Summary of Contents for Planar ND1750
-
Page 3: Table Of Contents
Contents Contents ......................1 Preface ........................2 Installation ......................4 Unpacking ....................................4 Desktop Installation................................4 Connecting the Network Display and Base........................4 Viewing Angle Adjustment...............................4 Alternate Mounting Solutions............................5 Detaching Network Display from Its Stand ........................5 Interface for Arm/ Wall Mount Applications ......................5 Connecting the Display to Your Network ........................5 Connecting User Devices..............................6 Connecting the AC Power..............................6 Setting Up the Network Display .............................6... -
Page 4: Preface
Preface This manual is designed to assist users in setting up and using the Integrated Thin Client Network Display (Network Display). Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. -
Page 5: Important Safety Instructions
Important Safety Instructions Please read the following instructions carefully. This manual should be retained for future use. 1. To clean the Network Display screen; -- Power off the Network Display and unplug the AC Cord. -- Spray a non-solvent cleaning solution onto a soft cloth. -- Gently clean the screen with dampened cloth. -
Page 6: Installation
If you find that any of these items are missing or appear damaged, contact Planar immediately. Register Your Planar Products Today Thank you for choosing Planar. To assure you receive all the benefits of your Planar product and services, register your Planar product today. Visit our website to register your product at http://www.planar.com/support/product_registration.html... -
Page 7: Alternate Mounting Solutions
Alternate Mounting Solutions Detaching Network Display from Its Stand Unscrew screws the swivel base support column and pull down the hinge to release. Figure 1-3 Interface for Arm/ Wall Mount Applications Before installing to mounting device, please refer to Fig.1-3. The rear of this LCD display has four integrated 4 mm, 0.7 pitch threaded nuts, as well as four 5 mm access holes in the plastic covering as illustrated in Figure 1-4. -
Page 8: Connecting User Devices
Please contact your Information Technology specialist for further details. A detailed User Guide and Administrators Guide for the Wyse Thin Client Operating System (WTOS) may be obtained at http://www.planar.com/support/ for this product model number. -
Page 9: Display Controls
Display Controls User Controls A brief description and the location of all Network Display functions controls and indicators: Figure 2-1 Power Control - LED Modes are changed by pressing the Power Control Button (Please refer to Figure 2-2) Brightness Function / Adjust increase Brightness Function / Adjust decrease Audio Volume Function / Adjust increase Audio Volume Function / Adjust decrease... -
Page 10: Power Modes
Power Modes The Network Display has three modes of operation. Figure 2-2 The following assumes the AC Power Adapter is connected to the display and an AC power source. Power Mode Operation Description • Power button is pressed for 3 Sec while in Standby mode (Thin client is switched off) •... -
Page 11: Technical Information
Brightness Digital Volume Digital Power Management Power Mode Power Consumption* Power LED Color 60 W maximum Green (DC output, 12V/5A) ND1750: 36 W, typical ND1950: 40 W, typical Standby 12 W maximum Yellow 10 W typical 1 W maximum Dark... -
Page 12: Supported Display Resolutions
Input Voltage Single phase, 100 ~ 240VAC, 50 / 60 Hz Input Current 1.5 A maximum Size and Weight ND1750 ND1950 Dimensions 367 (W) x 384 (H) x 199 (D) mm 413 (W) x 418 (H) x 222 (D) mm Net Weight 4.5 kg... -
Page 13: Troubleshooting
Troubleshooting This Network Display has been pre-adjusted using factory standards. PROBLEM There is no image on Network Display If there’s no image on the Network Display, please perform the following steps: 1. Verify that the power cord is connected to a proper source of power. 2. -
Page 14: End User License Agreement ("License")
End User License Agreement (“License”) IMPORTANT – READ CAREFULLY. THIS LICENSE IS A LEGAL DOCUMENT setting forth the terms under which Planar Systems, Inc. (“Licensor”) and its licensors and suppliers (collectively referred to as “Third Party Suppliers”) are willing to license to you software which is owned by Licensor and/or its Third Party Suppliers, who are intended third party beneficiaries under this License. - Page 15 Software. You may not decompile, reverse engineer or otherwise decode or alter the Software, or attempt to do any of the same, except and only to the extent that applicable law notwithstanding this limitation expressly permits such activity. Software Transfer. You may permanently transfer to another party ownership of the Device and equipment, including all of your rights under this License to use the Software, provided you retain no copies, you transfer the entire product (including the Device and Software, all component parts, the media and printed materials, any upgrades, these license terms, and, if applicable, the Certificate(s) of Authority), and the recipient accepts...
