MILWAUKEE ELECTRIC TOOL CORPORATION – TEST & MEASUREMENT PRODUCT
REPAIR SERVICE INSTRUCTIONS — CALIBRATION
2266-20 Laser TEMP-GUN™ Thermometer
Perform all calibration at an ambient temperature of 23°C ± 2°C / 73.4°F ± 3.6°F and relative
Environmental
humidity of 80% - allow the TEMP-GUN™ thermometer to sit at this temperature for a
Condition
minimum of 30 minutes before proceeding.
MILWAUKEE ELECTRIC TOOL CORPORATION
13135 WEST LISBON ROAD ● BROOKFIELD, WISCONSIN 53005-2550 ● USA
REPAIR SERVICE
INSTRUCTIONS
Calibration
58-92-2266d1 04/2010
