Microdia MMCmicro Operating Manual

MMCmicro
OPERATING MANUAL

SPECIFICATIONS

Dimension:
Weight:
Voltage Performance:
Temperature Performance:
Clock Frequency:
Humidity Performance:
NOTE: Specifications are subject to change without notice.
REMOVAL THE PLASTIC CASE FROM BLISTER
1. Hold tight the blister.
2. Hold the blister upside down with about an inch of distance
between the blister and the table.
3. Use your fingers to push the edges of the plastic case.
4. Then MMCmicro TM card and adapter with plastic case will
drop on the table.
REMOVAL AND STORAGE OF THE MMCmicro
1. Hold the case with both hands when opening and closing.
2. Unlock and open the lid of the case.
3. Store or remove the MMCmicro
Ensure the MMCmicro TM
tray before closing the case.
4. Lock the plastic case.

PRECAUTIONS FOR HANDLING AND STORAGE

Keep out of the reach of children. Get medical advice immediately if swallowed.
•
Do not touch the interface pin directly by hands, metal or hard objects.
•
Do not modify or disassemble the MMCmicro
•
Do not wet, heat/fire, impact, drop or bend the MMCmicro
•
Do not use or store in a humid and dusty place; in hot place such as inside a hot car, under a blazing sun, near
•
fire, a stove, an air-conditioner outlet, etc.
Do not expose to strong magnet fields, electrical noise and put near corrosive chemicals/gas. This may cause
•
damage through melting or the emission of heat/smoke or cause product failure.
Do not place in cooking appliances such as microwave ovens or high-pressure containers.
•
Do not detach the label on the MMCmicro
•
MMCmicro TM card and adapter.
All manuals and user guides at all-guides.com
TM
14 (L) x 12 (W) x 1.1 (T) mm
Approx. 0.4g
1.7V to 1.95V or 2.7V to 3.6V
-40°C to +85°C
Minimum 2.4MB/sec
5% to 95%RH
TM
CARD IN PLASTIC CASE
TM
and adapter card in the tray.
and adapter are placed properly on the
TM
card.
TM
card and adapter. Do not attach other stickers/labels on the
CONFIRMATION OF PARTS LIST
TM
MMCmicro Card MMCmicro
Step 1
Step 2
TM card.
TM
Adapter Plastic Case
Step 2 & 3 Step 4
Step 3
Manual
