Blade Server Configuration Guide

Dominion KX II Blade Server Configuration Guide – Release 2.1.10, v1.0

Version: Dominion KX Release 2.1.10

Date:

July 9, 2009

Applicable Dominion KX II models:

DKX2-108, DKX2-116, DKX2-132

DKX2-216, DKX2-232

DKX2-416, DKX2-432, DKX2-464

DKX2-832, DKX2-864

Overview:

This guide contains instructions on the configuration of IBM and Dell blade server

chassis KVM and management modules to enable integration with the Dominion KX II

blade server feature introduced in Release 2.1. The guide provides supplemental

information to the Dominion KX II Users Guide featuring screen shots and detailed

instructions.

Contents:

The guide contains instructions and screenshots for configuration of the following blade

server types:

• IBM BladeCenter E or H with Advanced Management Module)

• Dell 1855/1955 with Analog KVM Module

• Dell M1000e with iKVM Module
