Summary of Contents for Prima LPR 712
-
Page 1: Washing Machine
WASHING MACHINE LPR 712 INSTRUCTION BOOKLET 132967680... -
Page 2: Important Safety Information
Important Safety Information It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant warnings. -
Page 3: Table Of Contents
Contents For the User 16-17 Maintenance and Cleaning Descaling Important Safety Information After each wash Maintenance Wash Your New Washing Machine External cleaning Description of the Appliance Cleaning the dispenser drawer Detergent dispenser drawer Cleaning the drawer recess Child safety feature Cleaning the filter 16-17 The Control Panel... -
Page 4: Your New Washing Machine
Your New Washing Machine Your new washing machine meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption. Even small loads are washed “economically” because the amount of water used is regulated automatically according to the load and type of fabric. Automatic cooling of the wash water to 60°C ●... -
Page 5: Description Of The Appliance
Description of the Appliance 1 Detergent dispenser drawer 2 Control panel 3 Door opening handle 4 Filter 5 Adjustable feet Detergent dispenser drawer Prewash Main wash Fabric softener Child safety feature This machine incorporates a special child safety feature to prevent small children from being trapped inside the machine. -
Page 6: The Control Panel
The Control Panel 1Detergent dispenser drawer Rinse Hol When Rinse Hold option is selected, the last rinse water is not emptied out, to prevent the fabrics from 2 Mains-on light creasing. When the programme has finished, the door is This light comes on when the “On/Off” button is locked, the light of the “Start/Pause”... -
Page 7: Programme Progress Display
6 “Prewash “button 10 Programme progress display The machine performs a prewash cycle at 30°C max. By selecting the wash programme, the pilot lights The prewash cycle ends with a short spin at 650 r.p.m. corresponding to the various phases making up the in programmes for Cottons and Synthetics, and with programme come on. -
Page 8: Programme Information
The selector dial can be turned either clockwise or End of “Soak 30” programme anticlockwise. At the end of the soak time, the machine stops Position Eco in cottons and synthetics sectors automatically with water left in the tub. The light of corresponds to the ENERGY SAVING programmes and the “Start/Pause”... -
Page 9: Operating Sequence
“Spin” “Softener” Separate long spin at the maximum speed for hand Hand washed cotton garments can be softened with this washed cotton garments. programme. The machine performs 1 rinse, followed by a final spin at the max. speed, which can be reduced by “Mini”... -
Page 10: Select The Required Programme
4. Select the required programme 7. Start the programme Turn the programme selector dial to the desired position. To start the selected programme, press the “Start/Pause” button; the corresponding light stops flashing. The pilot light corresponding to the wash phase which is running is on. -
Page 11: Washing Hints
Washing Hints Do NOT overload the machine. Weigh the laundry the Use a good quality detergent suitable for automatic ● first few times you use the appliance. washing machines. Use the correct quantities of detergent. ● The average weights of the most common items are listed below as a guide: For wool, use gentle detergent only in small ●... -
Page 12: Which Detergent
Which detergent?..And in which form? To ensure you obtain the best wash results from your Not only are there different types of detergent, but they appliance, it is important to use the right detergent in are also available in different forms. Whether you chose your everyday wash, and only detergents recommended a powder or liquid in traditional or compact form is for use in automatic machines. -
Page 13: Wash Care Symbols
Wash Care Symbols Wash care labels inside garments recommend how to launder your clothes with the best results. The care labelling code is in line with care labelling used in the rest of Europe. The symbols used make it easy to select the correct programme on your washing machine. -
Page 14: Washing Programmes
Washing Programmes Consumption** ype of Programme Additional Max. Section Temp. Energy Water Time fabric description functions load SPIN SPEED/ R. HOLD Cottons 90° Whites Wash at 95°C 5 kg PREWASH, QUICK, 3 rinses EXTRA RINSE Normal spin EASY IRON Wash at 67°C Cottons 90 Eco°... -
Page 15: Special Programmes
Special Programmes Consumption Additional Max. Programme Programme description functions load Time Energy Water Soak 30° Soak at 30°C for about 30 5 kg 0.30 minutes. Stop with water in the tub. 3 rinses with liquid additive 5 kg 0.08 SPIN SPEED/ Rinses RINSE HOLD if required... -
Page 16: Maintenance And Cleaning
Maintenance and Cleaning Before any maintenance or cleaning is carried out you must DISCONNECT the appliance from the electricity supply. Descaling The water we use normally contains lime. It is a good idea to periodically use a water softening powder in the machine. -
Page 17: The Dangers Of Freezing
Unscrew and remove the filter. The dangers of freezing If the machine is exposed to temperatures below 0°C, certain precautions should be taken. Turn off the water tap. ● Unscrew the inlet hose. ● Unhook the drain hose from the rear support and ●... -
Page 18: Something Not Working
Something Not Working Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your local Service Force Centre, please carry out the checks listed below. IMPORTANT: if you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee. -
Page 19: Service And Spare Parts
Symptom Possible causes The machine vibrates when spinning The internal packing has not been removed. ● The machine is in contact with the wall or furniture. ● The machine is not level. ● The washing load is badly distributed in the drum. ●... -
Page 20: Guarantee Conditions
We undertake that if, within 12 months of the date of the agreements. purchase, this Prima appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option, repair... -
Page 21: Installation Instructions
Installation Instructions It is dangerous to alter the specifications or attempt to modify this product in any way. Care must be taken to ensure that the appliance does not stand on the electrical supply cable. Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. -
Page 22: Unpacking
Unpacking Set the machine upright and remove the two remaining bolts from the back. Pull out the three plastic spacers from the holes into All transit bolts and packing must be removed which the bolts were fitted. before using the appliance. Plug the open holes with the plugs supplied with the instruction booklet. -
Page 23: Water Drainage
If you cannot make the cold water connection direct When discharging into a standpipe ensure that the top of from the rising mains, you may be able to operate the the standpipe is no more than 90cm (35.4'') and no less appliance from your cold water storage system. -
Page 24: Levelling
Special conditions If the floor is carpeted or covered with crumbly or soft material, insert a rigid support base under the feet to prevent noise, vibration or displacement. The base should protrude a few centimetres beyond the edges of the machine. Warning The machine should NOT be placed on deep pile Important... -
Page 25: Electrical Connection
Electrical connection The wire coloured green and yellow must be connected to the terminal marked with the letter «E» or by the Any electrical work required to install this appliance earth symbol or coloured green and yellow. should be carried out by a qualified electrician or The wire coloured blue must be connected to the competent person. -
Page 26: Building-In
Building-in a) Door The dimensions of the door should be: This appliance has been designed to be built into the - width 595-598 mm kitchen furniture. - thickness 16-22 mm The recess should have the dimensions shown in picture The height (C-Fig. C) depends on the height of the adjacent furniture's base. - Page 27 Drill four fixing holes see Fig. G Top view If the door has to be opened from left to right, invert the position of the plates (7), the magnet (4) and the plate Position the base into the recess with its front edge as (5) (Fig.
- Page 28 plc 2007...
