4 Ton Electric
Log Splitter
Model 40318
Assembly & Operating Instructions
Distributed by Exclusively by Harbor Freight Tools
.
®
Copyright 1999 by Harbor Freight Tools
. All Rights Reserved.
®
No portion of this manual or any artwork contained herein may be reproduced in any
manner, shape or form without the express written consent of Harbor Freight Tools.
For technical questions and replacement parts, please call 1-800-444-3353.
Rev 03/04
Advertisement
Table of Contents
Related Manuals for Central Machinery 40318
Summary of Contents for Central Machinery 40318
-
Page 1: Log Splitter
® No portion of this manual or any artwork contained herein may be reproduced in any manner, shape or form without the express written consent of Harbor Freight Tools. For technical questions and replacement parts, please call 1-800-444-3353. Rev 03/04... - Page 2 SpEciFicaTionS MoDEL # 40318 Log SpLiTTER Electric Motor 2 Horsepower 115 Volts, 15 Amps, 1500 Watts 1 Phase, 60 Hertz, 3450 RPM Power Cord AWG 14, 2’, UL listed, 3-prong Measured Amperage 7 with no load 15 with load 187912...
- Page 3 REMOVE ADJUSTING KEYS AND WRENCHES. Be sure that keys and adjusting wrenches are removed from the tool or machine work surface before operation. AVOID UNINTENTIONAL STARTING. Be sure that you are prepared to begin work before Page 3 SKU # 40318...
-
Page 4: Special Warnings When Using This Log Splitter
REPLACEMENT PARTS AND ACCESSORIES. When servicing, use only identical replacement parts. Use of any other parts will void the warranty. Only use parts and accessories intended for use with this tool, which are available from Harbor Freight Tools. SpEciaL WaRningS WHEn uSing THiS Log SpLiTTER Using this powerful tool may create special hazards. - Page 5 Operation and Maintenance instructions provided in this manual. Figure 2 Major components overview Wedge Log Guiding Plates Log Pusher/Lifting Handle Handle A Handle B Shield Pump Cover Main Body Motor Base Motor Assembly Motor Start Switch Wheels Page 5 SKU # 40318...
-
Page 6: Operation
Stack as you work. This will provide a safer work area, by keeping it uncluttered, and avoid the danger of tripping, or damaging the power cord. Remember to retighten the Bleed Screw (#14) when you are finished. Page 6 SKU # 40318... -
Page 7: Extension Cords
150’ 175’ 200’ AMPS AWG AWG AWG AWG AWG AWG AWG AWG 0-10.0 10.1-13.0 13.1-15 —- 15-18 —- —- Do not modify your plug in any way. If you have any doubt, call a qualified electrician. Page 7 SKU# 40318... -
Page 8: Maintenance
UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. Page 8 SKU # 40318... - Page 9 MoDEL # 40318 Log SpLiTTER paRTS LiST Page 9 SKU # 40318...
- Page 10 MoDEL # 40318 Log SpLiTTER paRTS DiagRaM note: Some parts are listed and shown for illustration purposes only and are not available individually as replacement parts. Page 10 SKU # 40318 REV 02/02 REV 03/04...
-
Page 11: Limited 1 Year / 90 Day Warranty
LiMiTED 1 YEaR / 90 DaY WaRRanTY Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that for a period of one year from date of purchase that the tank is free of defects in materials and workmanship (90 days if used by a professional contractor or if used as rental equipment).
