Seagate Medalist 13640 Product Manual

Seagate Medalist 13640 Product Manual

Ultra ata interface drives
Hide thumbs
Table of Contents

Advertisement

Quick Links

Enlarged version
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Medalist 13640, Medalist 10230
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Medalist 6422, Medalist 3210
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ultra ATA Interface Drives
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Product Manual
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Medalist 13640 and is the answer not in the manual?

Questions and answers

Related Manuals for Seagate Medalist 13640

Summary of Contents for Seagate Medalist 13640

  • Page 1 ........Medalist 13640, Medalist 10230 .
  • Page 3 ......... . Medalist 13640, Medalist 10230 .
  • Page 4 1998, 1999 Seagate Technology, Inc. All rights reserved Publication Number: 20400128-001, Rev. B, January 1999 Seagate, Seagate Technology, the Seagate logo and Medalist are reg- istered trademarks of Seagate Technology, Inc. Other product names are registered trademarks or trademarks of their owners.

  • Page 5: Table Of Contents

    Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B Contents Introduction ..........1 Specification summary table .
  • Page 6 Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B 1.12.2 Electromagnetic Compatibility ....14 1.12.3 FCC verification ......15 2.0 Drive mounting and configuration .
  • Page 7 Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B Figures Figure 1. Typical startup and operation current profile ... . 9 Figure 2. Alternate capacity jumper and master/slave jumper ..18 Figure 3.
  • Page 8 Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B...

  • Page 9: Introduction

    Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B Introduction This manual describes the functional, mechanical and interface specifi- cations for the Medalist 13640 (ST313640A), Medalist 10230 (ST310230A), Medalist 6422 (ST36422A) and the Medalist 3210 (ST33210A). These drives are referred to throughout this manual by their model numbers.

  • Page 10: Specification Summary Table

    Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B Specification summary table The specifications listed in this table are for quick reference. For details on specification measurement or definition, see the appropriate section of this manual. Drive Specification ST313640A ST310230A ST36422A...
  • Page 11 Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B Drive Specification ST313640A ST310230A ST36422A ST33210A Length (mm max) 147.00 Weight (grams typical) Track-to-track seek time (msec typical) 1.5 (read), 3.0 (write) Average seek time (msec typical) 9.5 (read), 12.0 (write)
  • Page 12 Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B Drive Specification ST313640A ST310230A ST36422A ST33210A Wet bulb temperature (max) 29.4°C (op.), 29.4°C (nonop.) Altitude (meters below –122 to 3,048 (op.) mean sea level, max) –122 to 12,192 (nonop.) Shock, operating...

  • Page 13: Drive Specifications

    Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B 1.0 Drive specifications Unless otherwise noted, all specifications are measured under ambient conditions, at 25°C, and nominal power. For convenience, the phrases the drive and this drive are used throughout this manual to indicate the ST313640A, ST310230A, ST36422A and the ST33210A.

  • Page 14: Supported Chs Translation Geometries

    Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B 1.1.2 Supported CHS translation geometries These drives support any translation geometry that satisfies all of the following conditions: • Sectors per track • Cylinders 16,383 (for drives over 8.4 Gbytes) •...

  • Page 15: Physical Characteristics

    Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B I/O data-transfer rate 16.6 (PIO mode 4 with IORDY) (Mbytes per second max) 16.6 (multiword DMA mode 2) 33.3 (Ultra DMA mode 2) Interleave Cache buffer (Kbytes) 512 (ST313640A and ST310230A) 256 (ST36422A and ST33210A) 1.4 Physical characteristics...

  • Page 16: Start/Stop Times

    Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B Note. These drives are designed to consistently meet the seek times represented in this manual. Physical seeks, regardless of mode (such as track-to-track and average) are expected to meet or exceed the noted values.

  • Page 17: Figure 1. Typical Startup And Operation Current Profile

    Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B During Standby mode, the drive accepts commands, but the drive is not spinning, and the servo and read/write electronics are in power-down mode. Mode Typical Watts RMS Typical Amps RMS Spinup —...

  • Page 18: Conducted Noise

    Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B 1.7.2 Conducted noise Input noise ripple is measured at the host system power supply across an equivalent 80-ohm resistive load on the +12 volt line or an equivalent 15-ohm resistive load on the +5 volt line.

  • Page 19: Environmental Tolerances

    Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B Sleep mode. The drive enters Sleep mode after receiving a Sleep command from the host. The heads are parked and the spindle is at rest. The drive leaves Sleep mode after it receives a Hard Reset or Soft Reset from the host.

  • Page 20: Altitude

    Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B 1.8.4 Altitude Operating –122 m to 3,048 m (–400 ft to 10,000+ ft) Nonoperating –122 m to 12,192 m (–400 ft to 40,000+ ft) 1.8.5 Shock All shock specifications assume that the drive is mounted securely with the input shock applied at the drive mounting screws.

  • Page 21: Drive Acoustics

    Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B 1.8.6.2 Nonoperating vibration The following table lists the maximum nonoperating vibration that the drive may experience without incurring physical damage or degradation in performance when subsequently put into operation. 5–22 Hz 0.20-inch displacement (peak to peak)

  • Page 22: Reliability

    Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B 1.11 Reliability Nonrecoverable read errors 1 per 10 bits read, max Mean time between failures 400,000 power-on hours (nominal power, 25°C ambient tem- perature) Contact start-stop cycles 40,000 cycles (at nominal voltage and temperature,...

  • Page 23: Fcc Verification

    Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B 1.12.3 FCC verification These drives are intended to be contained solely within a personal computer or similar enclosure (not attached as an external device). As such, each drive is considered to be a subassembly even when it is individually marketed to the customer.
  • Page 24 Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B...

  • Page 25: Drive Mounting And Configuration

    Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B 2.0 Drive mounting and configuration 2.1 Handling and static-discharge precautions After unpacking, and before installation, the drive may be exposed to potential handling and electrostatic discharge (ESD) hazards. Observe standard static-discharge precautions. A grounded wrist-strap is preferred.

  • Page 26: Drive Mounting

    Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B ATA interface connector 2 4 6 4-pin power connector 1 3 5 Alternate capacity and master/slave jumper settings Slave The drive is shipped with a jumper on pins 7 Master or single drive and 8.

  • Page 27: Figure 3. Mounting Dimensions-Top, Side And End View

    Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B Note. Dimensions are shown in mm [inches] 94.3 ± 0.8 [3.71 ± 0.03] 71.8 ± 0.8 [2.83 ± 0.03] 56.5 ± 0.8 [2.23 ± 0.03] 26.10 MAX [1.028] 5.83 ± 0.38 PIN ONE J2 4.66 ±...
  • Page 28 Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B...

  • Page 29: Ata Interface

    Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B 3.0 ATA interface These drives use the industry-standard ATA task file interface that supports 16-bit data transfers. It supports ATA programmed input/output (PIO) modes 0, 1, 2, 3 and 4; multiword DMA modes 0, 1 and 2; and Ultra DMA modes 0, 1 and 2.

  • Page 30: Figure 4. I/O Pins And Supported Ata Signals

    Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B Drive pin # Host pin # and signal description Signal name Reset – Hardware Reset Ground Ground Host Data Bus Bit 7 Host Data Bus Bit 8 Host Data Bus Bit 6...

  • Page 31: Ata Interface Commands

    Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B 3.2 ATA Interface commands 3.2.1 Supported ATA commands The following table lists ATA-standard commands that the drive sup- ports. For a detailed description of the ATA commands, refer to the Draft ATA-4 Standard.
  • Page 32 Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B Command Supported by Command name code ST313640A, ST310230A, ST36422A, ST33210A Write Multiple Write Sectors ATA-standard power-management commands Check Power Mode or E5 Idle or E3 Idle Immediate or E1 Sleep...

  • Page 33: Identify Drive Command

    Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B The following commands contain drive-specific features that may not be described in the Draft ATA-4 Standard . 3.2.2 Identify Drive command The Identify Drive command (command code EC ) transfers information about the drive to the host following power up.
  • Page 34 Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B Word Description Value 10–19 Serial number: ASCII (20 ASCII characters, 0000 = none) Retired 0000 Retired 0100 Obsolete 0000 23–26 Firmware revision (8 ASCII character x.xx string, padded with blanks to end of...
  • Page 35 Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B Word Description Value 60–61 Total number of user-addressable 4FC4 0195 (ST313640A) LBA sectors available: 4312 0131 (ST310230A) 26,562,500 (ST313640A) BDEC 00BE 20,005,650 (ST310230A) (ST36422A) 12,500,460 (ST36422A) D680 0060 6,346,368 (ST33210A)
  • Page 36 Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B Word Description Value Command sets enable extension 4000 0 x 07 Ultra DMA support and current mode Security erase time 0000 Enhanced security erase time 0000 0000 91–127 ATA-reserved Security status 0000 129–159...

  • Page 37: Set Features Command

    Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B 3.2.3 Set Features command This command controls the implementation of various features that the drive supports. When the drive receives this command, it sets BSY, checks the contents of the Features register, clears BSY and generates an interrupt.

  • Page 38: Commands

    Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B 3.2.4 S.M.A.R.T. commands S.M.A.R.T. provides near-term failure prediction for disc drives. When S.M.A.R.T. is enabled, the drive monitors predetermined drive attributes that are susceptible to degradation over time. If self-monitoring determines that a failure is likely, S.M.A.R.T.
  • Page 39 Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B...
  • Page 40 Medalist 13640, 10230, 6422 and 3210 Product Manual, Rev. B Seagate Technology, Inc. 920 Disc Drive, Scotts Valley, California 95066, USA Publication Number: 20400128-001, Rev. B, Printed in USA...

This manual is also suitable for:

Medalist 10230Medalist 6422Medalist 3210
