About the iMcV-Gigabit™

The SNMP-manageable iMcV-Gigabit module provides a single conversion between
1000 Base-T twisted pair and 1000 Base-SX/LX fiber. Each iMcV-Gigabit includes
one RJ-45 connector and one pair of SC fiber optic connectors. iMcV-Gigabit
modules install in any modular, SNMP-manageable iMediaChassis and iMediaCenter
series chassis as well as the MediaChassis series, which is unmanaged.
The iMcV-Gigabit is also available in a single-strand fiber version that allows two
wavelengths to share one fiber strand—Full-Duplex data travels on different
wavelengths (1310 nm and 1550 nm)—doubling the capacity of fiber. Also, one RJ-
45 connector and one SC fiber connector are included.
iMcV-Gigabit is part of the iMcV series. Information for other iMcV modules can be
found in their respective manuals and on the IMC Networks Web site at:
http://www.imcnetworks.com/support/.
All iMcV-Gigabit modules, including 1300 multi-mode and 1310 single-mode
(TX/LX), 850 nm multi-mode fiber (TX/SX) and single-strand versions (TX/SSLX) will be
referred to as iMcV-Gigabit throughout this guide except where differences need to
be indicated.
NOTE
