When the card and the driver have been properly installed but no playback is possible:
Check that the DIGI32 appears correctly in the Device Manager. If the device 'DIGI32' is
marked with a yellow exclamation mark then either an address conflict or an IRQ conflict is
present.
If no yellow exclamation mark is present check the 'Resources' tab.
Check that the DIGI32 has been set as 'transmitting device' in the software. Also check
the settings under >Settings /Control Panel /Multimedia /Advanced<. Here the DIGI32
must appear as an audio device when it´s been correctly installed, and can be set as the
Preferred Device under 'Audio'.
The computer crashes whenever the DIGI32 is accessed:
If your graphics board is an older Matrox Mystique or uses a '968' S3 chip, there could be a
memory allocation error. Change the memory area allocated to the DIGI32 to below the
area used by the graphics board (e.g. D0000000 - D0FFFFFF). Detailed information on this
subject can be found in \rmeaudio.web\techinfo\install.htm on the RME Driver CD.
13. DIGICheck: Analysis, Test and Measurements
The DIGI96 series from RME is accompanied by a world wide unique software tool: DIGICheck,
the incredible utility for test, measure and analysis of the digital audio data stream.
Although the DIGICheck software is fairly self-explanatory, it still includes a comprehensive
online help. A detailed description of all functions and the technical background is also avai-
lable in HTML format (digich.htm, in the \techinfo directory on the RME Drivers CD or from our
website). As DIGICheck has been developed for the DIGI96 series, only the following functions
are available when using the DIGI32 series:
Level Meter. High precision 24-bit resolution, 2 channels. Application examples: Peak level
measurement, RMS level measurement, Over detection, phase correlation measurement,
dynamic range and signal-to-noise ratios, RMS to peak difference (loudness), long term
peak measurement, input check
Bit Statistics. Shows the true resolution of audio signals as well as errors and DC offset
Totalyser. Professional 30-band Analyser and Goniometer (Vector Scope)
To install DIGICheck, go to the \DIGICheck directory on the RME Drivers CD and run se-
tup.exe. Follow the instructions prompted on the screen.
