST_STATUS_TOGGLEPARITY Toggle parity before video ROM test. POST_STATUS_INITBEFOREVIDEO Initialize before video ROM check. POST_STATUS_VIDEOROM Passing control to video ROM. ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 53 Issue KB reset command. POST_STATUS_CHECKSTUCKKEYS Check for stuck keys. POST_STATUS_INITCIRCBUFFER Initialize circular buffer. POST_STATUS_CHECKLOCKEDKEYS Check for locked keys. POST_STATUS_MEMSIZEMISMATCH Check for memory size mismatch. POST_STATUS_PASSWORD Check for password or bypass setup. POST_STATUS_BEFORESETUP Password accepted. ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 54 ROM extension returned. POST_STATUS_DISPCONFIG 0b0h Display system configuration box. POST_STATUS_INT19BOOT Call INT 19h bootstrap loader. POST_STATUS_LOWMEMEXH 0b1h Test low memory exhaustively. POST_STATUS_EXTMEMEXH 0b2h Test extended memory exhaustively. POST_STATUS_PCIENUM 0b3h Enumerate PCI busses. ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 55: Embedded Bios Beep Codes

    Exhaustive extended memory test failed. POST_BEEP_CMOS CMOS restart byte test failed. POST_BEEP_ADDRESS_LINE Address line test failed. POST_BEEP_DATA_LINE Data line test failed. POST_BEEP_INTERRUPT Interrupt controller test failed. POST_BEEP_PASSWORD Incorrect password used to access SETUP. ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 57: Pld Code Listing

    + SEL * /AEN * SA19 * SA18 * /SA17 * SA16 * /SA15 * /SA14 CS_DOC.TRST = VCC OX = /IOWR_BAR OX.TRST = VCC SIMULATION SETF /AEN /SA0 /SA1 /SA2 /SA3 /SA4 /SA5 /SA6 /SA7 /SA8 /SA9 IOWR_BAR SETF SA7 IOWR_BAR SETF /IOWR_BAR SETF IOWR_BAR ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 58 SETF /SEL SETF /AEN SETF SEL SETF /SA19 SETF SA19 SETF /SA18 SETF SA18 SETF SA17 SETF /SA17 SETF /SA16 SETF SA16 SETF SA15 SETF /SA15 SETF SA14 SETF /SA14 SETF /SEL ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 59: Bill Of Materials

    Conn,AGP Edge Recept., FOXCONN PC1243K-10 120 pins,AGP-124 2 USB Stack Connectors FOXCONN UB1112C-D3 Part # BIOS FLASH changed in INTEL E28F004B5T60 Memory,TSOP12X20/40S previous VLSI,PIIX4,PCI to IDE &ISA Bridge,324 Intel FW82371EB mBGA,BGA20x20-324 ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 60 C2,C6,C58,C Cap,Tant,100uF, 10V,D T495D107M010A Kemet C84,C88,C8 Case,7343 9,C95, C109 C1,C7,C23,C C68,C74,C7 7-C82, C101,C113,C 115, C141,C158, C163- Chip Capacitor,0.01uF C0603C103J5RA Kemet 173,C177- 50V,CC0603 180, C184- 186,C201- 202,C204,C2 07, C211- 213,C216- 217,C220- C225 ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 61 Resistor,10K,5%,CR0805 117,R123- 124,R127 R1,R3,R88,R Chip Panasonic ERJ6GEYJ153V 89.R90,R91 Resistor,15K,5%,CR0805 Chip Panasonic ERJ6GEYJ220V Resistor,22,5%,CR0805 R10,R12,R1 Chip 3,R14,R39,R Panasonic ERJ6GEYJ221V Resistor,220,5%,CR0805 58,R70 Chip R92-R95 Panasonic ERJ6GEYJ270V Resistor,27,5%,CR0805 R20,R44,R5 Chip Panasonic ERJ6GEYJ272V 7,R71 Resistor,2.7K,5%,CR0805 ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 62 RP25,RP37, Res,Array,SMT,2.7K,5%,EX RP49,RP50, Panasonic EXB38V272JV RP53 Res,Array,SMT,47,5%,EXB- RP57 Panasonic EXB38V470JV RP48 RP5,RP6,RP Res,Array,SMT,4.7K,5%,EX changed Panasonic EXB38V472JV 7, RP48 value in Rev 1.6 Res,Array,SMT,5.6k,5%,EX RP12,RP34 Panasonic IC,Logic,Inverter, Schmitt Philips 74LVC14AD Trigger,SOIC14 ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 63 R8,R15,R16, Chip Panasonic ERJ-6ENF1240V R46,R47 Resistor,124,1%,CR0805 Res,Array,SMT,270,5%,EXB RP38,RP40 Panasonic EXB38V271JV R300-R307 Chip Resistor,0,5%,CR0805 Panasonic ERJ6GEY0R00V Chip Panasonic ERJ6GEYJ681V Resistor,680,5%,CR0805 Chip R308 Panasonic ERJ6GEYJ330V Resistor,33,5%,CR0805 Chip Resistor,0 Ohm R309 Panasonic ERJ6GEY0R00V Shunt,5%,CR0805 ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 64: Pga370 Socket Processor Assembly Bill Of Materials

    R70,R78,R88,R92 10K, CR0805 PANASONIC ERJ-6GEYJ103V RP64 10K, EXB-V PANASONIC EXB-V8V103JV 110 ohm 1%, R97,R101 PANASONIC ERJ-6ENF1100V CR0805 R57,R58,R59 150 1%, CR0805 PANASONIC ERJ-6ENF1500V R47,R96,R98,R108, 150 ohm, CR0805 PANASONIC ERJ-6GEYJ151V R109, R110 ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 65 Qty per board R50,R51 47 ohm, CR0805 PANASONIC ERJ-6GEYJ470V corrected 4700pF, 50V, KEMET - C117 PANASONIC ECJ-1VB1H472K CC0603 C0603C472K5R 470uF, 16V, C127,C130 PANASONIC EEU-FC1C471L PCAPR200-300 51 ohm 5%, R100 PANASONIC ERJ-6GEYJ510V CR0805 ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 66 CON3, FAN CONNECTOR, 3 2302-6111 PIN HEADER CON4, 644518-4 644518-4 ITPM 104078-4 MAX1617, MAXIM MAX1617MEE QSOP16 MTD3055V, U12,U13 MOTOROLA MTD3055V TO252 S370-256 916783-2 SC1185A, SO24W SEMTECH SC1185ACSW SUD50N03-07, U10,U11 SILICONIX SUD50N03-07-T4 TO252 ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 67: Key Components Bill Of Materials

    NOTE: This BOM does not include items such as mounting hardware, packaging material, documentation, etc., because these items are development kit specific and subject to change with no prior notice to the customer. 1. Shipped exclusively with kit: EIACEL18FMBDVKT 2. Shipped exclusively with kit: EIACEL25FMBDVKT ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 69: Schematics

    Schematics Schematics are provided for the following items listed below. Schematics are available from the Intel Developer’s web site in OrCAD* (version 9.0 or later) and PDF format. Baseboard: • Revision History • Block Diagram • Mini-PCI Connector (Not Populated) •...
  • Page 70 Schematics • 440BX Memory Interface • Connectors • GTL+ Termination • Bus Ratio, Thermal, ITP • Voltage Regulator • Layout Guidelines ® Intel 440Bx Scalable Performance Board Development Kit Manual...
  • Page 78 VDDAPIC VDDCPU VDDCPU AVDD AVDD VDDREF VDDUSB VDDPCI VDDPCI...
  • Page 84 VCCSUS VCCSUS VCCSUSB VSSUSB VCCP VCCP VCCP VCCP VCCP VCCP VCCP VCCP VCCP...
  • Page 86 SMD250-002 PME#/IRQ9 BUTTON_IN POWERON VBAT AVSS...
  • Page 98 INTERFACE PCI ARB & PWR INTERFACE...
  • Page 100 VIA4 VIA3 VIA2 VIA1 VIA4 VIA3 VIA2 VIA1 VIA4 VIA3 VIA2 VIA1 VIA4 VIA3 VIA2 VIA1...
  • Page 102 1.004 0.794 0.700 0.60 0.449 0.284 0.100...
  • Page 105: Index

    J2, ITP connector 30 ITP debugger 22 J2, USB connector 30 connector 30 J3, parallel port 31 J4, serial ports 32 JP1, floppy connector 33 JP4/JP3, IDE connector 32 Jumpers default settings 37 ® Intel 440BX Scalable Performance Board Development Kit Manual Index-105...
  • Page 106 PGA370 Socket 20 Windows CE 50 PLD 57 World Wide Web 9 Post Code Debugger 24 www.intel.com 9 POST codes 41 Power connector 29 Power LEDs 18 Power supply 15 connecting 18 ® Index-106 Intel 440BX Scalable Performance Board Development Kit Manual...
