- Page 1 19” Liquid Crystal Display Television Fernsehers mit Flüssigkristallanzeige Téléviseur à Écran à Cristaux Liquides TV de Pantalla de Cristal Líquido Questo televisore LCD LCD (vloeibaar-kristalscherm) TV Televisor com Ecrã de Cristais Líquidos Telewizora ciekłokrystalicznego Жидкокристаллического Телевизионного Дисплея S_LCD2_UM_EUR_R01_K 62-01000016G000...
-
Page 2: Table Of Contents
19EU.book Page 1 Thursday, April 10, 2008 5:31 PM Table of Contents Regulatory Information ..............3 Description of Warning Symbols ..........3 Safety Notices ................4 Preface ..................6 Warranty and Service ..............6 1. Getting Started ................ 8 1.1 Package Contents ............. 8 1.2 Introducing the TV ............. - Page 3 19EU.book Page 2 Thursday, April 10, 2008 5:31 PM Table of Contents 3.3 Adjusting Sound Settings ..........25 3.4 Adjusting Channel Settings (Analog TV) ......25 3.5 Adjusting DTV Settings (Digital TV) ........27 3.6 Adjusting PC Setup Settings ..........29 3.7 Adjusting Setup Settings ..........
-
Page 4: Regulatory Information
Directive 2006/95/EC on the harmonization of the laws of Member States relating to electrical equipment for use within certain voltage limits. Hannspree cannot accept responsibility for any failure to satisfy the requirements resulting from a non-recommended modification of the device. -
Page 5: Safety Notices
19EU.book Page 4 Thursday, April 10, 2008 5:31 PM Safety Notices Installation Safety Notes Location Avoid allowing the TV to get prolonged exposure to sunlight or other strong sources of heat. Leave sufficient distance between the TV and the wall to provide enough space for the emission of heat. - Page 6 19EU.book Page 5 Thursday, April 10, 2008 5:31 PM Personal Safety 1. To avoid overloading the power supply, never plug too many electrical devices into an outlet, power strip, or extension cable. 2. Dangerous high-voltage electric power components are located inside the TV.
-
Page 7: Preface
The information in this manual is subject to change without notice. To the extent allowed by applicable law, Hannspree, Inc. (“Hannspree”) shall not be liable for direct, indirect, special, exemplary, incidental or consequential damages arising from any defect or omission in this manual, even if advised of the possibility of such damages in advance. - Page 8 Hannspree. The TV described in this manual may include copyrighted software of Hannspree (or other third parties). Hannspree (or other third parties) preserves the exclusive rights for copyrighted software, such as the right to distribute or reproduce the copyrighted software.
-
Page 9: Getting Started
19EU.book Page 8 Thursday, April 10, 2008 5:31 PM Getting Started Package Contents Make sure the following components are included in the box. Please contact Hannspree Customer Service immediately if anything is missing or damaged. • • User’s manual •... -
Page 10: Introducing The Tv
19EU.book Page 9 Thursday, April 10, 2008 5:31 PM Introducing the TV You can watch PAL/ SECAM broadcast, cable or digital television channels, and easily connect a VCR, STB or DVD player to the standard CVBS, S-Video and SCART input ports (location of these ports depends on model). You can also use the TV as a monitor for your PC by connecting it through the D-sub port. -
Page 11: Control Panel
19EU.book Page 10 Thursday, April 10, 2008 5:31 PM Control Panel Description ICON Function Power Press to turn the TV on or off. Source INPUT Press to display the input source list. Menu MENU Press to open the OSD menu. Press to increase the program number Program select or move upward to the previous item on... -
Page 12: Input And Output Jacks
19EU.book Page 11 Thursday, April 10, 2008 5:31 PM Input and Output Jacks Description Connector Function Cable/Antenna Connect to an antenna or cable TV. Connect to earphones or external Earphone Output speakers with built-in amplifier. EAR PHONE Audio for PC Connect to a PC’s line/ audio out PC LINE IN Input... -
Page 13: Remote Control
19EU.book Page 12 Thursday, April 10, 2008 5:31 PM Description Connector Function Connect to the provided power Power Connector AC IN cord. Remote Control Description Icon Function Power Press to turn the TV on or off. Source INPUT Press to display the input source list. Use to select a program directly. - Page 14 19EU.book Page 13 Thursday, April 10, 2008 5:31 PM Description Icon Function Electronic Press to display program information. Program (For DTV only) Guide Teletext mode TEXT Press to switch to the teletext mode. Press VOL to increase audio volume. Volume adjust / VOL Press VOL to decrease audio volume.
- Page 15 19EU.book Page 14 Thursday, April 10, 2008 5:31 PM Description Icon Function Press to display the hidden information, Reveal REVEAL such as solutions to puzzles. (Programmable in the teletext mode only) Press to display the subtitles while Subtitle SUB.TITLE watching DTV. Favorite Press to select or store your favorite FAV.
- Page 16 19EU.book Page 15 Thursday, April 10, 2008 5:31 PM CAUTION • If the remote control is not used for a long period, remove the batteries and store them properly. • Handle damaged or leaking batteries carefully, and wash hands with soap if they come in contact with leaked chemical fluids.
-
Page 17: Setting Up Your Tv
19EU.book Page 16 Thursday, April 10, 2008 5:31 PM Setting up your TV Basic Connections 2.1.1 Power Connection 1 Connect the power cord to the AC IN input jack on the rear of the TV. 2 Insert the plug at the other end of the power cord into a power outlet. 2.1.2 Connecting an Antenna or Cable TV Connect one end of the VHF/UHF (Antenna) or CATV cable to TV/DTV jack on the... -
Page 18: Connecting External Devices
19EU.book Page 17 Thursday, April 10, 2008 5:31 PM Connecting External Devices Connect external devices such as VCRs, STBs, DVD players, video game consoles, earphones, or a PC to the TV using the appropriate ports on the rear of the TV. 2.2.1 Connecting External Earphones Headphones... -
Page 19: Connecting To Av Devices
19EU.book Page 18 Thursday, April 10, 2008 5:31 PM 2.2.2 Connecting to AV Devices The following diagram illustrates how to connect the AV devices to your TV via HDMI (A), Component (B), SCART (C), and Composite (D) ports. AUDIO AUDIO HDMI SCART IN / OUT HDMI Cable... -
Page 20: Connecting A Vcr/ Stb/ Dvd Player Using Component Video
19EU.book Page 19 Thursday, April 10, 2008 5:31 PM 2.2.3 Connecting a VCR/ STB/ DVD Player Using Component Video Connect the TV to a VCR/ STB/ DVD player using the component video inputs. AUDIO Audio Cable (Optional) Video Cable (Optional) 2.2.4 Connecting a VCR/ STB/ DVD Player Using Composite Video... -
Page 21: Connecting A Decoder Or Vcr/ Stb/ Dvd Player Using Scart
19EU.book Page 20 Thursday, April 10, 2008 5:31 PM 2.2.5 Connecting a Decoder or VCR/ STB/ DVD Player Using SCART Connect the TV to a decoder or VCR/ STB/ DVD player using the SCART input. You can choose to use a SCART cable or adapter for the connection depending on the ports available on your decoder or player. -
Page 22: Connecting Hdmi
19EU.book Page 21 Thursday, April 10, 2008 5:31 PM 2.2.7 Connecting HDMI HDMI (High Definition Multimedia Interface) assures that the best video signal is always sent form source to the TV. Refer to the following illustration to connect an HDMI device to the TV. HDMI DVD Player HDMI Cable... -
Page 23: Using The Tv
19EU.book Page 22 Thursday, April 10, 2008 5:31 PM Using the TV 2.3.1 Turning the TV On and Off 1 Press on the control panel or remote control. The power LED indicator on the front of the TV changes from amber to blue, indicating that the power is on. 2 Press again. -
Page 24: Adjusting On-Screen Display (Osd) Settings
19EU.book Page 23 Thursday, April 10, 2008 5:31 PM Adjusting On-Screen Display (OSD) Settings The On-Screen Display (OSD) menu system provides a quick and simple method to adjust the TV settings. The OSD menu can be accessed through the buttons either on the control panel or the remote control. -
Page 25: Osd Setting Menus
19EU.book Page 24 Thursday, April 10, 2008 5:31 PM OSD Setting Menus Follow the instructions indicated on the right side of the OSD Function Menu. Press on the control panel or arrow keys to scroll through the menus, VOL + on the control panel or the arrow key to select an item, or MENU to exit the OSD menu. -
Page 26: Adjusting Sound Settings
19EU.book Page 25 Thursday, April 10, 2008 5:31 PM Adjusting Sound Settings Press MENU to enter the OSD Main Menu Main Menu Sound Sound Mode Standard screen. Balance Select Press to select Sound. Treble MENU Press to enter the Sound Menu. Exit Bass Press... - Page 27 19EU.book Page 26 Thursday, April 10, 2008 5:31 PM • The area can be set to England, Italy, France, Spain, Netherlands, Portugal, Turkey, Poland, Russia, and Germany*. • The Colour System can be set to AUTO, PAL, or SECAM. • The Sound System can be set to AUTO, BG, DK, I, L, or L’. •...
-
Page 28: Adjusting Dtv Settings (Digital Tv)
19EU.book Page 27 Thursday, April 10, 2008 5:31 PM Adjusting DTV Settings (Digital TV) Press MENU to enter the OSD Main Menu Main Menu Channel Management screen. Area England Select Press to select DTV. Auto Search MENU Press to enter the DTV Menu. Exit Manual Search Preferred Audio... - Page 29 19EU.book Page 28 Thursday, April 10, 2008 5:31 PM • Select Manual Search to search the TV/ Radio channels manually. Manual Search Channel Name Freq(KHz) 177500 BandWidth Signal Quality • Select Parental Lock to change the password. The old password is set to 0000 by default.
-
Page 30: Adjusting Pc Setup Settings
19EU.book Page 29 Thursday, April 10, 2008 5:31 PM Adjusting PC Setup Settings Main Menu Press MENU to enter the OSD Main Menu PC Setup Auto Adjust screen. H Position Select Press to select PC Setup. V Position MENU Exit Phase Press to enter the PC Setup Menu. - Page 31 19EU.book Page 30 Thursday, April 10, 2008 5:31 PM The Setup menu can be used to adjust the Language, TT Language, SCART, HDMI Scan Info, Aspect, Dynamic Contrast, OSD Time, Background, Reset settings. • The available nine languages are English, Italian, Spanish, Portuguese, French, German, Russian, Polish, and Dutch.
-
Page 32: Troubleshooting
19EU.book Page 31 Thursday, April 10, 2008 5:31 PM Troubleshooting Situation Solution • Connect the power cord properly. • Check if the power LED is on or not. • Press power on the control panel or remote control. No picture and sound. •... -
Page 33: Specifications
19EU.book Page 32 Thursday, April 10, 2008 5:31 PM Specifications LCD Panel Size 19 inch TFT Screen Format Panel Resolution 1280 (H) x 1024 (V) TV System ATV: PAL, SECAM DTV: DVB-T AV (Pal/ Secam/ NTSC) SCART (RGB/ CVBS/ S-Video) Video System HDMI HDTV (YP... -
Page 34: Pc Mode Support Timing
19EU.book Page 33 Thursday, April 10, 2008 5:31 PM PC Mode Support Timing Horizontal Vertical Pixel Mode Resolution Frequency Frequency Frequency (kHz) (Hz) (MHz) VGA 60 640x480 @60 31.469 59.941 25.175 SVGA 60 800x600 @60 37.879 60.317 40.000 XGA 60 1024x768 @60 48.363 60.004... - Page 35 MEMO...
