Summary of Contents for Fisher-Price T3640
- Page 1 IMPORTANT! KEEP INSTRUCTIONS FOR FUTURE REFERENCE. WARNING T3640 T3640...
- Page 2 Important! DANGER To prevent electric shock, do not immerse in water or expose to rain or moisture; wipe clean with damp cloth. WARNING To prevent strangulation with power cord, never place transmitter within reach of child. CAUTION This product cannot replace responsible adult supervision.
- Page 3 • Always use transmitter and receiver where there is adequate ventilation. To prevent overheating, keep transmitter and receiver away from heat sources such as radiators, heat registers, direct sunlight, stoves, amplifi ers, or other appliances which produce heat. • Fisher-Price ® does not recommend the use of two monitors in one house.
- Page 4 Features...
- Page 5 Transmitter Power Indicator Microphone Power Button Night Light – press to turn on a soft glow. Channel Switch Receiver Speaker Power/Volume Dial – Turns power on. Set volume to a comfortable level. Clip - (backside of receiver). Fasten to your clothes to stay in touch with baby around the house or yard. Sound Lights - let you see baby’s sounds.
- Page 6 Assembly Antenna Antenna Antenna Antenna • Fit each antenna into the socket in the receiver and the transmitter. Turn the antennas to secure in place. IMPORTANT! This product is designed to operate properly with the antennas provided. To reduce the chance of potential radio interference to other users, assemble and use only the antennas provided.
- Page 7 Receiver Battery Installation (Optional) Battery Compartment Door Battery Compartment Door • Locate battery compartment door on back of the receiver. • Loosen screws in battery compartment door with a Phillips screwdriver. Remove battery compartment door. • Insert three “AAA” (LR03) alkaline batteries into the battery compartment. •...
- Page 8 Testing Sound Reception Test transmitter transmission and receiver reception each time you change location of use. Power Button Power Button • Place transmitter in room in which you intend to use it. • Press transmitter power button to turn power on. Power indicator lights. •...
- Page 9 Testing Sound Reception Power/Low Battery Power/Low Battery Indicator Indicator • Place the receiver in the room in which you intend to use it. • Turn power/volume dial to turn power on. Power/low battery indicator lights. Adjust receiver location for best reception. Hint: If battery power is low, the power/low battery indicator turns orange.
- Page 10 Testing Sound Reception Adjust Channel • Sound lights turn on when sound is received by the receiver. - One or two lights for shallow sounds - Three or more lights for louder sounds. • If you experience interference (buzzing or static, etc.) while using one channel setting, switch both units to other channel.
-
Page 11: Setup And Use
Setup & Use IMPORTANT! Test sound reception of this monitor before fi rst time use and whenever you change location of transmitter (see page 8). Adjust Channel • Set transmitter channel switch to same channel as the receiver. - Page 12 Setup & Use • Place transmitter in same room with child. Point microphone directly toward crib/cot or play area. • Unwrap and fully extend power cord for best transmission. Plug power cord into wall outlet. • Use the power cord only in a wall outlet. Do not plug the power cord into a ceiling light. •...
- Page 13 • Place the receiver where you will see or hear it. • Unwrap and fully extend AC adaptor cord for best reception. Insert AC adaptor jack into receiver socket and plug into wall outlet. Note: To use batteries as a power source, refer to instructions on page 7. •...
- Page 14 Setup & Use • Clip the receiver to your clothes to stay in touch with baby around your house or yard. Hint: Under permitting conditions, the receiver receives sounds up to 122 metres away from baby!
-
Page 15: Problems And Solutions
Hint: If, after checking all of these solutions, you believe that your transmitter power cord or AC adaptor are damaged, please contact Fisher-Price Receiver is out of range of transmitter. Move receiver closer to transmitter. Note: Range varies depending on surrounding conditions such as noise levels, physical obstructions and signal interference. - Page 16 Never immerse transmitter, receiver or AC adaptor. Fisher-Price, Inc., a subsidiary of Mattel, Inc. East Aurora, New York 14052, U.S.A. T3640pr-0726 ©2009 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc.
