Ritron Quick Assist Owner's Manual

Wireless callbox transmitter
Hide thumbs
Table of Contents

Advertisement

Quick Links

________________________________________________________________________________________________________________________
Description
®
What this Manual Covers ....................................................1
General Information ............................................................1
®
Models and Frequencies ..............................1
®
Features .......................................................1
Important Safety Information ....................................................1
for this Product .........................................................................2
Programming............................................................................3
®
Programming Features ......................................4
Summary Screen ................................................................4
Append Battery Messages.............................................4
Low Battery Alarm Enabled ...........................................4
Play Location Message..................................................4
Message Delay on TX ...................................................4
Description.....................................................................4
Input Screen........................................................................4
Frequency Table............................................................4
Transmit Frequency.......................................................4
QC or DQC Code...........................................................5
DQC Invert.....................................................................5
Compand .......................................................................5
TX Alert Tone ................................................................5
Press and Hold Reset....................................................5
ANI.................................................................................5
Message Repeat............................................................5
Voice Messages ............................................................5
Power Options Screen ........................................................6
Frequency Table............................................................6
Transmit Frequency.......................................................6
QC or DQC Code...........................................................6
DQC Invert.....................................................................6
Compand .......................................................................6
TX Alert Tone ................................................................6
___________________________________________________________________________________________________________
Ritron Publication 14500079
© 2011 Ritron, Inc. All rights reserved. Ritron, Patriot, Jobcom, OutPost, GateGuard, Quiet Call and Quick Assist
Inc. Quick Talk, Liberty and RadioNexus are trademarks of Ritron, Inc.
Call 800-USA-1-USA for the right Wireless Solutions to your communication needs.
P.O. Box 1998 • Carmel, Indiana 46082-1998 • USA
Phone: 317-846-1201; 800-USA-1-USA (800-872-1872) • Fax: 317-846-4978
Email: ritron@ritron.com • Website: www.ritron.com
Quick Assist
W
IRELESS
O
WNER
Page
®
Rev. A 07-11
C
T
ALLBOX
'
M
S
ANUAL
Description
ANI ................................................................................ 6
Message Repeat ........................................................... 6
®
Default Programming......................................... 6
Tone......................................................................................... 7
Table 1: MURS model radios only ...................................... 7
Table 2: VHF Business band models................................. 7
Table 3: UHF Business band models ................................ 7
Table 4: Canadian UHF model radios only ......................... 8
Table 5: Quiet Call Tone Codes.......................................... 8
Table 6: Digital Quiet Call Codes....................................... 8
Assist Message................................................................... 9
Reset Message................................................................... 9
Low Battery Message ......................................................... 9
Location Message............................................................... 9
Record Custom Voice Messages ............................................. 9
using the on-board microphone: ......................................... 9
Installation / Replacement of Batteries................................... 10
Automatic Low Battery Alert Message ................................... 11
Care and Maintenance........................................................... 11
FIG-1: Controls & Connectors.......................................... 12
Ritron, Inc. Limited Warranty.................................................. 13
®
RANSMITTER
®
®
Voice Messages....................... 9
®
®
Programming................................... 10
®
.................................................... 11
®
®
are registered trademarks of Ritron,
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Quick Assist and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ritron Quick Assist

Summary of Contents for Ritron Quick Assist

  • Page 1: Table Of Contents

    Ritron Publication 14500079 Rev. A 07-11 ® © 2011 Ritron, Inc. All rights reserved. Ritron, Patriot, Jobcom, OutPost, GateGuard, Quiet Call and Quick Assist are registered trademarks of Ritron, Inc. Quick Talk, Liberty and RadioNexus are trademarks of Ritron, Inc.

  • Page 2: About The Quick Assist

    Because it’s six internal AA Alkaline batteries will - Transmit Frequency; power the unit for about a year, the Quick Assist® does not ® - Tone Coded Squelch Encoder (Quiet Call Interference require AC line power.

  • Page 3: Please Note The Following With Regard To Rf Exposure For This Product

    RQA-151, RQA-151M, RQA-451, RQA-451-CANADA: This product generates radio frequency (RF) energy when the • Use only the antenna(s) available from RITRON for these button on the front of the unit is depressed. This product has models. DO NOT operate the radio without an antenna.

  • Page 4: Frequently Asked Questions About Quick Assist Programming

    F.C.C. Station License. Consult your radio user manual, coded squelch signals required for your radio system. your dealer, or call Ritron for help if you cannot determine your ® Do I need to test my Quick Assist Transmitter? radio’s receiver frequency.

  • Page 5: Summary Screen

    ROGRAMMABLE EATURES ® The Quick Assist can be programmed with unique voice messages and attributes. All programming is accomplished with the RITRON RQA/RQT PC Programmer software available at www.ritron.com. ® The programmer software requires Window XP or greater, and a PC computer with a USB port.

  • Page 6: Qc Or Dqc Code

    Message Repeat To identify your QC or DQC tone: Number of Message Transmissions • Read-out the Tone Code of the RITRON radio you intend to You can set a limit to the number of times the message will be ®...

  • Page 7: Power Options Screen

    FIG-5: Programmer Power Options Screen Message Repeat Frequency Table # Time between transmissions To match other RITRON radios, the owner can select from a ® This sets the amount of time the Quick Assist will wait before table of transmit frequencies. Simply “read-out” the Frequency re-transmitting a Low Battery Alert message.

  • Page 8: Programming Your Quick Assist Transmitter Frequency And Tone

    The Quick Assist transmitter operates exclusively on a 12.5 kHz narrow band channel bandwidth. Many of the Frequency Table Codes programmed in your compatible Ritron radios are for 25 kHz wide band channels. If these codes are selected when ®...

  • Page 9: Table 4: Canadian Uhf Model Radios Only

    Use Code “44” to program No Tone for systems without a Coded Squelch Interference Eliminator feature. TABLE 6: Digital Quiet Call Codes Code Code Code Code Code Code Code Code Code ________________________________________________________________________________________________ For assistance, call RITRON at 800-872-1872, or go to www.ritron.com...

  • Page 10: Recording Your Quick Assist Voice Messages

    Do I need to record Custom Voice Messages? messages, an “Assistance needed” message that is transmitted when If the factory-recorded messages “Assistance the front panel push button is pressed, and a “Quick Assist call cleared” needed” and “Quick Assist call cleared” suit your ®...

  • Page 11: Test Your Quick Assist Programming

    Install the battery holder lid and connect the two polarized, in-line battery connectors. ® Press the front panel push button and test the Quick Assist listening on a receiving radio. Secure the case halves with the four corner screws and re-install on the wall or mounting surface.

  • Page 12: Automatic Low Battery Alert Message

    ® Chemicals: Do not use harsh, corrosive or abrasive chemicals to clean the Quick Assist case; use only a cloth moistened with water. Do not attempt to clean the printed circuit board inside the housing.

  • Page 13: Identification Of Quick Assist Controls And Connectors

    Press this button to initiate voice recording. Front Panel LED Internal Antenna ® The red front panel LED is lit whenever the Quick Assist The internal antenna radiates radio signals. is transmitting a message. Front Panel Push Button SMB Antenna Connector...

  • Page 14: Ritron, Inc. Limited Warranty

    Attention: Warranty Department. Please point out the nature of the defect in as much detail as you can. You must retain your sales or lease receipt (or other written evidence of the date of purchase) and deliver it along with the product. If RITRON chooses to repair or replace a defective product, RITRON may replace the product or any part or component with reconditioned product, parts or components.

This manual is also suitable for:

Quick assist rqa-151Quick assist rqa-151mQuick assist rqa-451Quick assist rqa-451-canada
