RCA RP5605 User Manual

v6.0 (1.0.6.0) (EN/F)
user manual
guide de l'utilisateur
RP5605R
EN/F
It is important to read this user manual prior to using your new product for the fi rst time.
Nous vous recommandons de lire ce manuel d'instructions avant d'utiliser votre nouveau
produit pour la première fois.
For your records
WARNING: The battery (battery or
batteries or battery pack) shall not
In the event that service should be
be exposed to excessive heat such as
required, you may need the model
sunshine, fi re or the like. number and the serial number. In
the space below, record the date
Ecology and place of purchase and the serial
number:
Help protect the environment - we
Model No.:
recommend that you dispose of
Date of Purchase:
used batteries by putting them into
Place of Purchase:
specially designed receptacles.
Serial No.:
Service information
This product should be serviced
only by those specially trained in
appropriate servicing techniques.
For instructions on how to obtain
service, refer to the warranty
included in this user manual.
Technical information
Product: CD/Clock Radio
Brand: RCA
Model: RP5605, RP5605R
Power Supply: 120V ~ 60Hz
Power Consumption: 13 Watts
General controls
Top view
– stops CD playback
– turns on the unit from CD mode;
pauses or resumes CD playback
SLEEP – activates the Sleep function
CLOCK SET – activates clock time
setting mode
WAKE TIME – activates wake time
setting mode; checks current wake
time
WAKE MODE – activates wake
function and changes wake mode
SNOOZE – turns off the wake
function temporarily; cancels the
sleep function
RADIO ON – turns on the radio;
selects the radio from other modes
OFF – turns off the unit; turns off the
wake function and sleep mode
/ – sets clock or wake time;
skips to previous or next CD track
during CD playback
CD player
Listening to CD
1. Lift open the CD compartment
• If disc is paused for
door.
more than 5 minutes,
the CD player will
resume to stop mode
automatically.
• If disc is stopped in the CD
mode for more than 30
minutes without further
operations, the unit will turn
off automatically.
2. Insert a disc and close the door.
3. Press to select CD mode and
start CD playback.
• Press to pause playback and
press again to resume.
4. Adjust volume to your desired
level.
5. Press or to skip backward
or forward a track. Press and
hold to search through a track.
6. Press to stop playback.
7. Press RADIO ON to listen to the
radio or OFF to turn off the unit.
Warranty information
Warranty information
incurred for installation, removal
12 Month Limited Warranty or reinstallation of product, to
Applies to RCA Audio/Video corruptions caused by computer
Products viruses, spyware or other
• AUDIOVOX ELECTRONICS CORP. malware, to loss of media, fi les,
(the Company) warrants to the data or content, or to damage to
original retail purchaser of this tapes, discs, removable memory
devices or cards, speakers,
product that should this product
accessories, computers, computer
or any part thereof, under
peripherals, other media players,
normal use and conditions, be
home networks or vehicle
proven defective in material or
electrical systems.
workmanship within 12 months
from the date of original • This Warranty does not
purchase, such defect(s) will apply to any product or
be repaired or replaced with part thereof which, in the
reconditioned product (at the opinion of the Company, has
Company's option) without suffered or been damaged
charge for parts and repair labor. through alteration, improper
• To obtain repair or replacement installation, mishandling,
within the terms of this misuse, neglect, accident, or by
Warranty, the product is to be removal or defacement of the
delivered with proof of warranty factory serial number/bar code
coverage (e.g. dated bill of label(s). THE EXTENT OF THE
sale), specifi cation of defect(s), COMPANY'S LIABILITY UNDER
transportation prepaid, to the THIS WARRANTY IS LIMITED TO
Company at the address shown THE REPAIR OR REPLACEMENT
below. PROVIDED ABOVE AND, IN NO
• This Warranty does not extend EVENT, SHALL THE COMPANY'S
to the elimination of externally LIABILITY EXCEED THE PURCHASE
generated static or noise, to PRICE PAID BY PURCHASER FOR
correction of antenna problems, THE PRODUCT.
loss/interruptions of broadcast • This Warranty is in lieu of
or internet service, to costs all other express warranties
• Do not defeat the safety purpose
of the polarized or grounding-
type plug. A polarized plug
has two blades with one wider
than the other. A grounding
type plug has two blades and
RP5605
a third grounding prong. The
wide blade or the third prong is
provided for your safety. If the
provided plug does not fi t into
your outlet, consult an electrician
for replacement of the obsolete
Some of the following information
outlet.
may not apply to your particular
• Protect the power cord from
product; however, as with any
being walked on or pinched
electronic product, precautions
particularly at plugs, convenience
should be observed during handling
receptacles, and the point where
and use.
they exit from the apparatus.
• Read these instructions.
• Only use attachments/accessories
• Keep these instructions.
specifi ed by the manufacturer.
• Heed all warnings.
• Use only
• Follow all instructions.
with the
• Do not use this apparatus near
cart, stand,
water.
tripod,
• Clean only with dry cloth.
bracket,
• Do not block any ventilation
or table
openings. Install in accordance
specifi ed by
with the manufacturer's
the manufacturer, or sold with
instructions.
the apparatus. When a cart is
• Do not install near any heat
used, use caution when moving
sources such as radiators, heat
the cart/apparatus combination
registers, stoves, or other
to avoid injury from tip-over.
apparatus (including amplifi ers)
• Unplug this apparatus during
that produce heat.
FCC Information
Note: This equipment has been • Consult the dealer or an
tested and found to comply with experienced radio/TV technician
the limits for a Class B digital device, for help.
pursuant to Part 15 of FCC Rules.
These limits are designed to provide Changes or modifi cations not
reasonable protection against expressly approved by Audiovox
harmful interference in a residential could void the user's authority to
installation. This equipment operate the equipment.
generates, uses, and can radiate
radio frequency energy and, if not
installed and used in accordance
with the instructions, may cause
harmful interference to radio
communications.
However, there is no guarantee
that interference will not occur
in a particular installation. If this
equipment does cause harmful
interference to radio or television
reception, which can be determined
by turning the equipment off and
on, the user is encouraged to try to
correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between
the equipment and receiver.
• Connect the equipment into an
outlet on a circuit different from
that to which the receiver is
connected.
Right view
TUNING – selects radio frequency
BAND AM/FM – selects radio band
Left view
+ VOLUME – – adjusts volume
Wake function
Setting wake time Selecting wake source
1. Press WAKE TIME once. The 1. If your desired wake source is
current wake time fl ashes on the radio or CD:
display. • Wake to Radio – select an AM or
FM station (refer to "Radio").
• Wake to CD – insert a CD in the
CD compartment.
2. Set a wake time (refer to
"Setting wake time").
3. Press WAKE MODE repeatedly
2. Press or to set the wake to select a wake source. The
time. The time decrements or indicator lights against the wake
increments will follow by a faster source icons on the right of the
rate when you press and hold display to indicate the currently
the buttons. AM or PM indicator selected wake source:
also lights beside the time on the
display.
3. When fi nished, wait for about 5
seconds or press WAKE TIME to
exit wake time setting mode.
• The Wake to Alarm mode (read
• Once the wake source is selected,
below) will be automatically
the wake function will be
activated whenever the wake
time has been set. activated at the set wake time.
Checking wake time
Press WAKE TIME to show the
current wake time which fl ashes
briefl y on the display.
also have other rights which vary
or liabilities. ANY IMPLIED
from state to state.
WARRANTIES, INCLUDING
ANY IMPLIED WARRANTY
How to make a warranty claim:
OF MERCHANTABILITY,
• If your product is capable of
SHALL BE LIMITED TO THE
storing content (such as an mp3
DURATION OF THIS WRITTEN
player, digital voice recorder,
WARRANTY. ANY ACTION FOR
etc), it is recommended to
BREACH OF ANY WARRANTY
make periodic backup copies of
HEREUNDER INCLUDING ANY
content stored on the product.
IMPLIED WARRANTY OF
MERCHANTABILITY MUST BE If applicable, before shipping a
BROUGHT WITHIN A PERIOD product, make a back up copy
OF 24 MONTHS FROM DATE of content or data stored on
OF ORIGINAL PURCHASE. the device. Also, it is advisable
IN NO CASE SHALL THE to remove any personal
COMPANY BE LIABLE FOR ANY content which you would not
CONSEQUENTIAL OR INCIDENTAL want exposed to others. IT IS
DAMAGES FOR BREACH OF THIS LIKELY THAT CONTENTS AND
OR ANY OTHER WARRANTY. DATA ON THE DEVICE WILL BE
No person or representative is LOST DURING SERVICE AND
authorized to assume for the REFORMATTING. AUDIOVOX
Company any liability other than ACCEPTS NO LIABILITY FOR LOST
expressed herein in connection CONTENT OR DATA, OR FOR THE
with the sale of this product. SECURITY OF ANY PERSONAL
CONTENT OR DATA ON THE
• Some states do not allow
RETURNED DEVICE. Product will
limitations on how long an
be returned with factory default
implied warranty lasts or the
settings, and without any pre-
exclusion or limitation of
loaded content which may have
incidental or consequential
been installed in the originally
damage so the above limitations
purchased products. Consumer
or exclusions may not apply to
will be responsible for reloading
you. This Warranty gives you
data and content. Consumer will
specifi c legal rights and you may

IMPORTANT SAFETY INSTRUCTIONS

PLEASE READ AND SAVE THIS FOR FUTURE REFERENCE
lightning storms or when unused
for long periods of time. • Care should be taken so that
• Refer all servicing to qualifi ed
service personnel. Servicing is
required when the apparatus • Do not attempt to disassemble
has been damaged in any way,
such as power-supply cord or
plug is damaged, liquid has been
spilled or objects have fallen into • The marking information
the apparatus, the apparatus
has been exposed to rain or
moisture, does not operate • To be completely disconnect the
normally, or has been dropped.
ADDITIONAL SAFETY
INFORMATION • Main plug is a disconnect device.
• Apparatus shall not be exposed
to dripping or splashing and no
objects fi lled with liquids, such
as vases, shall be placed on the • The ventilation should not
apparatus.
] • Always leave suffi cient space
around the product for
ventilation. Do not place
product in or on a bed, rug, in • No naked fl ame sources such as
a bookcase or cabinet that may
Portable Cart Warning
prevent air fl ow through vent
openings. • Attention should be drawn to
• Do not place lighted candles,
cigarettes, cigars, etc. on the
product. • The use of apparatus in
• Connect power cord only to AC
power source as marked on the
Before you begin
Battery back-up operation
Install battery as follow:
1. Remove battery compartment
The power failure protection circuit
will not operate unless battery is
installed.
No worry battery backup
When the battery backup functions,
the digital display will not light, 2. Connect a 9-volt battery (not
however, the wake function still
occurs during the power interruption 3. Replace the compartment door.
if remaining battery power is
adequate.
Normal operation will resume after
AC power is restored so you will not
have to reset the time or wake.
Clock
Setting clock
3. When fi nished, wait for about 5
1. Press CLOCK SET once. The
current clock time fl ashes on the
display.
2. Press or to set the clock
time. The time decrements or
increments will follow by a faster
rate when you press and hold
the buttons. AM or PM indicator
also lights beside the time on the
display.
Turning off the wake
Stop the wake function:
function Press OFF. The wake function will
activate again on the following day
Silence the wake function
at the same time.
momentarily:
• With SmartSnooze™, press
SNOOZE, , , or to
turn off the wake function
temporarily for extra sleep time.
Cancel the wake function
completely:
Press WAKE MODE repeatedly until
no indicator lights against the wake
source icons. The set wake time will
not be erased and can be used the
• The wake function will activate
next time when you switch on wake
again when the snooze period (9
wake by alarm
function again.
minutes) is over.
wake by radio
• The snooze period is fi xed and
wake by CD
cannot be changed.
be responsible to restore any
• A new or refurbished unit will be
personal preference settings.
• Properly pack your unit. Include
any remotes, memory cards,
What we will do:
cables, etc. which were originally
Provide you with a new, or at our
provided with the product. option, a refurbished unit. The
However DO NOT return any exchange unit is under warranty
removable batteries, even if for the remainder of the original
batteries were included with product's warranty period.
the original purchase. We
recommend using the original For Canada Customers, please
carton and packing materials. ship to:
• Include evidence of purchase
date such as the bill of sale. Also Audiovox Return Centre
print your name and address and c/o Genco
a description of the defect. Send 6685 Kennedy Road,
via standard UPS or its equivalent Unit#3, Door 16,
to: Mississuaga, Ontario
L5T 3A5
Audiovox Electronics Corp.
Attn: Service Department.
150 Marcus Blvd.
Hauppauge N.Y. 11788
1-877-833-3491
• Insure your shipment for loss or
damage. Audiovox accepts no
liability in case of damage or loss
en route to Audiovox.
• Pay any charges billed to you by
the Exchange Center for service
not covered by the warranty.
product. This equipment is a Class
II or double insulated
objects do not fall into the electrical appliance. It
product. has been designed in
such a way that it does
the cabinet. This product does not require a safety
not contain customer serviceable connection to electrical
components. earth.
is located at the bottom of
Plugging in for power
apparatus.
AC OUTLET POWER SUPPLY:
120 V~60 Hz
power input, the main plug of
The AC power plug
apparatus shall be disconnected
is polarized (one
from the mains.
blade is wider than
the other) and only
The main plug should not be
fi ts into AC power
obstructed OR should be easily
outlets one way.
accessed during intended use.
If the plug will
not go into the outlet completely,
be impeded by covering the
turn the plug over and try to insert
ventilation openings with items
it the other way. If it still does not
such as newspaper, table-cloths,
fi t, contact a qualifi ed electrician to
curtains etc.
change the outlet, or use a different
one. Do not attempt to bypass this
lighted candled should be placed
safety feature.
on the apparatus.
the environmental aspects of
battery disposal.
moderate climates.
Power failure indicator
When AC power is interrupted
door (located at the bottom of
(disconnected) for a short period of
the radio) by applying thumb
time, both time and alarm settings
pressure to the tab on battery
will change (unless battery is
door and then lift the door out
installed). After AC power is restored
and off the cabinet. (reconnected), the Digital Display
will blink to indicate that power was
supplied) to the connector plug. interrupted and you should readjust
the time and alarm settings.
Radio
Switching on
seconds or press CLOCK SET to
Press RADIO ON to turn on the
exit clock setting mode.
radio.
Switching band
Slide the BAND/AM•FM switch on
the right of the unit to select AM or
FM band.
Tuning radio
Rotate the TUNING dial on the right
of the unit to select radio frequency.
Antennas
AM Antenna – A built-in ferrite
rod antenna eliminates the need
for an outside antenna for AM
reception. Rotating the unit slightly
may improve reception of distant
AM stations.
Sleep function
You can set the duration (up to 90
min) before the radio or CD player
turns off automatically.
1. Press SLEEP repeatedly to select
a duration (90, 80, 70, 60, 50,
40, 30, 20, 10min or OFF) before
the radio or CD player turns off
automatically.
• The default sleep time is 60
minutes.
• By default, the radio will be
switched on once SLEEP is
pressed. You may change to
listen to the CD player by
pressing if a disc is loaded.
2. To check the remaining duration
before the unit turns off, press
SLEEP once.
3. To cancel the sleep function,
press SNOOZE or OFF.
shipped to you freight prepaid.
Important battery
precautions
• Any battery may present a risk of
fi re, explosion, or chemical burn
if abused. Do not try to charge
a battery that is not intended to
be recharged, do not incinerate,
and do not puncture.
• Non-rechargeable batteries,
such as alkaline batteries, may
leak if left in your product for
a long period of time. Remove
the batteries from the product if
you are not going to use it for a
month or more.
• If your product uses more than
one battery, do not mix types
and make sure they are inserted
correctly. Mixing types or
inserting incorrectly may cause
them to leak.
• Discard any leaky or deformed
battery immediately. They
may cause skin burns or other
personal injury.
• Please help to protect the
environment by recycling or
disposing of batteries according
to federal, state, and local
regulations.
Alkaline (NEDA 1604A/
IEC 6LR61) battery is
recommended. Carbon-
zinc battery may be used but
memory holding time will be
substantially reduced. Memory
holding time for a fresh alkaline
battery is approximately 8
hours (if radio or alarm are not
operated) which should take
care of short, nuisance-type
AC power failures. To preserve
battery life, the unit should
remain plugged into an AC
outlet. As the battery gets older,
its voltage drops and memory
may be lost. Be sure to replace
the battery periodically. Battery
should be removed if the unit
will be stored for more than one
month. Leaky battery can badly
damage the clock radio.
FM Antenna – The power cord acts
as your FM antenna. The power
cord picks up moderate to strong
stations and eliminates the need for
an external antenna in most strong
signal areas. Be sure the power cord
is stretched out to its full length. Do
not coil or bunch the cord together.
Changing position of the power cord
may improve reception.
Built-In AFC – The Built In
Automatic Frequency Control (AFC)
works only on FM. It helps reducing
drift on FM reception and keeping
the radio locked in on the FM station
to which it is tuned.
When tuning in FM stations, you
may notice that the station you are
tuning can be well-tuned on two
or three nearby points on the dial.
Always tune carefully at the loudest
and clearest point.
If you set Sleep function
with low volume level
before going to bed, we
advise using Wake to Alarm mode.
Illustrations contained within this
publication are for representation
only and subject to change.
The descriptions and characteristics
given in this document are given as
a general indication and not as a
guarantee. In order to provide the
highest quality product possible,
we reserve the right to make any
improvement or modifi cation
without prior notice.
Visit http://store.audiovox.com to find the best
accessories for your products.
© 2010 Audiovox Accessories Corporation
111 Congressional Blvd., Suite 350
Carmel, IN 46032
Trademark(s) ® Registered
Printed in China
