POSIFLEX LM-8115 User Manual

LM-8115 / TM-8115 / TM-8315
LCD Touch Monitor
User's Manual
I. FEATURES
• LM/TM-8115 is a stand along LCD monitor for industrial and commercial use.
• TM-8315 is a second display which suit for Posiflex POS Terminals with Gen.5
base stand.
• Application covers POS, Factory Automation etc.
• High quality 15" TFT LCD panel with scaling function for full screen display.
• TM-8315 support power supply through LCD cable from Posiflex Terminals
(Power supply need to setup from terminal and please refer to the terminal's
manual).
• Recommended LCD resolution: 1024 x 768
• Resistive type extra long life touch panel in USB interface or RS232 interface
(option) supports touch panel function including left/right button, double click, drag
& drop
• Touch beep can be pitch adjusted/enabled/disabled by software control (for TM-
8115/TM-8315)
• USB HUB function with 2 ports for optional side mount devices (SD-400Z or KP-
300)
• Connect to host through VGA port plus USB port (for all models) and/or COM port
(for RS232 touch model only)
• Support 2 downlink USB ports
FCC NOTICE
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions manual, may cause interference to radio communications. It has been tested and found to comply with limits for a Class
A digital device pursuant to subpart J of Part 15 of FCC Rules, which are designed to provide reasonable protection against
interference when operated in a commercial environment. Operation of this equipment in a residential area is likely to cause
interference in which case the user at his own expense will be required to take whatever measures to correct the interference.
WARRANTY LIMITS
Warranty will terminate automatically when the machine is opened by any person other than the authorized technicians. The user
should consult his/her dealer for the problem happened. Warranty voids if the user does not follow the instructions in application of
this merchandise. The manufacturer is by no means responsible for any damage or hazard caused by improper application.
ABOUT THIS MANUAL
This manual assists the user to utilize the LCD Monitor LM-8115 series and the Touch Monitor TM-8115/TM-8315 series. This
product provides exquisite touch control capability over a stable and adjustable LCD monitor with minimal footprint.
The manufacturer of the LM-8115 / TM-8115 / TM-8315 touch monitor heartily apologizes to the user for reserving the right to
change or to modify this manual without notice due to the rapid and constant progress and improvement on science and technology.
The user may always obtain the most up to date information through any of our web sites: http://www.posiflex.com,
http://www.posiflex.com.tw, http://www.posiflexusa.com.
TRADE MARKS AND SERVICE MARKS
POSIFLEX is a registered trademark of Posiflex Technology, Inc.
Other brand and product names are trademarks and registered trademarks and service marks of their respective owners.
19690903030
P/N:
Rev. B0
© Copyright Posiflex Technology, Inc. 2011
Part 1
