microSD
OPERATING MANUAL
SPECIFICATIONS
Dimension:
Weight:
Operating Voltage:
Operating Temperature:
Clock Frequency:
Operating Humidity:
NOTE: Specifications are subject to change without notice.
REMOVAL OF THE microSD CARD AND ADAPTER FROM BLISTER
1. Hold a corner of the blister.
2. Clap the blister on your palm for removing the plastic case.
3. Hold the blister upside down with about an inch of distance
between the blister and the table.
4. Use your finger to push the edge of the microSD
adapter.
TM
5. Then microSD
card and adapter will drop on the table.
REMOVAL AND STORAGE OF THE microSD CARD IN PLASTIC CASE
1. Hold the case with both hands when opening and closing.
2. Unlock and open the lid of the case.
3. Store or remove the microSD
TM
Ensure the microSD
card and adapter are placed properly on
the tray before closing the case.
4. Lock the plastic case.
PRECAUTIONS FOR HANDLING AND STORAGE
•
Keep out of the reach of children. Get medical advice immediately if swallowed.
•
Do not touch the interface pin directly by hands, metal or hard objects.
•
Do not modify or disassemble the microSD
•
Do not wet, heat/fire, impact, drop or bend the microSD
•
Do not use or store in a humid and dusty place; in hot place such as inside a hot car, under a blazing sun, near
fire, a stove, an air-conditioner outlet, etc.
•
Do not expose to strong magnet fields, electrical noise and put near corrosive chemicals/gas. This may cause
damage through melting or the emission of heat/smoke or cause product failure.
•
Do not place in cooking appliances such as microwave ovens or high-pressure containers.
•
Do not detach the label on the microSD
TM
microSD
card and adapter
DATA PROTECTION
•
MICRODIA microSD
TM
SD card before formatting.
•
Slide down Write-Protect Switch to "LOCK" for preventing record/edit the card. Unlock the card
before reading/writing data.
•
Do not remove the microSD
read, written and transferred. It can cause data to be destroyed.
•
Insert the microSD
TM
card firmly in the correct orientation. The product will not operate correctly if it
is inserted in an incorrect orientation or not inserted all the way
•
Parental Guidance is needed when a child uses the microSD
protect the product and insure that the child follows your instructions.
TM
MEMORY CARD
11.0 (W) x 15.0 (L) x 1.0 (T) mm
Approx. 0.4g
2.7 to 3.6 V
-25°C to +85°C
Up to 25MB/sec
5% to 96% RH
TM
card and adapter in the tray.
TM
card and adapter.
TM
card and adapter. Do not attach other stickers/labels on the
Memory Card comes pre-formatted. Make sure to back up all the data on your
TM
card and switch off any equipment using the card when data is being
CONFIRMATION OF PARTS LIST
TM
microSD
Card
TM
card and
Step 1 & 2
Step 2
TM
card and adapter
TM
card. Teach the child how to use and
TM
Plastic Case
microSD
Adapter
Step 3 & 4
Unlock
Email: info@microdia.com
Website: http://www.microdia.com
Manual
Step 5
Step 3
Lock
MICRODIA Ltd
