Heat & Glo VRTIKL-AU Installation & Operation Instructions
Heat & Glo VRTIKL-AU Installation & Operation Instructions

Heat & Glo VRTIKL-AU Installation & Operation Instructions

Freestanding stove

Advertisement

Quick Links

Model:
VRTIKL-AU
FREESTANDING STOVE
AUSTRALIAN GAS ASSOCIATION CERTIFIED
• Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of
this or any other appliance.
• What to do if you smell gas
- Do not try to light any appliance.
- Do not touch any electrical switch. Do not
use any phone in your building.
- Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppli-
er's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
Certifi cate Number: 7153
CAUTION
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
Heat & Glo • VRTIKL-AU • 2123-900 • 7/07
Installation & Operation
Instructions
• Leave this manual with
party responsible for use
and operation.
WARNING
HOT! DO NOT TOUCH.
SEVERE BURNS MAY RESULT.
CLOTHING IGNITION MAY RESULT.
Glass and other surfaces are hot during
operation and cool down.
• Keep children away.
• CAREFULLY SUPERVISE children in same room as
appliance.
• Alert children and adults to hazards of high temperatures.
• Do NOT operate with protective barriers open or
removed.
• Keep clothing, furniture, draperies and other combustibles
away.
Installation and service of this gas stove should be
performed by qualifi ed personnel.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VRTIKL-AU and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Heat & Glo VRTIKL-AU

  • Page 1 - If you cannot reach your gas supplier, call the fi re department. • Installation and service must be performed by a qualifi ed installer, service agency, or the gas supplier. Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 2 Heat & Glo, a brand of Hearth & Home Technologies, Inc. Heat & Glo Quality Systems 20802 Kensington Blvd., Lakeville, MN 55044, USA registered by SGS ICS Copyright 2007 • Printed in U.S.A. Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 3: Table Of Contents

    A. Ignition System Wiring ......22 Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 4: Listing And Code Approvals

    Do NOT use this gas stove if any part has been under water. Immediately call a qualifi ed service technician to inspect the appliance and to replace any part of the control system and any gas control which has been under water. Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 5: Framing And Clearances

    (see fi gure 2.1). tion 12. B. Clearances to Combustibles “A” measurement is from gas stove top, not side. Note: Mantel must Alcove maintain 25mm clearance from vertical fl ue. Millimeters 1372 Figure 2.1 Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 6: Optional Stone Surround Installed

    fl oor strong enough to support gas stove without tipping. • USE wood fl ooring, ceramic tile, brick hearth or high pressure laminate fl ooring applied directly over the sub-fl ooring material. Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 7: Termination Locations

    Figure 3.3 specifi es minimum fl ue heights for various PERPENDICULAR pitched roofs. WALL TERMINATION (GAS ONLY) 460 mm Gas Termination Wood & Fuel Oil Termination 150 mm 510 mm Figure 3.2 Multiple Vertical Termination Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 8 4. See Appendix J, Figure J1(a) and J2(a) for clearances required from a fl ue terminal to a LP Gas cylinder. A fl ue terminal is considered to be a source of ignition. MINIMUM CLEARANCES REQUIRED FOR BALANCED FLUE TERMINALS OR THE FLUE TERMINALS OF OUTDOOR APPLIANCES Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 9: Flue Information

    2. Horizontal terminations are measured to the outside other appliances connected to the fl ue. mounting surface (fl ange of termination cap). See Figure 3.1 on page 7. 3. Horizontal pipe installed level with no rise. Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 10: Flue Diagrams

    D. Flue Diagrams STRAIGHT UP VERTICAL FLUE 3.6M Minimum 11.8M Maximum For Natural and Propane Gases. Figure 4.2 STRAIGHT OUT HORIZONTAL FLUE 610 mm Maximum For Natural and Propane Gases. Figure 4.3 Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 11 V Minimum H Maximum 460 mm 920 mm 920 mm 1.8 M 1.4 M 2.8 M 1.8 M 3.6 M V+H = Max 11 M H Max = 3.6 M Figure 4.5 Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 12 1.8 M 1.5 M 2.7 M V+H1+H2 = Max 10M H1 Max = 2.2M H1+H2 = Max 4.5M V+H1+H2 = Max 10M H1 Max = 1.5M H1+H2 = Max 2.7M Figure 4.7 Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 13 Elbows System V Min. H1+H2 Max. 61 cm 1.0 M 91 cm 1.5 M 1.2 M 2.0 M 1.5 M 2.6 M V+H1+H2 = Max 11.4M H1+H2 = Max 2.6M Figure 4.9 Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 14 460 mm 340 mm 550 mm 920 mm 650 mm 1.1 M 1.4 M 1.0 M 1.6 M 1.8 M 1.8 M 2.1 M V1+V2+H1+H2=Max 10M H1 Max=1.8M H1+H2=Max 2.1M Figure 4.11 Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 15: Horizontal Termination

    The female locking lugs may not be visible from the outside. They may be located by examining the inside of the female ends. Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 16: Slim Line Heat Shield

    • Wear protective gloves and safety replaced with appropriate fasteners for stucco, brick, glasses during installation. concrete, or other types of sidings. The trim ring may be sealed with high temperature caulk or high temperature adhesive. Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 17 MINIMUM CLEARANCE MINIMUM OF 152 mm OF PIPE THROUGH THE WALL INTERIOR WALL 76mm CLEARANCE FROM REAR OF STOVE CENTER LINE HEAT SHIELD OVER TOP HALF OF PIPE TRIM RING Figure 4.18 Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 18: Vertical Termination

    ELBOWS • Do not pack air space with insulation or other materials. Failure to keep insulation or other materials away from fl ue pipe may cause fi re. Figure 4.21 Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 19 Ensure the roofing material overlaps the top edge of the flashing as shown in Figure 4.23. Verify that the chimney is the required height above the roof. See roof pitch table, Figure 3.3. Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 20: Vertical Flue Restrictor

    Do not fill any of the required air space with insulation. Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 21: Gas Information

    Table 1 Natural Gas Propane Minimum Inlet Pressure 1.13 kPa 2.75 kPa Outlet Pressure .80 kPa 2.40 kPa Max. Gas Consumption 26.7 mJ 24.5 mJ Burner Injector 2.53 mm 1.45 mm Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 22: Electrical Information

    MODULE (6V) BATTERY PORT (4 AA BATTERIES) THERMOCOUPLE BLOCK (CONNECTED TO ON/OFF BACK OF VALVE) SWITCH VALVE PILOT GAS LINE CONNECTED TO BACK OF VALVE Figure 6.1 Electronic Ignition Wiring Diagram Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 23: Appliance Setup

    Figure 7.3 After unbolting the gas stove from the pallet, insert two Figure 7.2 1/4 20 x 1-1/2 (or equivalent) counterscrews. Using pliers, adjust the counterscrews to level the gas stove. Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 24: Accessories

    7.8) and set aside. • Only Hearth & Home Technologies approved accessories may be used safely. Remove the four screws from the DV adapter collar (Figure 7.8). Set aside DV adapter collar and screws. Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 25 I NNER EXTENSION COLLAR NNER EXTENSION COLLAR Figure 7.11 Figure 7.9 Install the cover plate with gasket to the top of gas stove with screws previously removed (Figure 7.10). Figure 7.10 Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 26: Positioning The Logs

    Apply 15 mm size pieces sparingly along ports as shown. Place log #1 into the cradle in the burner. Lean the log Do not block ports. back towards right corner of firebox. Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 27: Operating Instructions

    For protection of young children or the infi rm, a secondary • Do not spray aerosols in the vicinity of this guard is required. appliance while it is in operation. Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 28: Lighting The Appliance

    For use with natural or propane gases. 1. Push the ‘OFF’ button on remote. Keep burner and control compart- ment clean. See installation and 2. Remove batteries from receiver. operating instructions accompany- ing heater. Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 29: After Appliance Is Lit

    Noise is caused by metal expanding and contracting as it heats up and cools down, similar to the sound produced by a furnace or heating duct. This noise does not affect the operation or longevity of the gas stove. Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 30: Maintaining And Servicing Appliance

    Refer to maintenance instructions. Figure 8.18 WARNING Inspect external vent cap regularly. • Ensure no debris blocks cap. • Combustible materials blocking cap may ignite. • Restricted air fl ow affects burner operation. Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 31: Maintenance Tasks

    4. Inspect for corrosion or separation. 5. Verify weather stripping, sealing and fl ashing remains intact. Remote Control 1. Verify operation of remote. 2. Replace batteries in remote transmitters and battery-powered receivers. Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 32: Troubleshooting

    Ignitor gap is too Verify that spark gap from ignitor to pilot hood is .43 cm. large. Module is not Verify module is securely grounded to metal chassis of stove. grounded. Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 33: Reference Materials

    Dimensions are actual appliance dimensions. Use for reference only. For framing dimensions and clearances refer to Section 3. Height includes 9.53 mm hearth pad. Hearth Pad 1045 1035 Millimeters Figure 11.1 Appliance Dimensions Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 34: Appliance Dimension With Stone Surround Diagram

    B. Appliance Dimension with Stone Surround Diagram Hearth Pad Height includes 9.53 mm hearth pad. Height includes 9.53 mm hearth pad. 1126 Millimeters Figure 11.2 Appliance Dimensions with Stone Surround Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 35: Flue Components List

    Pipe Support Strap SL-PSD Decorative Radius Cover DRC-RADIUS Slim Line Heat Shield HTI-DV-WT TERMINATION KITS Trapezoid Termination Kit 197 mm - 280 mm, 2 Firestops SLK-01TRD Vertical Termination Cap - High Wind SLK-991DA Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 36: Service Parts

    D. Service Parts VRTIKL-AU Beginning Manufacturing Date: July 2007 Service Parts Diagram VRT-GY-N-AU, VRT-BZ-N-AU Ending Manufacturing Date: ______ VRT-GY-P-AU, VRT-BZ-P-AU Log Set Assembly Part number list on following page. Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 37: Service Parts

    N2P-VRT-AU Conversion Kit (N to P) Conversion Kit (P to N) P2N-VRT-AU Pilot Orifi ce N 2098-518 Pilot Orifi ce P 2098-512 Additional service part numbers may appear on following page. Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 38 2111-186 2123-017 Burner N Burner P 2123-022 Burner Shelf 2123-126 Switch Assembly, Maxitrol 2098-145 Valve N 2098-130 Valve P 2098-131 Thermocouple Block 2098-146 Flex Gas Connector 2098-022 7000-156 Flex Tube Assembly Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 39: Warranty Policy

    It also reserves the right to discontinue styles and products. Please complete this information and retain this warranty in a safe place for future reference: Installation Date:_______ Model #_________ Serial #__________ Installing Contractor:__________________ Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
  • Page 40: Contact Information

    6053165, 6145502, 6170481, 6237588, 6296474, 6374822, 6413079, 6439226, 6484712, 6543698, 6550687, 6601579, 6672860, 6688302B2, 6715724B2, 6729551, 6736133, 6748940, 6748942, D320652, D445174, D462436; (Canada) 1297749, 2195264, 2225408; (Australia) 543790;586383; (Mexico) 97-0457; (New Zealand) 200265; or other U.S. and foreign patents pending. Heat & Glo • VRTIKL-AU • 2123-900 • 7/07...
