Page 1
SHINDAIWA GRASS TRIMMER TO BLADE CONVERSION INSTRUCTIONS Model 89291 For Trimmer T242 WARNING! Minimize the risk of injury to yourself and others! Read the Owner's/Opera- tor's manual originally supplied with the unit that is being upgraded and familiarize yourself with the contents. Always wear eye and hearing protec- tion when operating your unit.
The instructions described in this manual are intended to help Always wear a harness when operating this unit you get the most from your Shindaiwa power tool as well as with a blade. A harness to protect you and others from harm. These procedures are is also recommended when using trimmer line.
Safety Labels IMPORTANT! Safety and Operation Information Labels: Make sure all information labels are undamaged and readable. Immediately replace damaged or missing information labels. A new label is provided in this kit and additional labels are available from your local authorized Shin- daiwa dealer.
Assembly Removing the Existing Cutting Attachment Shield 1. Remove the four socket-head cap screws (A), bracket (B) and two shims (C). 2. Remove the cutting attachment shield from the gearcase. Remove Gear Case 1. Remove gear case locating screw (D) and loosen gear case clamp (E).
Page 5
Remove Handle Assembly T242 with 4-screw Handle 1. Remove the four socket-head cap screws (A) on the handle (B) and remove the handle (B) and mounting bracket (C). Handle Positioning Label Install Hanger 1. Position the hanger (A) on the outer tube (B) between the handle and throttle assembly and secure the hanger with the nut (C) and bolt (D).
Page 6
Barrier Bar and Hanger Assembly T242 with 4-screw Handle 1. Install the barrier bar (H) with the socket-head cap screws (A) and nuts (I). Tighten the screws finger-tight ONLY at this time. 2. Locate the handle (B) in the best position for operator comfort (usually about 10 inches ahead of the throttle housing (E)).
Page 7
Install New Cutting Attachment Shield Assemble the Cutting Attachment Shield to the Outer Tube. 1. Insert the cutting attachment shield (A) between the outer tube and the cutting attachment mounting plate (B). 2. Fit the two shims (C) and the upper clamp (D) over the outer tube and in- stall the four socket-head cap screws (E) finger tight.
Page 8
Installing Brushcutter Blade Gear Case with notched flange: 1. Turn the unit over so that the gearcase output shaft faces UP. 2. Align the hole in the holder with the notch in the gearcase flange, and then temporarily lock the output shaft by inserting a hex wrench through both holes.
Page 9
Gear Case with side-mounted locking tool hole: 1. Turn the unit over so that the gearcase output shaft faces UP. 2. Align the notch in trimmer head holder (T) with the notch in the gear case flange. Lock the holder and output shaft by inserting a hex wrench through the locking hole in the gear case and into the aligned notches.
WARNING! A standard grass trimmer unit with loop handle should NEVER be operated with blade-type attachments. For blade use, the trimmer must be fitted with a bicycle-type handlebar or barrier bar that is located in front of the operator to reduce the risk of the operator coming in contact with the cutting attachment.
Using A Brushcutter Blade WARNING! Before working with a blade-equipped unit, always inspect and clear the area of objects that could interfere with or damage the blade. Never use a blade near sidewalks, fence posts, buildings or other objects that could cause injury or damage. ...
Page 12
If you require assistance or have questions concerning the application, operation or maintenance of this product you may call the Shindaiwa Consumer Product Support Department at 1-877-986-7783 from 8:30 am to 4:30 pm (Central Standard Time) Monday through Friday. Before calling, please know the model and serial number of your unit.
