Am/fm stereo pll synthesized pocket receiver

Advertisement

DT-120/DT-180
GB
Version 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DT-120 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sangean DT-120

  • Page 1 DT-120/DT-180 Version 1...
  • Page 3 Controls POWER/BAND button LCD display DBB/ ‧ STEP button Mono/Stereo button Volume button Tuning jog wheel/Time setting button Lock switch Battery compartment Strap holder Earphone jack Memory button Display Selected band Battery power indicator Signal level indicator FM stereo indicator 90 minutes auto shut off Memory presets Key lock function...
  • Page 4: Battery Installation

    Battery Installation Battery cover is located on the back of the unit. Slide the cover downwards to gain access to the battery compartment. Insert two AAA (UM-4) batteries into the compartment. Make sure that the battery is positioned in accordance with the indicated diagram.
  • Page 5: Time Setting

    Time setting Press and hold Tuning jog wheel for 2 seconds. Hour will flash, turn the Tuning jog wheel to choose your desired time and then press in the Tuning jog wheel to select the digit. After completion of hour setting, minutes digit will then flash, following above setting steps to set minute.
  • Page 6: Volume Control

    Use the volume control knobs to adjust volume level. Display will show the changes when you operate the volume control. Tuning the radio Band Frequency DT-120 522-1629 kHz (9kHz) Antenna DT-120 520-1710 kHz (10 kHz) Internal/rotate radio for best reception...
  • Page 7 90 Minutes auto shut off device For saving battery power, this radio is designed to auto shut off after 90 minutes operation, LCD display shows continuous listening if necessary, pressing POWER/BAND button for more than 2 seconds to turn on the radio. Scan Tuning Turn on the radio, select required band by pressing POWER/BAND button.
  • Page 8: Manual Tuning

    Manual Tuning Turn on the radio, select desired band by pressing POWER/BAND button. D e s i r e d s t a t i o n m a y b e s e l e c t e d b y t u r n i n g t h e Tu n i n g j o g w h e e l intermittently until the desired station is reached.
  • Page 9: Stereo/Mono Switch

    Recall memory stations Turn on the radio, select required band then simply press and release Memory station button. LCD display will show Memory preset and radio frequency. Stereo/Mono switch The radio is designed to receive FM stereo broadcastings. For weak FM station, press MO./ST.
  • Page 10: Setting Fm Frequency Range

    Setting FM frequency range FM range is different from country. It is necessary to adjust FM range to allow the radio to work properly. Press and hold DBB/ . STEP button when your radio is in power off mode, the screen will show the software version (e.g.
  • Page 11 FM/AM step setting After your selection of frequency range, the screen will show FM tuning step (i.e. FM1 50 or 100). Turn the Tuning jog wheel to choose 50 KHZ or 100KHZ and then press the Tuning jog wheel to confirm your setting. After your completion of FM tuning step, the screen will show AM tuning step (i.e.
  • Page 12: Key Lock Function

    Specification Battery: 2 X AAA (LR03, UM-4) Frequency Coverage: FM: 87.50-108 MHz 522-1629 kHz (DT-120 9kHz) 520-1710 kHz (DT-120 10kHz) Output Power: 1.0 mW+ 1.0 mW Earphone Jack: 3.5 mm diameter (stereo) The company reserves the right to...
  • Page 13 If at any time in the future you should need to dispose of this product please note that: Waste electrical products s h o u l d n o t b e d i s p o s e d o f w i t h household waste.
