Salus SPMV22 Instruction Manual

C
Model No: SPMV22 & SPMV32
2 & 3 Port Motorised Valves
Salus Motorised Valves offer the ultimate choice for installers. A simple to replace actuator that requires no need
to drain down. The actuator comes complete with a manual lever for filling or draining down the heating system.
These valves offer outstanding performance and high reliability to the user. Suitable for all domestic
circumstances as well as certain commercial applications. The actuator and valve bodies are supplied together
but actuators can be purchased seperately. Both 2 port and 3 port valves are available in 22mm and 28mm to
cover all applications.
Features
• Suitable for S & C plan applications
• Industry colour coded wiring
• Plug in cable
• LED position indication
• Detachable head
MV22 Dimensions
A - 110 mm
B - 65 mm
C - 95 mm
D - 78 mm
