- Page 1 Dual Arm Monitor Stand for LCD/LED Displays RHMS-11002 User Manual...
- Page 2 Dual Arm Monitor Stand for LCD/LED Displays RHMS-11002 User Manual IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL BEFORE USING THIS PRODUCT Specifications Weight capacity-DO NOT EXCEED: 9*2=18 kg (40 lbs) includes monitor and allaccessories.
- Page 3 Dual Arm Monitor Stand for LCD/LED Displays RHMS-11002 User Manual Step 1 –Attach base assembly to desk A : Desk Clamp 0.6＂（16mm）＜board depth <2.75＂(70mm)
- Page 4 Dual Arm Monitor Stand for LCD/LED Displays RHMS-11002 User Manual B : Through-Desk 1＂(25.4mm)diameter<=2.95＂(75mm) You need disassemble the base［02］ assembly at first ,then assembling again according to the following pic C: Grommet Hole 2.95＂(75mm)<=hole diameter<=3.9＂(100mm)
- Page 5 Dual Arm Monitor Stand for LCD/LED Displays RHMS-11002 User Manual D: Side Mount board depth >2.95＂（75mm）and no mount hole Step 2 –Insert the mount arm[02] to base[01] WARNING:TIGHTENING TORQUE[01-d] BEFORE INSERT THE MOUNT...
- Page 6 Dual Arm Monitor Stand for LCD/LED Displays RHMS-11002 User Manual Step 3 –Lcd mornitor assembling Insert the hand screw [08],through the mount board[01-a] , into the threaded hole in the back of the monitor and lock it. Step 4 –Adjusted the rotating friction As following chart ,adjusting the tightness of head,middle and base location, insert the attached wrench [0A]into the lock screw to keep proper friction during rotation .
- Page 7 Route the cables through the clip [02-b] under the arm and [01-c] on the pole Thank you for purchasing a quality Rosewill Product. Please register your product at : www.rosewill.com for complete warranty information and future support for your product.
